H O M E

C O N T R O L

Vitrum Scene Control Panel

INSTALLATION and OPERATION

Table of Contents

Need help?

Do you have a question about the Scene and is the answer not in the manual?

Questions and answers

Summary of Contents for Vitrum Scene

Page 1 H O M E C O N T R O L Vitrum Scene Control Panel INSTALLATION and OPERATION...
Page 2: Table Of Contents
2. Positioning the glass decor panel . . 6 It’s used for creating lighting scenarios in 3. Vitrum is intelligent ... . . 8 your house: simply pressing a button, you 4.
Page 3: Before Starting
Carefully check that the wires and connectors are securely fastened. After securing the unit to the wall-mounting box, temporarily use the plastic cover for protection until the glass décor plate is fitted. Do not install Vitrum in the vicinity of sources of heat or in conditions of high humidity.
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS Electrical connections with neutral wire: connect the live wire to the terminal marked “L”, the neutral wire to the terminal marked “N”:...
Page 5 After connecting, check that the wires are correctly positioned inside the wall- mounting box. When securing Vitrum to the wall-mounting box, use the screws sup- plied and note that the maximum torque to be used when tightening the screws in the embedding box is 0.8 nm.
Page 6: Positioning The Glass Decor Panel
POSITIONING THE GLASS DECOR PANEL In order to refit the glass panel correctly, ensure that the four plastic tabs on the panel are in perfect alignment with the anchor holes. When the glass panel tabs are aligned with the holes, press the four corners of the glass panel evenly until it is fully inserted into the wall-mounting box.
Page 7 After fitting the glass panel, the buttons remain inoperative for about 10 seconds. An acoustic signal sounds three times to indicate that the sensors have been recalibrated, after which they resume normal operation. to remove the glass panel from the wall-mounting box, gently lever the upper or lower edge away. Anchor holes on décor panel...
Page 8: Vitrum Is Intelligent
“Z-Wave” Wireless technology, each Vitrum Wireless unit offers numerous advantages if connected as part of a network: it is possible to associate multiple Vitrum units, to construct scenarios, and to control lights using a remote control unit. If you connect Vitrum into a pre-existing z-wave net working with third parts devices, please refer to instruction and procedure of your remote control.
Page 9 • Place the hOME MAStER remote handset near the Vitrum unit to be included in the network. touch any of the keys on Vitrum to include the unit in the home wireless network. Everytime a new device is included into the zwave net, you must include your Vitrum scene again;...
Page 10 NOTE A Vitrum unit cannot be added to the network if it has already been included in a different network. In this case, it is necessary to perform the factory reset procedure -> see Paragraph 7).
Page 11: Advanced Functions
For creating a control logic, the modules must first be included in the home wireless network -> see paragraph 3. It’s very simple to create a scene. First of all you need to associate your Vitrum Scene to all the other buttons of other Vitrum that you desire be part of the scene (max 8 Vitrum).
Page 12 Press the buttons of the other Vitrum that are physically connected to the lighs you want to be part of the scene. the lED corresponding to the selected button/channel will flash magenta until the ‘association’ process has been completed. When finished “ASC”...
Page 13 After that , every time you press it, it will set all the light of your scene to the selected level; pressing again and you will switch all the light off. Perform the same operation with all Vitrum scene button.
Page 14: Factory Reset
FACTORy RESET Proceed as follows to reset the Vitrum unit to the original factory settings: EXCLuSION from the home network using the hOME MAStER remote han- dset: “EXC” • Press on the hOME MAStER remote handset and wait until the yellow lED lights.
Page 15 • Vitrum will flash red three times and sound an acoustic signal to indicate that the original configuration has been restored. FACTORy RESET using the hidden button • Remove the Vitrum unit from the wall-mounting box. • Press the hidden Factory Reset button and hold down for at least 3 seconds.
Page 16: Supervision
If you have decided to activate the hOME MAStER supervision apps for iPad ® you will find that the “identification” function featured by every Vitrum unit is extremely useful. “Identification” status is indicated when all the illuminated rings light Magenta and begin to flash. this functional status is created directly by the supervision app as soon as the corresponding command is entered.
Page 17: Compatibility
Vitrum wireless units. In this way, your system can easily be extended to operate with different applications and thus adapted to your specific needs.
Page 18: Main Technical Specifications
MAIN TECHNICAL SPECIFICATIONS Vitrum Scene Control Panel Power supply 240V/50hz Energy consumption <1 w Operating temperature 0-40° C (from / to) Wireless Z-Wave modem 868,4 Mhz frequency Range in open air 20 mt IP Protection Rating IP 40...
Page 19 VItRUM please visit our site: www.vitrum.com...
Page 20 H O M E C O N T R O L Think Simple SpA Head Office viale lino Zanussi, 3 tel +39 0434 516 216 33170 Pordenone Fax +39 0434 516 230 Sales Office corso Garibaldi, 86 tel +39 02 655 600 29 20121 Milano Fax +39 02 454 982 95 www.thinksimple.it...
