- Page 1 Defibtech Lifeline VIEW AED Manual Get an original copy of the Defibtech Lifeline VIEW AED Manual for manufacturer information about service, available accessories and how to use and maintain your device.
-
Page 2: User Manual
Defibtech DDU-2000 Series Automated External Defibrillator • DDU-2300 • DDU-2450 User Manual For comprehensive training on set-up, use and maintenance; source for complete technical specifications ELECTRONIC DISTRIBUTION DAC-A2510EN-BG... -
Page 3: Apply Pads
PRESS “ON” BUTTON APPLY PADS FOLLOW AED INSTRUCTIONS DAC-A2510EN-BG... -
Page 4: Limited Warranty
Notices Defibtech, L.L.C. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. Information in this document is subject to change without notice. Names and data used in any examples are fictitious unless otherwise noted. -
Page 5: Table Of Contents
Contents Introduction To The DDU-2000 Series AED ............6 Overview ........................... 6 The Defibtech DDU-2000 Series AED ................8 Usage ..........................10 Dangers, Warnings, And Cautions ..............11 Dangers ........................11 CAUTION DANGER WARNING Warnings ........................11 CAUTION DANGER WARNING Cautions ........................12 CAUTION DANGER WARNING... - Page 6 Maintenance Mode ..................38 7 .1 Overview ......................... 38 7 .2 Navigation (in Maintenance Mode) .................. 38 7 .3 Entering Maintenance Mode ................... 39 7 .4 AED Main Menu Screen ....................39 7 .5 AED Status Screen ......................39 7 .6 AED Maintenance Screen ....................
-
Page 7: Introduction To The Ddu-2000 Series Aed
Introduction To The DDU-2000 Series AED This User Manual provides information to guide trained operators in the use and maintenance of the Defibtech DDU-2000 Series Automated External Defibrillator (AED) and its accessories. It includes comprehensive training on set-up, use, and maintenance and is the source for complete technical specifications. This chapter includes intended use, an overview of the AED, a discussion of when it should and should not be used, and information on operator training. - Page 8 Defibrillation and AED operating power is supplied with a replaceable (non-rechargeable) battery pack that provides for long standby life and low maintenance operation. Each battery pack is marked with an expiration date. The DDU-2000 Series AED records event documentation internally and, optionally, on a Defibtech Data Card (DDC). The optional DDC card inserts into a slot in the AED and enables the AED to record event documentation and, optionally, audio data onto the card.
-
Page 9: The Defibtech Ddu-2000 Series Aed
1.2 The Defibtech DDU-2000 Series AED A. Speaker. The speaker projects the voice J. USB and Defibtech Data Card (DDC card) prompts when the DDU-2000 Series AED is Access Door. Behind the access door is the on. The speaker also emits a “beep” when USB connector port and Defibtech Data Card the unit is off and has detected a condition (DDC card) slot. - Page 10 E. Pads Connector Socket F. Active Status Indicator (ASI) D. ON/OFF Button C. Display Screen G. Softkey Buttons (Top, Center, Bottom) B. SHOCK Button H. USB Port A. Speaker I. Defibtech Data Card (DDC Card) (optional) J. USB and Defibtech Data Card (DDC Card) Access Door FRONT OF AED R.
-
Page 11: Usage
1.3 Usage Indications The DDU-2000 Series Automated External Defibrillator (AED) is indicated for use on victims of sudden cardiac arrest (SCA) who are: • Unconscious and unresponsive • Not breathing or not breathing normally For patients under 8 years old, or weighing less than 55 lbs (25 kg), use child/infant defibrillation pads, if available. Do not delay therapy to determine exact age or weight. -
Page 12: Dangers, Warnings, And Cautions
Dangers, Warnings, And Cautions This chapter includes a list of danger, warning, and caution messages that relate to the Defibtech DDU-2000 Series AED and its accessories. Many of these messages are repeated elsewhere in this User Manual and on the DDU-2000 Series AED or accessories. -
Page 13: Caution Danger Warning
WARNINGS (continued) • Avoid contact between parts of the patient’s body and conductive fluids such as water, gel, blood or saline, and metal objects, which may provide unwanted pathways for defibrillating current. • Disconnect all non-defibrillator proof equipment from the patient before defibrillation to prevent electrical shock hazard and potential damage to that equipment. -
Page 14: Setting Up The Ddu-2000 Series Aed
Setting Up The DDU-2000 Series AED This chapter describes the steps required to make your Defibtech DDU-2000 Series AED operational. The DDU-2000 Series AED is designed to be stored in a “ready” state. This chapter tells you how to make the device ready, so that if and when you need it, few steps are required to begin using the device. -
Page 15: Connecting The Defibrillation Pads
3.2 Connecting The Defibrillation Pads The DDU-2000 Series AED defibrillation pads are supplied sealed in a package with the connector and part of the cable exposed. DO NOT open the sealed pads package until the pads are to be used. The packaging should be opened only immediately prior to use, otherwise the pads may dry out and become non-functional. -
Page 16: Checking The Ddu-2000 Series Aed Status
3.4 Checking The DDU-2000 Series AED Status Active Status Indicator (ASI) Once a fully functional battery pack is installed in the DDU-2000 Series AED, an LED indicator located to the right of the ON/OFF button actively indicates unit status. If the unit is ready for use, the Active Status Indicator (ASI) will flash green. -
Page 17: Installing The Defibtech Data Card (Ddc Card) (Optional)
3.5 Installing The Defibtech Data Card (DDC Card) (optional) The Defibtech Data Card (DDC card) is used to store event and audio information collected by the AED. All DDU-2000 Series AEDs will operate without DDC cards and will still store select event information internally. Information stored on the DDC card is retrievable with a separate Defibtech PC-based software package. -
Page 18: Using The Ddu-2000 Series In Aed Mode
Using The DDU-2000 Series In AED Mode This chapter describes how to use the DDU-2000 Series in AED Mode. In AED Mode, the unit analyzes the patient’s rhythm and automatically charges if a shockable rhythm is detected. Push-button controls include an ON/OFF button, three softkey buttons, and a SHOCK button. - Page 19 Overview (continued) Unit Video Display Screen (During AED Mode) Battery Indicator Rescue Breathing Options Softkey Icon Information Softkey Icon Main Screen Mode Select Softkey Icon Text Prompts (DDU-2450 only) Give 30 Compressions (sample display screen) Battery Indicator – The Battery Indicator indicates the approximate remaining battery capacity. Main Screen –...
-
Page 20: Preparation
Unit ECG Display Screen (During AED Mode, DDU-2450 only) Battery Indicator Main Screen Mode Select Softkey Icon Analyzing Text Prompts (sample display screen) Battery Indicator – The Battery Indicator indicates the approximate remaining battery capacity. Heart Rate Indicator – The Heart Rate Indicator displays the patient’s heart rate. Elapsed Time –... - Page 21 Selecting an Alternate Spoken Language Some AED models are factory configured to support an alternate spoken language. If the AED supports an alternate language, a Language Softkey Icon (represented in the form of a flag) will be displayed. When the Language Softkey Icon is present, the user may press the corresponding softkey to switch the spoken voice prompts to the alternate language.
- Page 22 Applying The Defibrillation Pads To The Patient Follow this procedure to apply the defibrillation pads to the patient: 1. Tear the defibrillation pads package along the dotted line near the top of the package. 2. Remove the pads from the package and follow the directions and diagram showing proper pad placement located on the pads package.
-
Page 23: Heart Rhythm Analysis
Follow DDU-2000 Series AED Instructions At this point, the DDU-2000 Series AED will check to make sure that the pads are well connected to the patient and that an adequate ECG signal is being received. Do not touch the patient. Eliminate any patient movement, and cease CPR at this time. If there is a problem with the pad connection, socket connection, patient motion, or other interference, the AED will guide the operator with both audible and displayed instructions. -
Page 24: Post-Use Procedures
4.6 Post-Use Procedures After the DDU-2000 Series AED has been used on a patient, the unit should be cleaned following procedures in the “Cleaning” section in Chapter 6 of this manual and prepared for the next use. The following steps should be performed: 1. - Page 25 Pad Connection/Pad Application-Related Prompts (continued) Voice Text “Peel adhesive pads from blue liner” Peel Pads Purpose: This instructs the user to peel each pad from the blue liner before placing the pads on the patient. Peel the pads from the blue liner only when the pad is ready to be placed. Place the pads with the sticky side of the pad on the patient’s bare skin.
- Page 26 Heart Rhythm Analysis Prompts Voice Text “Analyzing heart rhythm” Analyzing Rhythm “Analyzing” Analyzing Purpose: The DDU-2000 Series AED is actively analyzing the patient’s ECG signal. The AED will continue analyzing until it has determined whether a rhythm is shockable or non-shockable or if analyzing is interrupted for some reason. “Do not touch the patient”...
- Page 27 Shock-Related Prompts (continued) Voice Text “SHOCK button not pressed” Button Not Pressed Purpose: After shock is advised, the DDU-2000 Series AED will prompt user to press the flashing shock button. If after 30 seconds the shock button is not pressed, the AED will give this prompt and immediately go to CPR mode.
-
Page 28: Operational Environment
CPR Coaching Help Prompts Voice Text “Place hands” Place Hands Purpose: This reminds the user of the correct placement of hands for CPR. “Press” Press “Compress Chest” Compress Chest Purpose: This reminds the user to perform CPR compressions. “Tilt head back” Tilt Head Back “Pinch nose”... -
Page 29: Ecg Monitor Mode (Ddu-2450 Only)
ECG Monitor Mode (DDU-2450 only) At the discretion of emergency care personnel, the DDU-2450 AED can also be used with an optional ECG Monitoring Adapter (DAC-2020/2021) to provide a non-diagnostic ECG display of the patient’s heart rhythm for attended patient monitoring. -
Page 30: Monitoring The Patient
5.3 Monitoring The Patient After the ECG monitoring electrodes are connected, the defibrillator displays a non-diagnostic ECG of the patient’s heart rhythm and heart rate in a Lead II configuration. While in ECG Monitor Mode, the defibrillator’s shock capability is disabled; however, the defibrillator continues to evaluate the patient’s ECG for a potentially shockable rhythm. Monitoring Monitoring Monitoring... -
Page 31: Maintenance And Troubleshooting
Maintenance and Troubleshooting This chapter describes the maintenance and troubleshooting procedures for the DDU-2000 Series AED. The self- tests that are automatically performed by the device are described along with recommended routine maintenance. A troubleshooting guide is provided to help diagnose user serviceable problems. The DDU-2000 Series AED contains no user serviceable parts. - Page 32 Checking The AED Status Using The AED Status Screen You may also check the status of the unit when it is off by pressing the center softkey button to enter Maintenance Mode and display the AED Status Screen. The AED Status Screen shown at left is used to provide a quick overview of the DDU-2000 Series AED’s status and to display select information without turning the unit on in AED Mode.
- Page 33 Checking The Condition Of The Unit And Accessories Inspect the unit for dirt and contamination, especially in the pads connector socket and around the battery pack opening. (Refer to the “Cleaning” section in this chapter of this manual for guidance on cleaning your AED.) Inspect the unit display screen for damage.
- Page 34 Checking Pad And Battery Pack Expiration Dates It is important to check the expiration dates of the pads and battery pack. Both may be checked when the unit is off by pressing the center softkey button to display the AED Status Screen. (Refer to the “AED Status Screen” section in Chapter 7 of this manual.) The expiration dates can also be found on each item: the pads package expiration date is printed on the outside of the sealed package;...
-
Page 35: Self-Tests
6.2 Self-Tests The DDU-2000 Series AED provides for both automatic and manually initiated self-tests. These self-tests test various components of the AED, including the system controls, battery pack condition, charge/discharge functions, and measurement and signal acquisition functions. Automatic Unit Self-Tests Every time the unit is turned on, power-on self-tests are performed to test the basic operation of the unit. -
Page 36: Operator's Checklist
6.5 Operator’s Checklist The following checklist may be used as the basis for an Operator’s Checklist. The table should be copied and filled out as recommend by the schedule in the “Routine Unit Maintenance” section of this chapter. As each item is completed it should be checked off. -
Page 37: Troubleshooting
6.6 Troubleshooting The following table lists the symptoms, the possible causes, and the possible corrective actions for common problems. Refer to the other sections of the user manual for detailed explanations on how to implement the corrective actions. If the unit continues to be non-functional, refer the unit for servicing. (Refer to Chapter 13 of this manual for contact information.) Symptom Possible Cause... -
Page 38: Repair
Troubleshooting (continued) Symptom Possible Cause Corrective Action Make sure pads connector is oriented “ Pads missing” prompt Pads not connected to unit correctly and fully inserted into unit Pads connector not plugged in Plug in pads connector Pads connector broken Replace pads “... -
Page 39: Maintenance Mode
Maintenance Mode 7.1 Overview Maintenance Mode for the Defibtech DDU-2000 Series AED permits the user to perform maintenance-related actions such as viewing unit information, initiating unit self-tests, changing unit parameters, downloading rescue data, and upgrading software. Maintenance Mode is navigated through a series of screens, menus, and menu options. In Maintenance Mode, the softkey buttons located directly to the right of the display screen are used to scroll through and select menu options. -
Page 40: Entering Maintenance Mode
7.3 Entering Maintenance Mode Before You Begin: Make certain the DDU-2000 Series AED is turned off and a battery pack is installed. STEP 1 – Press and release the CENTER softkey button. Result – The unit will turn on and display the AED Status Screen for a AED status short period of time. -
Page 41: Aed Maintenance Screen
AED Maintenance Screen The AED maintenance screen allows the user to select such options as AED tests, software upgrades, data backups, and data card functions. Before you begin: Be sure the unit is in Maintenance Mode. To enter: Navigate to AED maintenance: AED Main Menu Ú... - Page 42 To enter: Navigate to Upgrade AED: AED Main Menu Ú AED maintenance Ú Upgrade AED What it does: If an upgrade data card is present, the unit will start performing the upgrade process. Follow any prompts and instructions that the upgrade application provides. Do not turn off the unit or remove the battery pack or data card until the operation is complete.
-
Page 43: Aed Options Screen
To enter: Navigate to Format data card: AED Main Menu Ú AED maintenance Ú Format data card What it does: The unit will format the DDC card that is inserted in the AED: The unit says: “Formatting data card” The unit displays: Formatting Data Card When unit finishes formatting the DDC card, the unit will return to the menu. - Page 44 What it does: The unit will display the AED options menu screen. This screen will allow the user to modify the following user changeable parameters: • System time • System date • Volume level • Audio recording • Status broadcast To exit: Using the TOP or BOTTOM softkey buttons, scroll to and highlight the selection.
- Page 45 The date is now set and the user may use TOP or BOTTOM softkey buttons to navigate to other choices in the menu. Note: The factory default setting of the internal AED clock is Universal Time (GMT). Volume Level The Volume level option allows the user to set AED audio output to high, medium, or low volume.
-
Page 46: Rescue Options Screen
Rescue Options Screen To manually configure rescue options such as Rescue protocol and CPR breathing, select the Rescue options from the AED Main Menu screen. Before you begin: Be sure the unit is in Maintenance Mode. To enter: Navigate to Rescue options: AED Main Menu Ú... - Page 47 Settings Before you begin: Be sure the unit is in Maintenance Mode. To enter: Navigate to Settings: AED Main Menu Ú Rescue options Ú Settings What it does: The Settings option allows the user to change the currently enabled protocol by entering a special protocol code.
-
Page 48: Help Topics Screen
Help Topics Screen The Help topics option on the AED Main Menu provides a list of available help topics. Before you begin: Be sure the unit is in Maintenance Mode. To enter: Navigate to Help topics: AED Main Menu Ú Help topics What it does: The Help topics provides a list of available help topics. -
Page 49: Ddu-2000 Series Aed Accessories
DDU-2000 Series AED Accessories This chapter describes the component parts and accessories that can be used with the Defibtech DDU-2000 Series AED. For contact information on obtaining replacement component parts and accessories, refer to Chapter 13 in this manual. For more information about accessories, please visit www.defibtech.com or contact Defibtech or your distributor. -
Page 50: Usb Cable
8.5 USB Cable An optional USB cable may be used with the DDU-2000 Series AED for connecting the AED to a personal computer running Defibtech maintenance software. The AED has a mini-USB connector located on the right side of the unit behind the data card/USB port access door. -
Page 51: Event Viewing
Event Viewing This chapter includes information about DefibView, Defibtech Data Cards (DDC cards), and downloading internal data logs. 9.1 DefibView DefibView is a Windows-based software application that reads data stored on a DDC card or downloaded through the USB port and displays the data on a personal computer. DefibView serves the following primary functions: •... -
Page 52: Technical Specifications
Technical Specifications 10.1 Defibtech DDU-2000 Series AED General Category Specification Size 7 .3 x 9.5 x 2.3 inches (18.5 x 24 x 5.8 cm) Weight Less than 3 lbs (1.4 kg) (with battery) Power Battery Pack (not rechargeable) Meets applicable requirements of •... - Page 53 Defibtech DDU-2000 Series AED (continued) Defibrillator – ECG Mode (DDU-2450 only) Category Specification ECG information is received from defibrillation pads in anterior-lateral or Displayed ECG anterior-posterior positions, or from the 3-wire ECG Monitor Adapter in Lead II Screen type TFT Color LCD with backlight (53.6mm x 71.5mm) (320 x 240 pixels) Displayed Range Differential: +/- 2 mV full-scale...
- Page 54 Defibtech DDU-2000 Series AED (continued) Waveform Specifications The DDU-2000 Series AED delivers a 150 J (Adult) 50 J (Pediatric) Biphasic Truncated Exponential waveform (AED Mode) to patients with impedances ranging from 25 to 180 ohms. V max V min The waveform is adjusted to compensate for measured patient impedance. Nominal phase times and energy delivered are shown in the tables below.
- Page 55 Defibtech DDU-2000 Series AED (continued) Environmental Category Specification Temperature 0 – 50°C (32 – 122°F) Humidity 5% – 95% (non-condensing) Operating/ One Hour Operating Maintenance Temperature Limit -20°C (-4°F) (extreme cold)* Air Pressure 700 to 1060 hPa (21 to 31 inHg) Temperature 0 –...
- Page 56 Defibtech DDU-2000 Series AED (continued) Shockable Rhythm Criteria When placed on a patient meeting the indications for use criteria, the DDU-2000 Series AED is designed to recommend a defibrillation shock when it detects proper pad impedance and one of the following: Ventricular Fibrillation: Peak-to-peak amplitude at least 200 µVolts.
-
Page 57: Battery Packs
10.2 Battery Packs Use only Defibtech battery packs in the DDU-2000 Series AED. DBP-2003 and DBP-2013 Battery Packs Category Specification DBP-2003 Model number DBP-2013 (Aviation;TSO C-142a) 12VDC, 2800 mAh, Lithium/Manganese Dioxide. Main battery type Disposable, recyclable, non-rechargeable. Capacity 125 shocks or 8 hours of continuous operation. * Charge time 4 seconds or less (from shock advised)* Standby-life (installed in unit) -
Page 58: Event Documentation
10.5 Event Documentation Internal Event Record Select ECG segments and rescue event parameters are recorded and can be downloaded to a removable data card. Removable Storage (optional) Up to 30 hours of ECG and event data storage (no audio option) or up to 3 hours of audio (audio option). ECG and event storage on a removable data card. -
Page 59: Electromagnetic Conformity
Electromagnetic Conformity 11.1 Guidance And Manufacturer’s Declaration The essential performance of the DDU-2000 Series AED is successful delivery of defibrillation therapy and accurate differentiation between shockable and nonshockable rhythms. DDU-2000 Series AEDs are intended for use within the electromagnetic environment specified below. The customer or the user of the DDU-2000 Series AED should assure that it is used within the stated environmental specifications. - Page 60 Electromagnetic Immunity (continued) IEC 60601 Compliance Electromagnetic environment – Immunity test test level level guidance Portable and mobile RF communications equipment should be used no closer to any part of the DDU-2000 Series, including cables, 20 V/m than necessary. The recommended 80 MHz to separation distance calculated Radiated RF...
-
Page 61: Regulatory Compliance
Separation Distances (continued) For transmitters rated at a maximum output power not listed above, the recommended separation distance (d) in meters (m) can be determined using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer. -
Page 62: Glossary Of Symbols
Glossary Of Symbols Symbol Meaning High voltage present. SHOCK Button – Delivers defibrillation shock to the patient when the device is ready to shock. ON/OFF Button • Turns the device ON when it is OFF . • Turns the device OFF when it is ON. Caution, consult accompanying documents. - Page 63 Glossary Of Symbols (continued) Glossary Of Symbols (continued) Symbol Meaning Defibrillation proof - Can withstand the effects of an externally applied defibrillation shock. Internally powered with defibrillator-proof BF-type patient applied parts (per EN 60601-1). Manufacturer. Y YY Y-MM-DD Y Y Y Y- MM -D D Y Y Y Y Y Y Y Y Date of manufacture.
-
Page 64: Contacts
Contacts Manufacturer Defibtech, L.L.C. 741 Boston Post Road, Suite 201 Guilford, CT 06437 USA Y Y Y Y- MM -D D Y Y Y Y- MM -D D Tel.: 1-(866) 333-4241 (Toll-free within North America) 1-(203) 453-4507 Fax: 1-(203) 453-6657 Email: sales@defibtech.com (Sales)
