  • Page 1 Instruction Manual...

  • Page 2: Table Of Contents

    Introduction • Thank you for choosing Quadrone! This is a four-axis aircraft that can fly outdoors, in order to make it easier to control the aircraft. Please carefully read this manual before operating your Quadrone. Please keep this manual for future reference.

  • Page 3: Warning

    • If this is your first time flying a quadcopter read the manual carefully. Seek the help of an experienced pilot to help you fly. These safety instructions are intended not only for the protection of your Quadrone but also to protect your own safety. Improper operation can cause injury or property damage.

  • Page 4: Included

    Ni-Cad and Alkaline batteries. • Make sure the batteries are installed correctly to ensure correct polarity. If you do not plan to use your Quadrone for an extended period of time, remove the batteries from the controller to avoid battery leakage which may damage the controller.

  • Page 5: Quadrone Diagram

    Quadrone Diagram Blade Motor Receiver Canopy Board Main Frame Remote Controller Diagram Backward Aileron Left Trim Button Trim Button Forward Aileron Right Trim Button Trim Button Throttle Directional Joystick Joystick Left Turning Fast/Slow Trim Button Speed Button Flips Battery Right Turning...

  • Page 6: Charging Your Drone

    Quadrone. The Quadrone is now charging. A red light will turn on on the USB charger indicating the charging process has completed. Always charge your Quadrone under adult supervision and out of the reach of children. Battery and Charger Specifications Battery Battery Type...

  • Page 7: Flight Controls

    • If you are not going to use your Quadrone for an extended period of time, please take out the batteries in your remote controller. Potential battery leakage could occur and possibly damage the remote or create a fire hazard.

  • Page 8: Practice Tips

    Narrow the circle as your skills progress. Trimming the Quad • If your Quadrone is leaning to or favoring a side, you may need to use the trim feature to balance it out so it flies straight. Turning...

  • Page 9: Flips And Rolls

    Move the directional joystick in any direction and the aircraft will perform a coinciding flip. Speed Selection • Your Quadrone can fly at three speeds. To select a speed, press the F/S button on your remote. Your remote will beep each time you switch speeds.

  • Page 10: Changing The Blades

    Changing the Blades • If a blade breaks or falls off your Quadrone during a crash, it will be up to you to repair it. Simply push one of the extra blades onto the exposed motor. It is important for the correct blade to be put on the correct motor or the drone will not fly correctly.

  • Page 11: Safety Guidelines

    Safety Guidelines • Follow community-based safety guidelines, as developed by organizations such as the Academy of Model Aeronautics (AMA). • Fly no higher than 400 feet and remain below any surrounding obstacles when possible. • Keep your drone in eyesight at all times, and use an observer to assist if needed.

  • Page 12: Limited 90-Day Warranty

    Limited 90-Day Warranty DGL Group, Ltd. warrants to the original consumer that this product is free from any electrical or mechanical defects for a period or 90 DAYS from the date of purchase. If any such defect is discovered within the warranty period, DGL Group, Ltd.

  • Page 13: Fcc Statement

    Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 14 WARNING: FCC ID: XXXXXXXXXXXX CHOKING HAZARD-Small parts. Not for children under 3 years. DGL TOYS™ is an innovative division of DGL Group, Ltd. Other trademarks and trade names are those of their respective owners. Tested to comply with FCC standards. FOR HOME OR OFFICE USE.
