Summary of Contents for Hyundai HWC-M100
-
Page 1: User Manual
RF Data Modem HWC-M100 HWC-W100 HWC-W120 User Manual... -
Page 2: Table Of Contents
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 Table of Contents 1. Overview 1.1 Features ㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 1.2 Accessories ㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 1.3 Product Description ㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 2. Installation the device 2.1 Network configuration ㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 2.2 Configure the Setting of RF-Master(HWC-M100) ㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ 2.3 Configure the Setting of RF-Modem(HWC-W100) ㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍㆍ... -
Page 3: Overview
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 1. Overview 1.1 Features ∎ A license and qualification of application of the radio station are unnecessary. ∎ RF Range - Indoor/Urban up to 75m(depending on environment) - Outdoor(line-of-sight) up to 300m ∎... - Page 4 ∎ Serial communication type can be selected in RS-232,RS-422 and RS-485 through GUI - HWC-W100 and HWC-W120 ∎ Supply Voltage : DC 24V(Input Range : DC 8V ~ DC 32V) (HWC-M100, HWC-W100, HWC-W120) ∎ Operating Temperature : -30°C ~ 80°C (HWC-M100, HWC-W100, HWC-W120) ∎...
-
Page 5: Accessories
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 1.2 Accessories ∎ RF Master(HWC-M100) ∎ RF Modem(HWC-W100) ∎ RF Master(HWC-W120) -
Page 6: Product Description
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 1.3 Product Description ∎ RF Master(HWC-M100) - Page 7 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ① Debug - Connecting PC or Notebook to debug port, you can set control data and see the operating status of device. ② Indicator - Indicate the operation status of device, visually.
- Page 8 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ∎ RF Modem(HWC-W100)
- Page 9 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ① Debug - Connecting PC or Notebook to debug port, you can configure parameter of modem and see the operation status of the device. ② Configuration S/W - You can use this switch to configure nework-ID, devide-ID, communication-type and so ③...
- Page 10 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ∎ RF Modem(HWC-W120)
- Page 11 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ① Debug - Connecting PC or Notebook to debug port, you can set control data and see the operating status of device. ② Indicator - Indicate the operation status of device, visually.
-
Page 12: Installation The Device
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 2. Installation the device 2.1 Network configuration... - Page 13 ∎ The network consists of one RF-Master(HWC-M100) and several AP(Access Point)/EP(End Point) ∎ You can set AP(Access Point) or EP(End Point) mode of RF Master(HWC-M100) using configuration-Switch. ∎ Communication between HOST and RF-Master can be implemented in public or private network.
-
Page 14: Configure The Setting Of Rf-Master(Hwc-M100)
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 2.2 Configure the Setting of RF-Master(HWC-M100) < Front View > < Rear View > ∎ DEBUG : You can configure RF-Master through the debug-port using special GUI in PC or notebook. The debug-port supports RS-232C interface(57600 bsp, 8 bit data, None parity, 1stop). - Page 15 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 - UP-LINK : IP Address, Subnet Mask, Gateway Address, MAC Address (MAC Address is assigned when RF-Master is producted. If RF-Master has no MAC address, you can re-assign by the address printed on sticker that attached on PCB.) - LOCAL-LINK : You don't need to set Ethernet network parameter for AP.
-
Page 16: Configure The Setting Of Rf-Modem(Hwc-W100)
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 2.3 Configure the Setting of RF-Modem(HWC-W100) < Front View > < Rear View > ∎ You can configure Net-ID, Device-ID and Mode of RF-Modem using switches. And you can confirm the configuration information in special GUI. The debug-port supports RS-232C interface(57600 bsp, 8 bit data, None parity, 1stop). - Page 17 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 - NET-ID : Network Number. Each network has its own unique frequency band. and you can select one of the 16 network.(Net.ID : 0~15) - DEVICE-ID : Device-ID of the EP. Each EP has its own unique number in a network.
- Page 18 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ∎ Frequency Table according to setting of NET-ID is as following: NET ID Frequency NET ID Frequency 2,405 MHz 2,445 MHz 2,410 MHz 2,450 MHz 2,415 MHz 2,455 MHz 2,420 MHz 2,460 MHz...
- Page 19 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 ∎ In AP-mode, you need to set Net-ID, Device-ID, AP/EP-Mode as follows: - NET-ID : Network Number. Each network has its own unique frequency band. and you can select one of the 16 network.(Net.ID : 0~15) - DEVICE-ID : Device-ID of the AP.
- Page 20 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 < AP Information Window in GUI > < EP Information Window in GUI >...
-
Page 21: Configure The Setting Of Rf-Modem(Hwc-W120)
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 2.4 Configure the Setting of RF-Modem(HWC-W120) ∎ You can configuration NET-ID, DEVICE ID, MODE by Rotary Swtich - NET-ID : Network Number. Each network has its own unique frequency band. and you can select one of the 16 network.(Net.ID : 0~15) - DEVICE-ID : Each HWC-W120 has its own unique number in a network.(Device-ID : 0~19) - Page 22 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 coverage of each network and Number of EP is same as the number of End-Device that you want to use in each network. ∎ You can use Serial port to connect with End-Device. Assignment of pin is differnet...
-
Page 23: Communication With Host
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 3. Communication with HOST 3.1 Communication method ∎ You can use Up-Link connector of RF Master to communicate with HOST through ethernet. HOST must know the IP address and udp port of RF Master. Udp port is fixed to 9506. -
Page 24: Communication With The End Device
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 4. Communication with the End Device 4.1 Communication Method ∎ You can use Up-Link connector of RF-Modem to communicate with HOST through ethernet. HOST must know the IP address and udp port of RF Master. Udp port is fixed to 9506. -
Page 25: Quick Start For Gui
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5. Quick Start for GUI 5.1 Initial Screen after Execution When you execute the GUI program, the following screen is shown up. (In case of showing message about the setting of program, please refer to "5.11 Configure the setting of communication with device"! ) - Page 26 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 you can see AP.0/EP.0 by pressing 'F5'Key. It could be different with real device list, and This is the function that you can see device information without Master.
-
Page 27: Network Configuration
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.2 Network Configuration User must request device list of network after execution of GUI.(Refer to "5.1 Initial Screen after Execution"). The following is explanation about result of request. At first, user must watch the left window. After requeset the network configuratin, It shows Master, APs and EPs. -
Page 28: Status And Control Of Master
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.3 Status and Control of Master In upper screen, please confirm whether the "state/control" is selected. (If "status/control" is not selected, click the tab of "status/control") The following is the status information of Master. -
Page 29: Status And Control Of Ap
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.4 Status and control of AP After selecting AP in device list, please confirm whether the "state/control" is selected (If "status/control" is not selected, click the tab of "status/control") The following is the status information of AP. -
Page 30: Status And Control Of Ep
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.5 Status and Control of EP After selecting EP in device list, please confirm whether the "state/control" is selected (If "status/control" is not selected, click the tab of "status/control") The following is the status information of EP. -
Page 31: Rssi Graph
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.6 RSSI Graph The Graph of RSSI visualizes the received signal strength between the installed AP and the selected EP. When it tries to determine whether the installation position of APs is appropriate or not, it will be useful. -
Page 32: Store The Rssi Data
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.7 Store the RSSI Data RSSI drawn on the graph is expressed in the list(Red box) as the numeric value. This data can be stored as a file. And the stored file is retrieved and the RSSI graph can be drawn again. - Page 33 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.8 CH RSSI The CH-RSSI is the RSSI value of the radio channel. It shows whether the channel is already occupied or not. that is, function to search the available channel without the cross talk.
-
Page 34: Ep Communication Count
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.9 EP Communication Count "EP Communication Count" is the function in which we know whether the communication state with each EP is good or not. The following is the usage： ∎ Request Status of Communication : It require the number of transmission and reception It shows the rate of communication success. -
Page 35: Download
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.10 Download This is the function that upgrade the firmware of the device The following is the usage : 1. Select the device that is to be upgraded in the left list. -
Page 36: Configure The Setting Of Communication With Device
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 5.11 Configure the setting of communication with device In spite of executing the program after connecting the device with PC, If it is not communicated, The configuration of communication has to be confirmed. -
Page 37: Others
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 When there is an error related to the setting of communication after executing the GUI program, the communication status window is automatically pop up. In this case, please confirm the communication configuration again! The error is in following case : ∎... -
Page 38: Dimension
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 6. Dimension 6.1 RF Master(HWC-M100) ∎ TOP VIEW ∎ FRONT VIEW ∎ REAR VIEW... -
Page 39: Rf Modem(Hwc-W100)
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 6.2 RF Modem(HWC-W100) ∎ TOP VIEW ∎ FRONT VIEW ∎ REAR VIEW... -
Page 40: Rf Modem(Hwc-W120)
RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 6.3 RF Modem(HWC-W120) ∎ TOP VIEW ∎ FRONT VIEW ∎ REAR VIEW... - Page 41 RF Data Modem HWC-M100 / HWC-W100 / HWC-W120 [ A/S CENTER ] 806 Ace Techno Tower 1st. 197-17 Guro3-Dong, Guro-Gu, Seoul, Korea Tel. +82-2-3281-9300 Fax. +82-2-3281-7775 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 42 WARRANTY Warranty is to cover the operating defaults after the purchase during the warranty period.(12 months after the purchase). Please notify us the defaults for repairs with short description of the defaults confirming the information of person in charge. The demages(defaults) prescribed below are NOT to be covered by warranty.
