Ecco Pacific 111 Operating Instructions

OPERATING INSTRUCTIONS

MODEL: 111
INFRARED THERMOMETER
WITH LASER SIGHTING
INTRODUCTION
This instrument is a portable easy to use 3½digit, com-
pact-sized digital infrared thermometer with laser sighting
designed for simple one hand operation. Meter comes with
backlight LCD display, Auto-Hold function and Auto
Power Off (10 seconds approx.) to extend battery life.

SAFETY INFORMATION

It is recommended that users read the safety and opera-
tion instructions before using the infrared thermometer.
DANGER
When sign appears, pull the trigger to turn the laser
beam on and off.
Be very cautious with the laser beam, not aiming your
eyes or those of any other person or animal.
● Do not look directly into the laser light from the opti-
cal system.
● When measuring the temperature of an object which
has a mirror finish, be careful not to allow the laser
light beam to be reflected off the surface into your
eyes or those of another person.
● Do not allow the laser light beam to impinge upon any
gas which can explode.
Customer Care Australia P: 13122 F: 1300 303 310 E: sales@cabac.com.au W:cabac.com.au
A: Distribution Pl, Seven Hills NSW 2147
Customer Care New Zealand P: 0800 966 969 F: 0088 6969 E: sales@cabac.co.nz W: cabac.co.nz
CAUTION
● Do not use the unit near any device which generates
strong electromagnetic radiation or near a static elec-
trical charge, as these may cause errors.
● Do not use the unit where it may be exposed to corro-
sive or explosive gases. The unit may be damaged, or
explosion may occur.
● Do not keep or use this unit in an environment where
it will be directly illuminated by sunshine, or where it
condensation. If you do, it may be deformed, its insu-
lation may be damaged, or it may no longer function
according to specification.
● Do not place the meter on or around hot objects
(70°C/158°F). It may cause damage to the case.
● If the meter is exposed to significant changes in ambi-
ent temperature (hot to cold or cold to hot). Allow 30
minutes for temperature stabilization, before taking
measurement.
● Condensation may form on the sensor when going
from a cold to hot environment-wait 10 minutes for
condensation to dissipate before taking measurements.
● This unit is not constructed to be waterproof or dust
proof, so do not use it in a very dusty environment or
in one where it will get wet.
● Do not point the lens at the sun or at any other
source of strong light. If you do, the sensor may be
damaged.
● Do not contact the lens against the object whose
temperature is to be measured, or get it dirty, allow
it to be scratched, or allow any foreign material to
adhere to it. Doing so may cause errors.
● Do not touch or hold by the front case. Tempera-
ture reading can be affected by heat from hand.
● Readings may be affected if the unit is operated
within a radio frequency electromagnetic field
strength of approximately 9 volts per meter, but
the performance of the instrument will not be per-
manently affected.
SPECIF
GENERAL
Display: 3½ d
mum readin
Low battery
battery volt
Measuremen
Operating En
< 70% R.H
Storage Tem
to 80% R.H
Auto power o
Standby cons
Battery: Stan
006P).
Battery Life:
Dimensions: 1
Weight: appro
Laser Speci
Laser safety c
Wave Length
Power out: <1
ELECTRIC
Temperature
Display Resol
Accuracy:
±(2°C/4°F)
±(2% readin
Temperature
±0.2% of
greater, cha
operating t
64.4°F/18°C
Response Tim
Spectral Resp
Adjustable em
Detection Ele
Optical Lens:
Sighting: 1-be
Field of View
Spot size increa
(Spot Diamete
