POSTURITE
DeskRite 100
Set-up Guide
CAUTION
!
Please read all instructions carefully before using this product.
Retain this manual for future reference.
The specifications of this product may vary slightly from the
illustrations and are subject to change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DeskRite 100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Posturite DeskRite 100

  • Page 1 POSTURITE DeskRite 100 Set-up Guide CAUTION Please read all instructions carefully before using this product. Retain this manual for future reference. The specifications of this product may vary slightly from the illustrations and are subject to change without notice.

  • Page 2: Technical Data

    Technical Data Colours available 2 colours Black/White Product dimensions (flat) WxDxH 890 x 600 x 120 mm 35 x 24 x 4 ins Lift range (top surface) 120-500 mm 5-20 ins Height adjustment levels Minimum desktop/table surface required (WxD) 900 x 610 mm 36 x 24 ins Keyboard tray range 100 mm...
  • Page 3 Using two people, carefully remove the DeskRite 100 Platform from the packaging. Carefully place on a suitable size desk/table surface. Make sure the DeskRite 100 feet do not overhang desk/table surface. Once in place, carefully remove the retaining strap. CAUTION...
  • Page 4 Operation Height Adjustment Grip the adjusting handles on each side of the DeskRite 100 and the workstation top surface together and slowly lift to adjust the surface to your desired height. 1. The top line of your screen(s) should be at eye level.
  • Page 5 Devices Carefully place your devices on top of the DeskRite 100 workstation platform. Make sure the devices do not overhang the back of the platform surface. Do not exceed the maximum weight limit of 18kg/40Ibs. Operationally adjustable to 18kg / 40Ibs Torque Adjustment Manually adjust the torque controller to a suitable tension.
  • Page 6 100mm / 4ins Cable Management System When the DeskRite 100 is raised up, the keyboard and mouse cables can be carefully inserted into the cable management system found on the underside surface. This helps avoid the cables potentially being trapped when raising and lowering the DeskRite 100.
  • Page 7 • Failure to follow these instructions may result in serious personal injury. Limited warranty The Deskrite 100 is guaranteed free of defects in material and workmanship for a period of 18 months from date of purchase. This warranty does not cover product abuse, improper operations, and/or misuse.
  • Page 8 MoovRite DocuRite TriRite Rocking standing platform Adjustable document holder Multi position footrest and footrest For USA For rest of the world Contact Posture Depot Contact Posturite info@posturedepot.com info@posturite.co.uk (+001) 704-999-0809 (+44) 345 345 0010 www.posturite.co.uk...
