HDMI Tree Chain Extender User Manual Ⅰ. Introduction Ⅱ. Product Ⅲ. System Structure Ⅳ. RS-232 Control Ⅴ. Specification... - Page 2 Furthermore, the patent for lossless image compression algorithm contributes to superb image quality for HD PC signal transmission. Ⅱ. Product Transmitter HD-308T-Tree IR Emitter：IR Emitter RS-232：RS-232 control port connected to PC HDMI In：HDMI AV input port Out：System connection port (output) DC 5V：Power port (DV5V/2A)
- Page 3 Ⅲ. System Structure Transmitter RS-232 Control HDMI AV HD-308T-Tre Repeater/Receiver HD-308R-Tr Max. 100m Max. 100m Repeater/Receiver Repeater/Receiver HD-308R-Tr HD-308R-Tr Max. 100m Max. 100m Max. 100m Max. 100m Repeater/Receiver Repeater/Receiver Repeater/Receiver Repeater/Receiver HD-308R-Tr HD-308R-Tr HD-308R-Tr HD-308R-Tr [Tree Chain] Each Receiver supports 2 output ports of system connection. Max.
- Page 4 Transmitter HDMI AV RS-232 Control HD-308T-Tre Repeater/Receiver HD-308R-Tr Max. 100m Repeater/Receiver HD-308R-Tr Max. 100m Repeater/Receiver HD-308R-Tr Repeater/Receiver HD-308R-Tr [Daisy Chain] If each Receiver connects only 1 output port of system connection Max. 100m between system connections. Tree Chain Configuration：Under 31 displays Daisy Chain Depth：31 levels, total 31 Receivers...
-
Page 5: Command List
Ⅳ. RS-232 Control 1. Interface：RS-232 2. Protocol：9600,N,8,1 3. HDMI Tree Chain Extender adopts ASCII, supporting RS-232 command of 32Bytes. 4. Command function includes Full Control and Access Control. 5. Command List： (1) Full Control- Command Format：[B] [baud rate] [data1][data2][data3]…… [data32] ASCII →... - Page 6 Support RS232-Over-CAT5 Broadcast / Selected Point-to-Point Mode Support Universal IR-Over-CAT5 Daisy/Tree Chain Specification Tree Chain Configuration：Under 100 displays Daisy Chain Depth：31 Clients (31 displays) Distance Spec.：Each point to point 100m Other Specification Voltage：5V @ 1.5A max Power Consumption：< 5 Watts www.sinew.com.tw...
