OPEN HYBRID MEM ErP
INSTALLATION AND MAINTENANCE MANUAL
EN
Dear Customer,
Thank you for purchasing an Open Hybrid MEM ErP system, a last generation appliance, with all the technical and performance
features to satisfy your needs for heating and the supply of domestic hot water, in maximum safety and with low running costs.
We recommend that your new appliance is started up within 30 days from the date of installation by qualified technicians,
so that you can benefit from both the legal warranty and the conventional warranty provided by Sime which is to be found
at the end of this manual.
Fonderie SIME S.p.A.
6322912 - 03/2016 - R3
