Page 1: Table Of Contents
Replacing the fuse Speci cations Trouble Shooting Thank you for purchasing MaSSC Clean Photocatalyst Air Purifier (MC-CA1). Before initial use, please read the operating instructions carefully to ensure proper use of the unit. Please pay attention to《Safety Precautions》before using this product.
Page 2 Actual disinfecting and deodorizing e ectiveness will vary according to the room conditions (Capacity of the room, shape, air conditioning, ventilation and product location, etc.) or the operation method. MaSSC(MC-CA1)Experimental Results The decomposition and deodorizing effect to Elimination effect to influenza virus...
Page 3: Faq (Frequently Asked Question)
(Frequently Asked Question) The unit does not work properly. Is the car adapter connected properly? Please be connected definitely. (See P.8) Have you checked if the fuse has blown? Replace with a new fuse. (See P.11) The indicator light is turned on in red and flickered. The unit has failed.
Page 4: Safety Precautions
Safety Precautions ■ Failure to heed the operating instructions will result in the following situation: May result in severe May result in injury or Warning Caution injury or death material damage To reduce the risk of electric shock, fire or injury ■...
Page 5 Please follow instructions carefully To protect from injury or damage, safety precautions should be followed, including: ■ The following pictograph intends to alert and explain you the safety precautions D O N ' T D O ' S Do not spill beverages or drop cigarette ashes, metal objects, burnable objects, ■...
Page 6 Safety Precautions ( C o n t ' ) Warning To reduce the risk of electric shock, fire or injury If the cigar lighter socket is integrated into the ashtray, be sure ■ that cigarettes are completely put out before using. When leaving the vehicle, unplug the cigar plug and close the ashtray's lid.(Failure to do so could lead to fire caused by the smoldering cigarettes.)
Page 7: Parts Name
Parts Name Main unit • Control panel/ Display Air Outlet Normal Clean Filter Error Filter reset Press & hold ON/OFF button ON OFF Operation Light Operation Button Green: under normal operation Orange: Clean the filter (The light turns on after operating for 720 hours) Red: The unit has failed.
Page 8: Getting Started
Getting started Connecting the car adapter and unit Connect the car adapter to the back of the unit ■Bottom view Route the cord along the groove Insert the cigar plug into the cigar lighter sock...
Page 9 Cautions on wiring the car adapter Do not let the cord touch or get caught in the seat rails, shift lever or other moving parts. Do not wire to impede the driving. Consider the moving range of the seats (forward/backward, swiveling or reclining) when wiring.
Page 10: Operating Method
Operating Method Normal Clean Filter Error Easy operation by pressing Filter reset the operation button Press & hold ON/OFF button Press the operation button. ON OFF The green light indicates that the unit is under normal operation. Cleaning and maintenance Be sure to unplug the cigar plug from the Warning cigar lighter socket when cleaning.
Page 11: Replacing The Fuse
Replacing the fuse Turn the tip of the cigar plug and remove it 12V/5A glass tube fuse Insert the new fuse, and then reassemble as before. Specifications Model MC-CA1 Rated voltage DC 12V Applicable Volume Approx 3.6m (Space corresponding to a cabin) Power consumption 9.0W...
Page 12: Trouble Shooting
T r o u b l e s h o o t i n g Reference S it uation P lease con firm Page Is the car adapter connected properly? →Please be connected definitely. The unit does not work properly. Have you checked if the fuse has blown? →Replace with a new fuse.
