INSTRUCTION MANUAL
░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░
AC TYPE SPOT WELDING MACHINE
AC TYPE WELDER CONTROL SYSTEM TSA-500
AC TYPE WELDER TRANSFORMER TST-5T(10T)
Room 1509, Seongsoo Academy Tower, 277-17 Seongsoo-Dong 2-Ka,
E-mail :
PLEASE READ THIS MANUAL BEFORE OPERATION OF WELDING MACHINE.
Model : TSA-500
Battery Specialist -------------------------------------------
JEONGWOOD TRADING
Seongdong-Ku, Seoul, Korea.
Tel : 82-2-3436-1212
jeonguj@empal.com
URL :
http://www.jeongwood.co.kr
CORP.
Fax : 82-2-3436-1279
uj@jeongwood.co.kr
Advertisement
Summary of Contents for JEONGWOOD TSA-500
- Page 1 ░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░ INSTRUCTION MANUAL ░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░ AC TYPE SPOT WELDING MACHINE Model : TSA-500 AC TYPE WELDER CONTROL SYSTEM TSA-500 AC TYPE WELDER TRANSFORMER TST-5T(10T) Battery Specialist ------------------------------------------- JEONGWOOD TRADING CORP. Room 1509, Seongsoo Academy Tower, 277-17 Seongsoo-Dong 2-Ka, Seongdong-Ku, Seoul, Korea.
-
Page 2: Specification
5) It provides welding counter. 2. Specification 1) Name of equipment : Resistance welding controller and power supply (transformer). 2) Model : Welding controller : TSA-500 Welding transformer : TST-5T 3) Input voltage : AC 220V/380V, +10%, -20% 4) Frequency : 50/60Hz... - Page 3 10 years under no electricity or no use 17. Detection of thyristor overheat(Transformer overheat) : Flicker to stop operation. 18. Welding counter range : 0 ~ 9999 19. Dimension : TSA-500 : 260mm(D) x 145mm(W) x 215mm(H) TST-5T/10T : 260mm(D) x 160mm(W) x 215mm(H) - 3 -...
- Page 4 3. Setting method of TSA-500 Spot Welding Machine 1. Turn “on” power and push “PGM” key. 2. When lamp is on at “SQEZ” and “≃”, use “⇧” and “⇩” key to set figure into “0” 3. When “UPSL” lamp is on by push “⇨” key, use “⇧”...
- Page 5 16. If welding result is not so strong, push “PGM” key and “SIN” key. When “%” and “HEAT1” lamp are on, increase previously set figure “40” into “45”. 17. Push “RUN” key and proceed welding by press of foot pedal. 18.
- Page 6 4. Front Panel of Power Supply - 6 -...
- Page 7 5. Circuit Block Diagram of Back Panel - 7 -...
- Page 8 - 8 -...
- Page 9 TSA-500 Spot Welding Machine Pictures - 9 -...
- Page 10 Wiring View of TSA-500 Spot Welding Machine - 10 -...
- Page 11 TSA-500 Spot Welding Machine Wiring Diagram - 11 -...
- Page 12 This is further technical information about TSA-500 AC type Spot Welding Machine and there are two methods to control weld current by SCR and/or voltage selector. A) Voltage Select Switch at Weld Transformer To increase weld power, it is required to change voltage select switch from level 1 to level 4 at weld transformer.
- Page 13 5) In order to weld 0.2 – 0.3mm(T) material, please see as below. SQEZ ≒ 3 : Start to weld after 48ms UPSL ≒ 1 : Current increasing in 16ms HEAT1 ≒ 30 : 30% output in 2 CYCLE(32ms) COOL ≒ 1 : Cooling in 16ms HEAT2 ≒...
