Summary of Contents for Blankom 5161.20
- Page 1 ...setting signals Device Manual LANIOS-RCL Ethernet switch 8-fold Ethernet switch with remote connection Part no. 5161.20 5161.21...
-
Page 3: Table Of Contents
Contents 1. Savety and operating instructions ........................4 2. Device variants ...............................4 3. Software options ............................4 General ................................4 5. Explanation of the operating elements ......................5 5.1 Front view ..............................5 5.2 Top view ...............................5 6. Functional description ............................5 7. Meaning of the LEDs ............................6 7.1 LEDs at the 10/100 Mbit ports ........................6... -
Page 4: Savety And Operating Instructions
The LANIOS-RCL is the 8-fold Ethernet switch with remote connection created for the SBL system. The integrated modem supports the communication via LTE, UMTS and GSM/ GPRS. LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 5: Explanation Of The Operating Elements
5. Explanation of the operating elements 5.1 Front view 5161.20 5161.21 Port 1 ... 4 LTE antenna connection „AUX“ Power connectors (loop through) LED‘s "POWER" & "REMOTE ACCESS" Port 5 ... 8 LTE antenna connection "MAIN" Button "(P)RESET", "REMOTE ON/OFF"... -
Page 6: Meaning Of The Leds
POWER yellow constant module is in standby module is off, operating voltage is not applied green constant active REMOTE connection REMOTE ACCESS none REMOTE connection LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 7: Settings By Web Interface
8. Settings by web interface To use all functions of the module activate Java Script in your browser settings. Settings via checkbox are applied immediatelly, but not stored in memory! So they would be lost on a possible restart of the module. To save these settings the “send“ button must be pressed. Please send and store your settings by pressing the ”send“... -
Page 8: Setting Of Individual Parameters
In all menus it‘s possible to switch the language between German and English on the top right. LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 9: Menu "Rcl Home
8.2.1 Menu ”RCL Home” The opening page gives a status overview of the LANIOS- RCL. Displayed are the IP address of the module (assigned by your internet provider), the online staus, the level in dBm and, if a VPN connection is enabled, the assigned IP address. -
Page 10: Menu "Port Forwarding
IP address (LANIOS-RCL):port. example: if the IP address of the LANIOS-RCL (»chapter 8.1) is 192.168.232.110, you reach the local module with the call http://192.168.232.110:8080. LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 11: Menu "Vpn Client
LANIOS-RCL are connected via wireless network and thus ensures an access from the PC to the module / headend. Blankom recommends to set up the LANIOS-RCL on the PC as a client and the other one as a server. Alternatively, the RS 232 tunnels can be realized with one LANIOS-RCL. This requires a virtual serial port on the PC, which then connects the LANIOS-RCL via TCP. -
Page 12: Menu "Status
BLANKOM homepage where the latest software release is available. Also the currently installed software release is displayed. LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 13: Menu "Setup
8.2.8 Menu ”Setup” In this menu, various administrative and system settings are made. The following can be configured: Graphical User Interface: GUI settings › Help info within the status line of the browser By default, the online help is displayed in an orange colored text box at the bottom of the page. - Page 14 If operations have been executed, the logged on user, who initiated the action, is saved too. By pressing of the “Erase“ button all entries are deleted (only possible by the administrator). LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch...
- Page 15 System Location rename the module Logout restart the user interface Default reset the module to factory default Reboot restart the module The name in ”Location“ is displayed on the top right of the website, below the language selection box. It is provided via SNMP: iso(1).org(3).dod(6).internet(1).mgmt(2).mib-2(1).
- Page 16 The headend can now be stored in the Setup→System administration. By selecting the respective modules link in the headend overview, you can switch to the other modules user interface quickly. LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch...
- Page 17 SNMP-Option First section: The “Mode“ selection field enables or disables the SNMP functionality, including the sending of traps. The selector “Version“ sets the SNMP version (version 1, 2 or 3). In the two fields below, the reading and writing via SNMP is separately indicated for the versions 1 and 2.
-
Page 18: Factory Settings
10 seconds. In this case the module is set to the following: Setup settings Network settings LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 19: Block Diagram
10. Block diagram USB 2.0 ARM Board MODEM Ethernet switch AT91SAM9G20 8x RJ45 11. Application example output Ausgang feed-in QAM / PAL Zuführung DVB-S/S2-Signal QAM/ PAL LANIOS-RCL HELIOS-P1 QUASARIOS LTE101 LANIOS-RCL DVB-S/-S2 DVB-S/-S2 DVB-S DVB-S DVB-S/-S2 DVB-S/-S2 QAMOS QAMOS PALIOS PALIOS QAMOS QAMOS-MEDIA... -
Page 20: Technical Data
8 W Environmental conditions temperature range -10 … +55 °C relative humidity ≤ 80 % (non condensing) installation type vertical installation location splash-proof and drip-proof LANIO S- RC L • Part no. 5161.20 / 5161.21 • Ethernet swi tch... -
Page 21: Bibliography
13. Notes on the software Software of the LANIOS-RCL © BLANKOM Antennentechnik GmbH Bad Blankenburg Copyright This software is based on Linux 3.6.8 is free software: you can redistribute it and/ or modify it under the terms of the GNU General Public License as published by the Free Software Foundation, either version 2 of the License, or (at your option) any later version. -
Page 22: Declaration Of Conformity
8-fold Ethernet switch with remote connection Type name: LANIOS-RCL Type number: 5161.20 and 5161.21 BLANKOM Antennentechnik GmbH confirms that the mentioned products meet the guideline(s) of the Council for the approximation of legislation of the member states. Electromagnetic compatibility (2004/ 108/ EC)
