2 -Wire Intercom System
DT602 Series User Manual
DT602
DT602D
DT-ENG-602/602D-V1 20140721

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT602 and is the answer not in the manual?

Questions and answers

Summary of Contents for KomelCo DT602

  • Page 1 2 -Wire Intercom System DT602 Series User Manual DT602 DT602D DT-ENG-602/602D-V1 20140721...
  • Page 2: Table Of Contents

    CONTENTS 1.Parts and Functions..................... 1 2.Terminal Descriptions ..................1 3.Specifications ...................... 2 4.Mounting ......................2 4.1 Mounting Without Rainy Cover ..............2 4.2 Mounting With Rainy Cover ................3 4.3 Placing Name Label ..................3 5.System Wiring and Connections ................. 4 5.1 Basic Connection...................
  • Page 3: Parts And Functions

    1.Parts and Functions Camera Lens Speaker Night Light Nameplate Call Button Microphone Rainy Cover 90 mm 23 mm 2.Terminal Descriptions JP/LK P L S + B U S Main Connect Port...
  • Page 4: Specifications

    • Lock control jumper, to select the lock type(see 5.2.1 , 5.2.2). JP/LK: • To connect the bus line and the electronic locks. Main Connect Port: • BUS: Connect to the bus line, no polarity. • PL: External lock power input, connect to the power positive(power +). •...
  • Page 5: Mounting With Rainy Cover

    4.2 Mounting With Rainy Cover The distance between the top of main unit and rain Rainy cover ≥3mm cover should be not less than 3mm. Main unit Rainy cover Main unit The rainy cover and main Connect the cable correctly. unit are installed on the wall.
  • Page 6: System Wiring And Connections

    5.System Wiring and Connections 5.1 Basic Connection BUS(IM) BUS(DS) L1 L2 PL S+ S- Doorbell Button Switch 5.2 Electric Lock Connection 5.2.1 Door Lock Controlled with Internal Power Note: Electronic lock of Power-on-to-unlock 1 2 3 connect E-magnetic lock, the jumper position in 1-2. type should be used.
  • Page 7: Door Lock Controlled With Dry Contact

    2s. be shown. Note: 1.must connect DT602/602D correctly before setting. 2.the parameter will be saved in DT602/602D automatically,so you need only set on one monitor. 3.Here we take DT47M(the monitor) for example, please refer to the corresponding user manual.
  • Page 8: Multi Doorstations Connection

    5.3 Multi Doorstations Connection 4# Camera 3# Camera 2# Camera 1# Camera (Device Address:3) (Device Address:2) (Device Address:1) (Device Address:0) L1 L2 PL S+ S- L1 L2 PL S+ S- L1 L2 PL S+ S- L1 L2 PL S+ S- 100~240VAC A B C D DBC4A...
  • Page 9: Multi Monitors Connection

    5.4 Multi Monitors Connection 5.4.1 Basic IN-OUT Wiring Mode Code=31 Code=30 Code=0 100~240VAC BUS(IM) BUS(DS) (Device Address:0) NOTE:Here we take DT47M(the monitor) for example.
  • Page 10: With Dbc4A Wiring Mode

    5.4.2 With DBC4A Wiring Mode Impedance Code=31 Code=30 OFF ON switch Code=29 Code=28 Code=3 Code=2 Impedance OFF ON switch Code=1 Code=0 100~240VAC BUS(IM) BUS(DS) (Device Address:0) NOTE:Here we take DT47M(the monitor) for example.
  • Page 11: Setup

    6.Setup Note:Monitors response button A must set the user code from 0 to 15.and button B set the user code from 16 to 31. 6.1 ID Settings of Doorstation Power-on within 5 seconds,press Enter the setting the state of prepare within 5 and hold "B"...
  • Page 12: Unlock Delay Time Setting

    6.2 Unlock Delay Time Setting Power-on within 5 seconds,press Enter the setting the state of prepare within and hold "B" button for 3 5 seconds, press and hold "A" button for 3 seconds,and it will enter the seconds, it will enter the state of unlock delay. setting the state of prepare.
  • Page 13: Ringback Tone Setting

    6.3 Ringback Tone Setting Power-on within 5 seconds,press Enter the setting the state of prepare within and hold "B" button for 3 5 seconds, press and hold "B" button for 3 seconds,and it will enter the seconds, it will enter the state of ringback setting the state of prepare.
  • Page 14: Cables Requirements

    7.Cables Requirements The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the maximum distance which the system can reach. The farest monitor monitor with two or four monitors monitor monitor DBC4A 100~240VAC When Monitor quantity <...
  • Page 15 -13-...
  • Page 16 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.

This manual is also suitable for:

Dt602d
