WiOn ECO series User Manual

! CAUTION! Suitable for use with outdoor appliances. Raintight
when mounted vertically with receptacles facing downward.
For use ONLY with a three conductor GFCI protected outlet.
Do not immerse in water. DO NOT EXCEED RATED CAPACITY.
READ ALL INSTRUCTIONS before using the WiOn Outlet.
Wi-Fi™ Status Indicator
Blinking Light: Ready to
connect to Wi-Fi router.
Light continuously ON:
Connection to Wi-Fi
router is complete and
the WiOn Outlet is ready
for use via the app.
Light OFF: Check your
internet connection or
review the app FAQ.
Power Indicator
NOTE: The closer the WiOn Outlet
is located to the Wi-Fi router during
set-up, the better the signal strength
will be for initial configuration.
TO CONNECT THE WiOn OUTLET TO A WI-FI ROUTER
• With the WiOn Outlet plugged into a GFCI protected power outlet outlet,
and the blue light blinking, plug the controlled device (a lamp, for example)
into the WiOn Outlet receptacle. Make sure the controlled device is switched
ON. Note: You can control up to two devices with the WiOn Outlet (each
WiOn Outlet has two app-controlled receptacles). Important: The two Wi-Fi
powered receptacles can only be controlled via the app as a group;
they cannot be controlled individually.
• If the blue light is blinking you can proceed to the next step to begin the
smart phone setup. If not blinking, you must reset the WiOn Outlet as
described in the FAQ section on the reverse side of this sheet. Note: the
blue light will continue blinking until the setup is finished via the smart-
phone app.
• Once you are finished connecting the WiOn Outlet to a Wi-Fi router, the
blue light will remain on continuously to indicate that Wi-Fi connection
has been established and the WiOn Outlet is accessible via the app.
DOWNLOAD
THE WiOn APP:
STEP 1:
Tap Smartphone's
Settings icon
Outdoor Wi-Fi Outlet
Power Button
Press this button
to manually
override the
WiOn Outlet
and turn the
unit ON/OFF.
Receptacles (2)
for controlled
device(s)
(iOS 7 or higher)
(Version 4 or higher)
Tap the Select the
Wi-Fi icon WiOn Outlet
STEP 2:
Tap the
WiOn icon
Select the Wi-Fi router that you want to
link to the WiOn Outlet. (Note: It may take
a few seconds for network communication).
STEP 3: Fill in the information (Note: US
residents enter your five-digit ZIP code,
Canadian residents enter your three-digit
telephone number area code). When
finished filling in the information, click
the SAVE SETTINGS or JOIN button.
(In iOS: if you can't find the JOIN
button, click in the "Password" box).
TO ADD ADDITIONAL WiOn OUTLETS TO THE APP: Repeat steps 1-3 for
each additional WiOn Outlet. Remember to give each outlet a different
name (for example, Outlet 1, Outlet 2, etc.). Note: Each WiOn Outlet has
two receptacles that are controlled by the app. If you need to control
more than two devices, you must add additional WiOn Outlets to the app.
125 V ac / 60 Hz
15 A Resistive
15 A General Use
1000 W Tungsten
500 VA Electronic Ballast
120 V ac 60 Hz, 8.3 A Ballast
1/2HP
Choose a Network
Device [ECO-XXXXXXXX] Ver: XXX
Home Router
Other Router A
Other Router B
Enter Zip Code:
Name Device: (such as lamp or fan)
Enter Wi-Fi Router Password:
More: Learn more about this app,
including an FAQ section.
Usage: Function is not available
on this device.
Settings: To set your Wi-Fi power outlet,
transfer local Wi-Fi to cloud mode, or to
rename the WiOn Outlet.
Timer: To set ON/OFF programs (up to a
maximum of 12 Custom ON/OFF events).
Cloud Icon: Activates remote access
function of device through 3G, 4G, LTE,
public Wi-Fi network, or other Wi-Fi router.
Mailbox: To email consumer service or
share app feedback.
Programmable Timer: To set custom
ON-OFF events.
Countdown Timer: The controlled device
will turn off after selected time.
Astronomic Timer: The controlled device
will turn on or off at sunset or sunrise.
Vacation Random: The controlled device
will turn on or off randomly between one
of three time frames (night, day, all day).
Security Random: The controlled device
will turn on and off randomly between
chosen start and end times.
