User Manual
Griddle User Manual
Griddle
User Manual
Please read this manual before using.
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 |
WWW.TWOTHOUSANDCO.COM
1
Advertisement
Related Manuals for Twothousand TT-WE173A
Summary of Contents for Twothousand TT-WE173A
- Page 1 Griddle User Manual Griddle User Manual Please read this manual before using. NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM...
- Page 2 Griddle User Manual Thanks for your purchasing and using GH Series Contact Grill. For making full use of function of this product and reducing unnecessary damage and injure. Please read this manual carefully before using this machine and keep it well for future reference. Warning! Any refitting and wrong installation, adjustment and maintenance can lead to property loss and causality.
- Page 3 Contact Grill single single single single single Upper/lower Upper/lower Upper Upper Upper/lower ribbed smooth smooth/lower ribbed/lower ribbed ribbed smooth Model TT-WE173A-(A TT-WE173A-(B TT-WE173A-(C TT-WE173A-(D TT-WE173B Voltage 220~240V 220~240V 220~240V 220~240V 220~240V 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz Power 1.8KW 1.8KW 1.8KW 1.8KW...
- Page 4 Griddle User Manual e controller number Temperatur 50~300℃ 50~300℃ 50~300℃ 50~300℃ 50~300℃ e range Upper grill 214×214(mm) 214×214(mm) 214×214(mm) 214×214(mm) 340×220(mm) size Lower grill 218×230(mm) 218×230(mm) 218×230(mm) 218×230(mm) 360×285(mm) size Dimension 290×395×210(mm) 410×370×220(m Weight 14kg 13kg 13.5kg 13.5kg 15.5kg Name Contact Grill Contact...
- Page 5 Griddle User Manual Suitable switch, fuse breaker and three-phase socket should be installed near the equipment. There is an earth bolt at the back of the equipment. Please connect the earth wire in compliance with the safety regulations reliably with copper cable of no less than 2mm. Before using user should check whether connection is firm and voltage is regular and earth connection is safe.
- Page 6 Griddle User Manual NOTICE! ●When the thunderstorm is coming, the electricity supply must be cut off soon. It will avoid the equipment being damaged in cause of lightning stroke. ● Do not destroy the control panel and the surface of the machine with hard or sharp things. ●...
-
Page 7: Troubleshooting
Griddle User Manual Cleaning and Maintenance Cut off the power supply before cleaning in case of accident. Do not use wet towel with non-corrosive cleanser to clean the module plate, the surface of the equipment and power cord. Direct wash by water is not permitted in case of any damage of the functions. If do not use it at any time, please turn off temperature controller and main switch. - Page 8 Griddle User Manual VIII. Circuit Diagram TT-WE173 (A) TT-WE173 (B) TT-WE173 (C) TT-WE173 (D) TT-WE173 (E) TT-WE174 (A) TT-WE174 (B) TT-WE174 (C) TT-WE174 (D) TT-WE174 (E) HL1, HL3----POWER INDICAOTR; HL2, HL4----HEATING INDICATOR; SA, SA1, SA2----TEMPERAUTRE CONTROLLER E----GROUND CONNECTION; SB, SB1, SB2----TEMPERAUTRE CONTROLLER; EH1, EH2, EH3, EH4----HEATING WIRE; THE SHELL OF THIS MACHINE MUST BE EARTH GROUNDED FOR SAFETY SAKE.
- Page 9 Griddle User Manual Whether the machine is tilted Whether the power cord is old, broken or Before using damaged Whether the control panel is damaged Whether there is strange smell After using Whether the upper and lower module plate cannot be heated at the same time? Is there any strange voice or is the machine out of control while the machine is lifting WARNING!
