Summary of Contents for IGS All stars
-
Page 3: Table Of Contents
Table of Contents 1. Hardware ..................2 Connectors Descriptions ................... 2 Connection Diagram ..................3 DIP Switch Settings................... 4 36 & 10 PIN Button Layout................4 Solving Hopper SSR Error ................5 2. Bookkeeping & Adjustment ............6 Access Flow Chart .................... 6 System Adjustment ................... -
Page 4: Hardware
1. Hardware Connectors Descriptions Reset 36-Pin Connector DIP SW2 DIP SW1 10-Pin Connector A RS-232 Connects to optional Citizen VGA port printer/ticket dispenser. Connects to screen * Use Belkin #F2L044 (serial printer cable/null modem) for Citizen printer. C RS-232 Connects to Micro Touch +5V Power output compatible touch screen Notes:... -
Page 5: Connection Diagram
Connection Diagram 36 Pins 10 Pins PARTS SIDE SOLDER SIDE PARTS SIDE SOLDER SIDE SPEAKER +12V +12V TICKET OUT TICKET SSR TICKET SWITCH START/ALL STOP STOP4/SMALL/HELP STOP5/PLAY STOP1/TAKE STOP3/DOUBLE/SELECT LINE STOP2/HOLD PAIR/BIG COIN A KEY IN COIN C RECORD TEST KEY OUT/PRINTER OUT COIN A METER KEY IN METER... -
Page 6: Dip Switch Settings
DIP Switch Settings DIP SWITCH 1 TOUCH LINER SELECT Note: Please reset after adjusting LINER SELECT. 36 & 10 PIN Button Layout STOP 1 STOP 2 STOP 3 STOP 4 STOP 5 START TAKE DOUBLE SMALL PLAY ALL STOP (HOLD (SELECT (HELP) TAKE... -
Page 7: Solving Hopper Ssr Error
Solving Hopper SSR Error After powering on the machine, if the hopper keeps working and can’t be stopped, it could be that the hopper SSR’s jump setting is incorrect. How to solve: 1. Locate the Hopper SSR jump (JP7) on the PC board. Then identify current HOPPER SSR is at HIGH ACTIVE or LOW ACTIVE. -
Page 8: Bookkeeping & Adjustment
2. Bookkeeping & Adjustment Access Flow Chart Press [RECORD] [BIG] [DOUBLE] LAST HAND SHORT TERM [BIG] [DOUBLE] CURRENT LAST MAIN GAME DOUBLE GAME DATA DATA Press [RECORD] [SMALL] SYSTEM Default password: PASSWORD Press [START] 8 times [BIG] [DOUBLE] [SMALL] [TAKE] MAIN GAME DOUBLE GAME ADJUSTMENT... -
Page 9: System Adjustment
System Adjustment ITEMS SETTING SELECTIONS DEFAULT MAX. PLAY/LINE (25) 2, 4, 8, 10, 15, 20 MAX. PLAY/LINE (9) 5, 10, 20, 30, 40, 50 MIN. PLAY/TOTAL 1, 5, 7, 9, 10, 15, 20, 25 MIN.PLAY FOR JACKPOT 1, 3, 5, 9, 10, 15, 18, 25 COIN RATE 1, 2, 4, 5, 10, 15, 20, 25, 30, 40, 50, 60, 75, 80, 100, 200, 250, 400,500, 1000... -
Page 10: Chance Adjustment
Chance Adjustment ITEMS SETTING SELECTIONS DEFAULT LEVEL 1 (easiest), LEVEL 2, LEVEL 3, LEVEL 4, MAIN GAME LEVEL LEVEL 6 LEVEL 5, LEVEL 6 (hardest) DOUBLE GAME LEVEL 95%, 90%, 85% Touch Screen Calibration 1. Press [RECORD] and follow the on-screen prompts to enter the calibration screen. -
Page 11: Game Introduction
5~20 free games: Free games will be triggered when correct symbols show up. Touch screen / Auto play support. Main Game ALL STARS is a 15-reel & 9/25-liner game with 3 different bonus games. 3 sets of Jackpots 9 / 25-liner... -
Page 12: Free Game
Free Game Get 3 or more enter the free game. Any 2 or more on the screen , the player get extra win. Bonus Game Getting 3 or more bonus symbols on the screen allows player to enter the Bonus Game. - Page 13 Bonus Game1 Start the reel to play the bonus game. Collect 3 Skill Moves in the frame above to get the extra bonus. Bonus Game 2 Player can select 1 of the 3 points to hit the ball. Exit the game when inning finished or home run hit.
-
Page 14: Double Game
Double Game After winning the Main game or Bonus game, player can press [DOUBLE UP] button to play Double Game. Player can press [DOUBLE UP] button to select one of five pokers from the lower row. Then, press [BIG] or [SMALL] to guess it’s bigger or smaller than the poker highlighted. -
Page 15: Wins Rules
Wins Rules Jackpot JACKPOT 1 Five-in-line wins 100% OF Jackpot 1; Four-in-line wins 50% OF Jackpot 1; Three-in-line wins 25% OF Jackpot 1. JACKPOT 2 Five-in-line wins 100% OF Jackpot 2; Four-in-line wins 50% OF Jackpot 2; Three-in-line wins 25% OF Jackpot 2. JACKPOT 3 Five-in-line wins 100% OF Jackpot 3;... -
Page 16: Line Chart
25-Liner MIN. TOTAL PLAY JACKPOT JACKPOT 100% Win paid from left to PLAY LINES LINE PLAY TOTAL PLAY WIN LINES right and right to left 1-10 1-25 Line Chart Line-up pattern: 9-liner Line-up pattern: 25-liner Odds Table Line-up pattern: 9-liner Line-up pattern: 25-liner... - Page 17 V100US...
