Summary of Contents for Performance Road Bike
- Page 1 ROAD BIKE ASSEMBLY...
- Page 2 ASSEMBLY THANK YOU tools you need Hex wrench set Bike stand Thank you for purchasing your bike from Performance. (typically 6mm, 5mm (preferred) We’re glad that we can be a part of your cycling and 4mm wrenches are required) experience. Don’t forget, if you live in the area of a...
- Page 3 ASSEMBLY unpacking & assembling your new road bike » Carefully cut through the top of cardboard with a sharp box cutter or a pair of scissors. once the box is open » remove the saddle and the seatpost. » remove the bike.
- Page 4 ASSEMBLY install the seatpost » Apply a small amount of grease to the inside of the seat tube and the seatpost below the minimum insertion line. FOr CArBOn sEATPOsT insTALLATiOn APPLy CArBOn PAsTE. DO nOT GrEAsE THE sEAT TuBE. » Loosen the bike frame seat clamp and insert the seatpost beyond the minimum insertion line. »...
- Page 5 ASSEMBLY install the front wheel » install the quick release skewer (located in the small parts box) through the axle of the front wheel. note positioning of the coil springs on the skewer before mounting. » mount the front wheel on the fork. The quick-release lever should be on the non-drive side (for reference, this is the left side of the bike if you were sitting on the saddle).
- Page 6 ASSEMBLY install the front brake cable » run the front brake cable through the front brake barrel adjuster (make sure that the brake quick-release lever is in the open or up position). (A) » Guide the cable through the cable tensioner bolt. (B) »...
- Page 7 ASSEMBLY install pedals » Apply a small amount of grease to each pedals threads. » install right pedal (“r” located on pedal axle or spindle) with pedal wrench by threading into the drive side crank arm in clockwise direction (for reference this is the right side of the bike if you were sitting on the saddle). DO nOT FOrCE A PEDAL THAT WiLL nOT THrEAD EAsiLy.
-
Page 8: Final Check
ASSEMBLY install reflectors » install seatpost reflector (colored red, located in the small parts box) to the seatpost with a Phillips head screwdriver. use provided shims (located in the small parts box) as necessary for a secure fit. » install handlebar reflector (colored clear, located in the small parts box) to the handlebar with a Phillips head screwdriver.
