Thanks for you purchasing EzCAP USB2.0 Video Grabber at ClimaxDigital http://www.climaxdigital.co.uk. The
following contents guide you how to set up on your computer. Hope this device will bring you nice digital
experience
The EzCAP series USB 2.0 Video Grabber, they can capture High-quality video and audio file direct
by USB 2.0 interface without sound card. However, the installation is very simple and the external power is
unnecessary. Solution for laptop, we have enclosed the professional video editing software –"ArcSoft ShowBiz
DVD 2"then provide best editing function for you. ShowBiz DVD 2 is video-editing software that makes editing
your movies as fun as shooting them. ShowBiz DVD 2 helps novice users finish stylish movies in only few steps.
Share finished projects on DVD, tape, the Web, and mobile devices.
Key Features
．Include Professional and easy to learn & used video editor software-ShowBiz DVD2
．Popular USB 2.0 interface and not need other power
．Capture Video & Audio though USB 2.0 interface
．Support Brightness, Contrast, Hue, and Saturation control
．The dimension suitable that is easy to carry
．Could capture audio without the sound card
．High plug & play
．Support For All Formats: record in DVD+/-R/RW, DVD+/-VR, and DVD-Video.
．Applying to internet conference / net meeting
Note: ClimaxDigital SNAPSHOT Version (EzCAP116) USB2.0 Video Grabber has a snapshot button that
allows you to take still photos.
Specification
．Complies With Universal Serial Bus Specification Rev. 2.0.
．Supports NTSC, PAL, Video format
．Video input: One RCA composite, One S-Video.
．Audio input : Stereo audio (RCA)
．USB bus power
．Supports high quality video resolution
NTSC: 720 x 480 @ 30fps, PAL: 720 x 576 @ 25fps
．Supports Windows XP, Vista 32 bit and Vista 64 bit.
System Requirements
．P4 1.70GHz CPU or above
．256MB RAM
．VGA card with 32MB memory
．One available USB 2.0 port
．Microsoft windows XP, Vista
Package Contents
Overview
1
Advertisement
Related Manuals for ClimaxDigital EzCAP series
Summary of Contents for ClimaxDigital EzCAP series
- Page 1 Overview The EzCAP series USB 2.0 Video Grabber, they can capture High-quality video and audio file direct by USB 2.0 interface without sound card. However, the installation is very simple and the external power is unnecessary. Solution for laptop, we have enclosed the professional video editing software –“ArcSoft ShowBiz DVD 2”then provide best editing function for you.
-
Page 2: Connection Chart
．USB extension cable (option) ．Software and driver CD Connection Chart Additional cables and adaptors can be purchased at ClimaxDigital http://www.climaxdigital.co.uk You should need to connect the video grabber with your analogue video device, such as V8/Hi8 Camcorder, DVD Player, Set-top Box, Personal DVR, etc. - Page 3 2, The below connection chart is for Composite Video output: 3, The below connection chart is for S-Video output: 4, For Scart output, you connect scart video audio adapter with video source, then you can get the Composite Video/S-Video/Audio output. Then you can connect them following above 2 or 3 term.
-
Page 4: Hardware Installation
Note: If you have any antivirus software enabled, please disable it during the installation of the software. Before you first connect the EzCAP series USB 2.0 Video Grabber to your computer, please insert the “Software and driver CD” into your CD drive. Select the option “Install Driver”. - Page 5 You can check the driver version for “USB 2861 Device” and “USB EMP Audio Device”.
- Page 6 ShowBIZ DVD 2 Installation Please insert the “Software and driver CD” into your CD drive, Click “Install ShowBiz DVD 2” and select your language for the installation. And click “Next” or/and “Install”. You need enter user name and serial number (you can find out the serial number on driver CD bag). Click “finish”...
- Page 7 Open ShowBiz DVD 2, select “Capture, create and edit video” and “Capture From Device”. You can see “USB 2861 Device” is for Video Device selection, and please select Audio Device selection to be “USB EMP Audio Device”. You can select the input and format to change video and audio selections. For recording, you can set the recorded file format and recorded files location as following picture after you click the “Record”...
-
Page 9: Frequently Asked Questions
Question: Is the EzCAP Video Grabber compatible with MACS? Answer: Yes, but you need the EzCAP Video Grabber Model EzCAP128 hardware for MACs. Please purchase it http://www.climaxdigital.co.uk Question: If my Video is e.g. 180mins long, will it take this long to transfer via the EzCAP Video... - Page 10 These adaptors can be bought at http://www.climaxdigital.co.uk Question: Can I copy original movies onto my computer using the EzCAP Video Grabber? Answer: Yes you can but this is illegal.
- Page 11 Solution 2: However, if you are using ‘ShowBiz DVD2’ software, please check the device name. If the user's device name shows " USB Audio device", then you need to update the driver from the supplied CD to "USB EMP Audio device", then the problem of preview with no sound will be solved.
