Woojeon & Handan Aqua Cam User Manual

Full hd real-time recording

Hide thumbs

Table of Contents

Quick Links

Download this manual

SAFETY ......................................................

BASIC PACKAGE BUNDLE ITEMS ............

BUTTON DESCRIPTION ..............................

CHARGING BATTER .................................

SD CARDS ...................................................

RECORDING,CAPTURE ..............................

1)VIDEO RECORDING

2) PHOTO CAPTURE

3) WI-FI ON/OFF　

SETTING ......................................................

1) VIDEO

2) PHOTO

3) WI-FI

4) SET UP

5) INFORMATION

TRANSFERRING FILES ..............................

HDMI TV OUT .............................................

APPLICATION .............................................

FIRMWARE UPGRADE ..............................

SPECIFICATION ..........................................

TROUBLE SHOOTING .................................

WARRANTY ................................................

CALL CENTER ..........................................

4 4

•

Table of contents

Table of Contents

Need help?

Do you have a question about the Aqua Cam and is the answer not in the manual?

Questions and answers

Summary of Contents for Woojeon & Handan Aqua Cam

Page 1: Table Of Contents
Table of contents 　 TRANSFERRING FILES ………………………… SAFETY ……………………………………………… HDMI TV OUT ……………………………………… BASIC PACKAGE BUNDLE ITEMS ………… APPLICATION ……………………………………… BUTTON DESCRIPTION ………………………… FIRMWARE UPGRADE ………………………… CHARGING BATTER …………………………… SPECIFICATION …………………………………… SD CARDS …………………………………………… TROUBLE SHOOTING …………………………… RECORDING,CAPTURE ………………………… 1)VIDEO RECORDING WARRANTY …………………………………………...
Page 2: Safety
4. Do not let water or sand enter Aqua Cam when port cover is open. It may cause trouble Aqua Cam. Do not open or close port cover with wet or sandy hands. Open port cover after drying your hands thoroughly.
Page 3 Storage 1. Do not expose Aqua Cam to direct sunlight or heating instruments. Do not leave it inside a parked vehicle in the summer season. 2. Do not use the product near fire (Do not put it in an electric oven.) 3.
Page 4: Basic Package Bundle Items
BASIC PACKAGE BUNDLE ITEMS ➊ Aqua Cam ➌ Handlebar Mount/Adhesive Mount ➌User’s Manual ➍ Warranty Certificate ➎ Charging port cover 품질 보증서 본 제품은 고객 여러분의 더욱 편리한 생활을 위해 품질 관리를 통해 엄격한 검사에 합격한 제품입니다. 다음과 같이 품질을 보증합니다.
Page 5 ★ A fixed form Like the picture above, Aqua cam is tied using Handlebar Mount / ☞ Adhesive Mount at the place where you want to set. ☞ This product is not being used as "Portable device", instead be used as fixed position.
Page 6 ★ Replacing the PORT COVER Bundle provides a charging port cover for water resistance environment ☞ To be water resistance, you must use ‘Duran USB cable’ ☞ You can remove the port cover by laterally inserting a sharp pin or pen into the micro SD card slot. Portable port cover Charging port cover (Water resistant)
Page 7: Button Description
BUTTON DESCRIPTION Recording Start / Stop / Select / Power ON,OFF(Press hold) Moving cursor / Move to Detail setting menu Micro-HDMI out jack (Press hold) (not inchide) Micro-5Pin (USB) jack Micro-SDcard insertion slot (not inchide) Reset button • BUTTON DESCRIPTION...
Page 8: Charging Batter
4. If you do not intend to use Aqua Cam for a period, charge Aqua Cam every 3 to 6 months ☞ : Sometimes In order to protect the life of the battery AQUA CAM goes into Trickle charge mode, this mode is not turned off LED lamp after Charging completed, so in this case, stop charging.
Page 9: Sd Cards
16GB 32GB MODE Make sure a micro SD card has been inserted before using Aqua Cam 4GB, 8GB, 16GB and 32GB Micro SD cards are available. ▒ Recommendation: It is recommended to use a micro SD card of Class4 or faster, 4GB~32GB Sandisk, Samsung or Transcend.
Page 10: Recording,Capture
RECORDING, CAPTURE 1) VIDEO RECORDING OPERATION DISPLAY 1. Place the cursor on then press the Recording (Select) button. 2. Video recording starts with the icon blinking. 3. If you want to finish recording, press the Recording (Select) button again. NOTE BEEP : Start Recording-Twice short / Finish Recording-Once long LED: The purple LED flashes during recording 2) PHOTO CAPTURE...
Page 11: Setting
SETTING 1) VIDEO OPERATION DISPLAY 1. Press and hold moving curser more than 2 seconds to move setting mode 2. Place the cursor on then press the Recording (Select) button. 3. Press moving curser to move to right mode 4. Press Recording (Select) button to select setting (Resolution, Mode, File delete) 5.
Page 12 2) PHOTO DISPLAY OPERATION 1. Place the cursor on and press the Recording (Select) button. 2. Select Detail setting (Resolution, Mode, Image quality, File delete) NOTE LED: LED on for each shot BEEP : Sounds on for each shot Manual Super fine Resolu Image...
Page 13: 5) Information
BALANCE, Time, MIC, Format, Factory set, Subtitle, Loop recording) Set up Language: English (to be supported) Up/Down reverse: Use for mounting Aqua Cam reversed LED: ON/OFF BEEP: ON/OFF WHITE BALANCE : Camera setting to produce natural colors based on different light conditions such as outdoor or...
Page 14: Transferring Files
(100PHOTO) File name: LOOP#### HDMI TV OUT OPERATION DISPLAY 1. Connect Aqua Cam to TV using the micro HDMI cable. 2. Check that the HDMI icon is automatically displayed on the LCD. 3. You can play video/photo through TV. Video, photo List screen...
Page 15: Application
APPLICATION You can download applications from the APP Store and the Play store (key word: Duran) Connection 1. Turn on the Aqua-Cam. 2. Connect to the Wi-Fi signal (initial name: Duran####/ password: 1234567890) of Aqua-Cam on a smart phone. ☞ You can change Wi-Fi password at ‘Detail setting’ of application. 3.
Page 16 Key functions 2. Quick mode change: Quick change Detail setting 1. Preview ON/OFF, recording, photo, video(You can view a preview and recording among favorite modes (video-manual, at the same time)☞except time-lapse mode photo-manual, burst shot, time-lapse photo) or resolution WVGA 4.
Page 17: Firmware Upgrade
You can also upgrade firmware by importing the firmware file with the camera and computer connected through USB without removing the SD card. After update the first time in about 20 seconds boot time is required due to optimization (with BEEP sound ). After optimizing please restart AQUA CAM Website :http://www.duran.co.kr •...
Page 18: Specification
SPECIFICATION A5S(Ambarella) Full HD real-time recording 1080p, 30fps 720p, 30fps Video Resolution 720p, 60fps WVGA, 120fps Photo Resolution Resolution 2304 x 1296 (Super Fine, Fine, Normal) C-MOS Sensor AR0330 ( 1/3” CMOS Sensor 3.5-mega pixel ) LENS FULL HD LENS -. Image plan : 16.5mm, “Composition : 1GM+5G+IRCF, F NO : f 2.0 Angle of view D : 140, H : 108, V : 80(Degree) RTOS...
Page 19: Trouble Shooting
Turn on Aqua Cam and connect to computer Computer doesn not recognize Aqua Cam When the battery level is low, charge the camera Moisture condensation has occurred. Turn off Aqua Cam and wait about an hour for The lens gets fogged the moisture to evaporate...
Page 20: Warranty
WARRANTY 1. Warranty against maker’s defects is 1 year for Aqua-Cam and 6 months for accessories. The product will be exchanged with a new product in case of defect of the whole product and accessories will be provided in case of defects of accessories. 2.
Page 21 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rul es. The se limit s are de signed to pro vide r easonable prote ction again st harmful interference in a residential in stallation.
Page 22: Call Center
CALL CENTER Phone support, 82-2-2105-0757 e-mail support, Customer service department : go@duran.co.kr Technical department : tech@duran.co.kr Sales department : sale@duran.co.kr Website, http://www.duran.co.kr • CALL CENTER...
