ZBA Z-1070 User Manual

Pocket-size personal data collector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ZBA Inc
.
Copyright © 2007. All rights reserved.
No warranty of any kind is made in regard to this material, including, but not
limited to, implied warranties of merchantability or fitness for a particular purpose.
Although every effort is made to assure accuracy and completeness, we can not
be held liable for any errors contained herein or incidental or consequential
damages in connection with furnishing, performance or use of this material.
We shall be under no liability in respect of any defect arising from fair wear and
tear, willful damage, negligence, abnormal working conditions, failure to follow
the instructions and warnings, or misuse or alteration or repair of the products
Page 1 of 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-1070 and is the answer not in the manual?

Questions and answers

Summary of Contents for ZBA Z-1070

  • Page 1 ZBA Inc Copyright © 2007. All rights reserved. No warranty of any kind is made in regard to this material, including, but not limited to, implied warranties of merchantability or fitness for a particular purpose. Although every effort is made to assure accuracy and completeness, we can not be held liable for any errors contained herein or incidental or consequential damages in connection with furnishing, performance or use of this material.
  • Page 2 ZBA Inc without written approval. No part of this document may be reproduced, transmitted, stored in a retrieval system, transcribed, or translated into any language or computer language in any form or by any means electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without express written consent and authorization.

  • Page 3: Table Of Contents

    ZBA Inc TABLE OF CONTENTS General Information ....................4 1.1. Introduction ......................4 1.2. Unpacking ........................ 4 Optional Accessory ......................5 1.3. Device Outline ......................6 1.4. Battery Care ......................6 1.5. Bluetooth® Communication ..................7 1.5.1. Connection Mode: ..................... 8 1.5.2.

  • Page 4: General Information

    ZBA Inc Inspecting on Interface Cables ................33 Battery ........................33 1. General Information 1.1. Introduction Congratulations on your purchase of the Personal Data Collector (PDC) with LCD display. The PDC features a real-time clock, a buzzer, a dual-color status...

  • Page 5: Optional Accessory

    ZBA Inc -1 ea. DB-9(F) serial communication cable (For data upload and download) - 3 ea. AAA NiMH rechargeable batteries - 1 ea Power Adapter -1 ea. CD-ROM support disk If any package contents are damaged or missing, please contact your dealer immediately.

  • Page 6: Device Outline

    ZBA Inc 1.3. Device Outline Figure 1: Pocket-Sized P ersonal Data Collector 1.4. Battery Care In the interests of providing the best product performance possible, the Personal Data Collector comes with high quality, rechargeable Nickel Metal Hydride (NiMH) batteries and a Power Adapter. After NiMH batteries are installed,...

  • Page 7: Bluetooth® Communication

    Note: The PDC comes with 3 AAA 700mAH NiMH rechargeable batteries (Use ZBA supplied rechargeable batteries only) If the PDC remains unused for an extended period (two months or more) the batteries should be removed. Even when the PDC is turned off, there is a very small amount of power consumed, which can, over time, have an adverse effect on batteries.

  • Page 8: Connection Mode

    ZBA Inc 1.5.1. Connection Mode: Before establishing a Bluetooth® connection between two devices, it is necessary to define which device to be the “Master” during the communication. The “Master” Bluetooth unit is the only device that can initiate a "connect" or "disconnect"...

  • Page 9: Connect/Disconnect With Target Devices

    ZBA Inc 1.5.6. Connect/Disconnect with Target Devices: The Bluetooth Master device can initiate connect or disconnect with target (Slave) devices. 1.5.7. Reliable RF Communication: During transmission, follow a specific protocol. There is a response to each transmission packet which is either, ACK or NAK. ACK indicates “acknowledged”, data is received and decoded properly.

  • Page 10: Packet Example

    ZBA Inc 1.5.8. Packet Example: If a record data is "ABCD" with STX/ETX, SEQ and CKS enable, assume SEQ is ‘0’ (030H) the send out data is format as: 02H + 030H + "ABCD "+ 03AH + 03H 030H + 041H (A) + 042H (B) + 043H (C) + 044H (D) = 013AH Checksum = 013AH –...

  • Page 11: Use Bluetooth® Dongle

    ZBA Inc 1.6. Use Bluetooth® Dongle If an optional Bluetooth USB dongle is purchased with PDC, you will find a CD with software from IVT Corporation know as BlueSoleil. If the CD is missing you can go to www.ivtcorporation.com to download the trial version of BlueSoleil.

  • Page 12: Pairing And Connect To A Spp Slave Pdc

    ZBA Inc A Bluetooth service Authorization window will pop out. Set always allows the device access to enable and click “Yes”. Upon completion of the pairing procedure then you can commence the connect function. The connect message appears at the right corner to indicate the COM port number to connect.
  • Page 13 ZBA Inc within range will have an icon appear in the main window. Right click the PDC icon to enable device service list, select “Pair Device” to start the pairing operation. The Bluetooth passkey window will pop out. Type the PIN code as passkey to finish the pair.

  • Page 14: Getting Started

    ZBA Inc 2. Getting Started 2.1. Installing Batteries Press the battery cover lock to remove the battery cover. Insert batteries according to the orientation picture in the battery cavity Replace the cover and lock it into place. Figure 2c: Inserting Batteries 2.2.

  • Page 15: Power On Device To Collect Data

    ZBA Inc unit. To charge NiMH batteries: 1. With NiMH rechargeable batteries (ONLY!) in the PDC unit, connect the PDC with the Communication Cable. 2. Plug the power adapter connector into the socket on the side of the large end connector of the Communication Cable.

  • Page 16: Power On Device

    ZBA Inc 2.3.1. Power On Device Press and hold the v and ^ keys together to turn on the Personal Data Collector. The screen will direct jump to the Power-On scan screen. Figure 4: Power On Scan Screen - Press the FN key to Remote Screen.

  • Page 17: Scan Barcode

    ZBA Inc Select the Run Task under Main Menu. The LCD shows <Rec>, for record number, and is ready to scan and collect data. 2.5. Scan Barcode Select 1. Run Task Enter into data input Press SCAN key under Main menu mode.

  • Page 18: Keying In Data

    ZBA Inc Figure 7: FREETASK Screen 2.6. Keying in Data When requiring to key in data manually, there are two modes of data, press the ^ key. Mode One: Press ^ key once Cursor digit add by Press v to move...
  • Page 19 ZBA Inc Press v keys to Press Scan key to Press FN to go mode one decrease data confirm input data Data Storage The PDC can retain more than 2,000 records. To review stored data, press the ^ key. To end review of stored data, press the FN key.

  • Page 20: Upload Data With Windows Software

    ZBA Inc Figure 8: Upload Data 2.8. Upload Data with Windows Software You can also upload data by specified PC software, please refer to section Use WinTaskGen. 2.9. Delete Data Use v and ^ keys to commend “Y” (yes) or “N” (no) to delete data. Follow by SCAN key to confirm.

  • Page 21: Beep Volume

    ZBA Inc Figure 10: LCD Contrast 3.2. Beep Volume Use v and ^ keys to select Volume from Low, Medium, Loud and Quiet. Follow by SCAN to confirm. Figure 11: Beep Volume 3.3. System Clock Set Date Set Time Use ^ and v key Barcode Setup 3.4.
  • Page 22 ZBA Inc RS-232 and HID. The Bluetooth® includes master and slave mode SPP profile will simulate a wired RS232 interface or USB-HID. The USB-HID Profile is the same as USB keyboard can easy adapt to any host computer like any standard keyboard.
  • Page 23 ZBA Inc Set PIN code: Previously paired PIN is Same as setting BD. ^ shown. Press v, ^ or FN key to modify existing and enter to edit mode. PIN. v key to clear existing PIN. SCAN key for scanning a new PIN.

  • Page 24: Rf Device - Pdc As Slave

    ZBA Inc 3.5.3. RF Device – PDC as Slave Select RF Device Select 2. Slave Previous PIN is shown. Mode The communication parameter is same as the RS-232 setting. 3.5.4. RS-232 Cable Select RS-232 Cable Disable/Enable Disable/Enable Sequential Num. Press Checksum Digit.

  • Page 25: Usb Hid Cable

    ZBA Inc Dis/Enable Online Disable/Enable Send Rec. Press Offline Operate. SCAN to select Press SCAN to select 3.5.5. USB HID Cable Select USB HID Set HID Language. Set Delay Setup. Cable Press SCAN to ^: numbers and select letters v: move cursor...

  • Page 26: Auto Power Off

    ZBA Inc 3.6. Auto Power off Use v and ^ keys to select the wait time of Auto Power off. Select to the setting of 1, 3, 5, 10, 30 minutes or Disable. Follow by SCAN key to confirm. Figure 13: Auto Power Off 3.7.
  • Page 27 ZBA Inc Communication RF Device Communication Mode Master Sequential Num. Disable Checksum Digit Disable STX/ETX Packet Disable Disable (STX/ETX on Send Terminator only) Data Terminator CR/LF Host ACK/NAK Enable Host Response 300 mS (ACK/NAK on only) Online Send Rec. Disable...

  • Page 28: User Reset

    ZBA Inc Offline Operate Disable (Online enable only) 3.8 User Reset While the PDC is powered off, press and hold the SCAN key for more than 1.5 Sec. As soon as the green LED lights-up, press the FN key. Then, the user reset screen will appear.
  • Page 29 ZBA Inc Press OK to confirm 4. Click Remote Device Setting at the menu bar Another setting window pops up. In this window, you can remotely change PDC settings. Press OK to confirm any changes. Page 29 of 33...
  • Page 30 ZBA Inc 5. Click Upload Data. Page 30 of 33...
  • Page 31 ZBA Inc 6. Press Connect to connect the PC with the PDC. 7. Once connected, the numbers of Records and Fields inside the PDC are shown on the left top. If Upload & Delete Data is selected, those stored data will be deleted soon after uploading to a PC.
  • Page 32 ZBA Inc 8. When uploading is completed, all data will be displayed in the main window, and Upload Finished pops up. Page 32 of 33...

  • Page 33: Cleaning The Window And Housing

    ZBA Inc 5. Maintenance This device provides reliable and efficient operation with minimum amount of care. Although specific maintenance is not required, the following precautions need to be ensured. 5.1. Cleaning the Window and Housing Any visible dirt, or scratch on the scan window will degrade reading performance, therefore do not use abrasive wipes or tissues on the window.
