- Page 1 PROGRAMMABLE MOTION DETECTOR WITH SECURITY ALARM Cat No. TG135A...
- Page 2 TG135A Programmable Motion Detector with Security Alarm Please read the instructions before using the product and retain for future use. 105dB alarm Chime switch PIR lens Battery low Programme Keypad button DISARM Red panic button...
-
Page 3: Battery Installation And Replacement
Introduction The TG135A is a programmable security alarm with a high security PIR sensor incorporating pulse-count technology. It has an optional capability of sounding a chime when it detects and is not in security mode. Battery Installation and Replacement In armed mode the battery low LED will flash every three seconds if the battery needs replacing. -
Page 4: Detection Range
Detection Range The TG135A has a PIR detection range of between 5 and 7m across a 90° angle (see fig 3). It should be mounted between 1.5m and 2.0m high and in a position where potential intruders will move across the face of the unit. -
Page 5: Installation
Keyhole Installation fixings Having decided on a position, mark and drill two holes 36mm horizontally apart and fit the plugs (if Cover necessary) and screws catches supplied. The screws (with heads left 2.5mm proud of the fixing surface) Battery engage with the two compartment Cover keyhole fixings on... - Page 6 The PIR coverage of the unit should now be checked, by switching chime on and waiting 60 seconds before moving around the expected coverage area. At every detection a two-tone chime is heard. It should be noted that the unit is more sensitive when the installer moves across the face of the unit and not directly towards or away from it.
- Page 7 2. To programme the alarm pattern: a. Press PROG. b. Press 1 (factory set); 30 seconds on, 30 seconds off, 30 seconds on. or 2; 60 seconds on, 30 seconds off, 60 seconds on. or 3; 90 seconds on, 60 seconds off, 90 seconds on.
-
Page 8: Operation
Operation 1. To arm the unit on leaving the building: a. Ensure chime switch is off. b. Enter your security code (see programming). c. Press ARM. Approximately 60 seconds after completing this sequence a single bleep will be heard confirming the system is active. This allows the PIR system to become operational and gives time for occupants to leave the building. -
Page 9: Panic Mode
3. Chime mode (only available when unit is disarmed): a. Slide chime switch to on. b. Wait for 60 seconds until a bleep is heard. The unit will now respond to moving heat sources with a two-tone chime. 4 Panic mode If the user feels endangered by a potential or actual intruder then the panic alarm (30 seconds duration) may be used to discourage... -
Page 10: Points To Note
Points to note • For indoor use only. • Keep away from direct sunlight. • Loud alarm – keep away from ears. • Do not locate near radiators or heaters. • Do not locate near fans. Trouble Shooting Unit fails to ARM or DISARM Try entering security code and ARM or DISARM again. -
Page 11: Specifications
Specifications PIR detection: 5 – 7m over 90°. Alarm: 105dB. Battery: PP3 Alkaline. THREE YEAR GUARANTEE 3 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture within 3 years of the date of purchase, please return it to your local Homebase store in the first year with proof of purchase and it will be replaced... - Page 12 HELPLINE 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND 020-8452-1112 or email csc@timeguard.com...
