Summary of Contents for Onnet technologies konnect plus

Page 1 www.onnettechnologies.com...
Page 2 As the upgrade of software and hardware, there will be changes. And if there are changes, Onnet Technologies is not responsible for informing in advance. If you want to know m o r e a b o u t o u r p r o d u c t i n f o r m a t i o n , p l e a s e v i s i t o u r w e b s i t e a t...
Page 3 FCC Caution The device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: This device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
Page 4 Chapter-1 Introduction Dear Customer, Thank you for buying another innovative product from Onnet Technologies. We assure you of an unparalleled and exceptional experience with our Onnet product. This product offer the best of USB /Print server applications. It is yet another example of Onnet's commitment to get the latest and most innovative technologies to you for your experience.
Page 5 About Onnet Onnet Technologies is a Green Initiative inspired company. Our core focus is to bring together innovative energy efficient wireless network routers for the small office and home office users as well as Energy Efficient power and switching equipments for the outdoor network in the ICT industry .
Page 6 The state of the art assembly unit for integrating the latest technology is also located at Gandhinagar. With one of the youngest pool of entrepreneurial skills available in the country, Onnet Technologies is revolutionizing the knowledge and technology based growth engine. Onnet Technologies objective is to contribute to the eventual energy security of the country.
Page 7: Table Of Contents
Table of Content Environment setup.....................08 Introduction ........................09 Hardware installation ....................12 Installation Konnect+ networking USB server Utility..........13 Installation Konnect+ networking USB server featured functions......20 Connect automatically for printing ................20 Connect this device when application starts..............21 Auto disconnect printer/MFP/storage device .............22 Create a shortcut on your desktop ................24 Device properties.......................25 Control menu ......................26 Configuration with the utility..................27...
Page 8: Environment Setup
Environment Setup The picture above depicts a sample household network USB device use environment. To setup the devise, simply plug it into the home/office network under the same router and power it on. Then it could be shared by all the computers on the same network...
Page 9: Introduction
Introduction Thanks you for purchasing this Konnect+ networking USB server that allows any networked computer to share a USB printer. USB devises. It complies with USB 2.0 specifications and is backward compatible with USB 1 (and provided an auto-sensing Ethernet port that works with either 10Base-T, 100Base-T or 1000Based-T networks. This until also supports multiple protocols and multiple operating systems.
Page 10 System requirements: • Windows 2000/XP/2003/VISTA, Windows 7 • Mac OS X 10.2 or later (Only support printer) • Device with a USB connection. Features • Easily connect your USB printer, USB devices to a network • Allows multiple computers to share USB printer, USB device on the network •...
Page 11 Notice: 1. Do not use the network USB server in the extreme hot, cold, dusty or humid environment. 2. Prevent friction with objects or it may lead to surface abrasion or hardware damage. 3. Avoid the hub falling down from a high place, or it may damage the hardware inside. 4.
Page 12: Hardware Installation
Hardware Installation 1. Make sure your network is working properly. 2. Connect the USB printer or other USB devices to the USB ports on the network USB server 3. Make sure all the driver of the devices connected with the network USB server is installed on your computer properly, 4.
Page 13: Installation Konnect+ Networking Usb Server Utility
Installation Konnect+ networking USB server Utility: • To start the installation, please double click Setup.exe. • And then click USB Server for Windows from auto run setup cover page. • The installer will automatically install the program. • When done, Select YES, I want to restart my computer now and click FINISH to reboot your computer.
Page 14 • After the installation completes, a shortcut will be created on your Desktop. System Firewall When you start the program for the first time, your windows OS will prompt to firewall Access. Please make sure you unblock the software or grant it access, otherwise the program will not work correctly.
Page 15 Main Dialog Box Once you have start up the program and grant it access through the firewall, you will see this main dialog box. The main dialog box is considered of Control Menu (File, Option, View and Help), a tree view in the middle that displays a list of all the server and devices discovered on the network, a Search button to get the current status of all USB Servers and devices, and a...
Page 16 Accessing a USB Device To connect to a USB device, please select it on the tree view and click on Connect Device button or double click on it. This process might take a few seconds up to a minute, depending upon complexity of the device.
Page 17 Search When you are in need of knowing the status of all the servers and devices immediately, use the Search button. Clicking on the Search button triggers the program to immediately poll the network for the status of all the servers and devices.
Page 18 Clicking on YES to release the device if you are done, click on Cancel if you are still using it. The requesting user will see this message if the occupying user releases the device: Then the device will be free to connect: If the occupying users click on CANCEL when received the request, requesting user will see this message instead:...
Page 19 System Tray Icon When minimized to system tray, the Konnect+ networking USB server Utility will still be running. Right Click on the icon brings up a menu of operations you can still do. As you can see, you can still do Search and Connect. Search is the same but to connect a storage device, move your mouse to the “Connect”...
Page 20: Installation Konnect+ Networking Usb Server Featured Functions
Konnect+ networking USB server Featured Functions Connect Automatically for Printing This is another one of very convenient functions. What this function does it that when you send a printing task to the printer, it detects this printing task and AUTOMATICALLY connect this printer to print out the document.
Page 21: Connect This Device When Application Starts
Connect this device when application starts : When enabled, this function automatically connects the target device 15 seconds after the application starts running. If you are using a USB hub or the server has a build-in HUB (4-port USB server has a build-in hub), the device won`t be automatically connected if you switch to another port.
Page 22: Auto Disconnect Printer/Mfp/Storage Device
Auto Disconnect Printer/MFP Storage Device These functions are there to prevent the case when one user connected a Printer or Storage device but forget to disconnect when he/she is done with the device. When these two functions are enabled, you will see below message when you connect a Storage device or a printer:...
Page 23 When the idle time is up and the device has been disconnected, you get another notification: NOTE : This function might not work with Storage device such as pen driver/flash driver. These devices tend to periodically (on a millisecond base) communicate with the OS even when the user is not reading data from it or writing data to it.
Page 24: Create A Shortcut On Your Desktop
Create Shortcut on your Desktop This function creates a shortcut on your desktop that, when double clicked start up an application and connects a targeted device at the same time. This function is particularly useful when the functions or one of the functions of the targeted device must work with a specific application such as a multi- Functions printer and the photo/picture scanning utility normally if you want to scan with a scanner...
Page 25: Device Properties
Device Properties Clicking on the Device Properties to bring up the Device property dialog box Device Properties dialog box displays information of the USB Device if the device is occupied it also displays the occupying PC Name and the IP of the PC occupying it.
Page 26: Control Menu
Control Menu File-the Quit function exits the program Options > Language: you can change the utilities Language with this option the default language would be the same as your systems language Setting Server: same function as the setting Server option on the server icon right click menu Run USBS server When PC Start UP: this utility automatically runs when your system start up.
Page 27: Configuration With The Utility
Configuration with the Utility Konnect+ networking USB server utility provides some advanced setting function for users to configure the Device to better fit their needs. To bring up the configuration dialog, please RIGHT CLICK device you would like to configure like this. And select the Setting Server option.
Page 28 Server Name: this field allows you change the server name change it whatever you want USE DHCP: when this field is checked, your server acquires IP address automatically. Uncheck it and you can enter IP address automatically NOTE: you can apply this function to a server under different network segment.
Page 29: Configuration With Web-Based Ui
Configuration with Web- based UI We allow the users to configure the setting the USB server via the web-based UI select the target server on the tree view and then click on the Open web page button or the same option on the right-click menu of server Icon, to bring up web-based configuration UI.
Page 30 Networking information/setting This page displays the current network setting of the server and provides links to The pages where you can perform special Action you can change the network Setting according to your need. However, please note that if you would like to give this server a static IP, please disable the DHCP option.
Page 31 Change Password Clicking on this link takes you to the Password update page below. To change the password, you must enter Current password, input new password and Re-input new password for confirmation and then click on Submit if you are setting the password for the first time you don't have to provide current password.
Page 32: Removing Konnect+ Networking Usb Serverutility From Your System
Removing Konnect+ networking USB serverUtility From your System To uninstall Konnect+ networking USB server Software please go to Control panel > Add or Remove Programs Then please browse through the program list and find Konnect+ networking USB server program Please select it and click on the Change/Remove button.
Page 33: Mfp-Printer/Lpr Printer Compatibility List
MFP-Printer / LPR Printer Compatibility List...
Page 37 N/A : This USB device does not have this function:- NOT tested (Only a certain function of this devices was test) NS: This function is not support Remark: 1. ** Devices compatible should be the same on both windows VISTA and 7, except for the case that device does NOT support the 2.
Page 38 Warranty Clause Onnet Technologies India Private Ltd Terms & Conditions of Warranty Definitions : Unless the context otherwise requires, the following terms would have the prescribed meanings: OTPL : Onnet Technolgies India Private Limited, a company duly registered under the Companies Act having its Registered Office 5, Celler Silicon Tower, B/h Samartheswar Mahadev, Nr.
Page 39 OTPL's Warranty for the Product(s) is only against any defects in the manufacturer's material or workmanship, which provide for the repair of the defective Products(s). OTPL's warranty does not cover against any accidental damage, loss, acts of god, or misuse /abuse of the Product(s) or any other event not attributable to the manufacturer's material or workmanship or manufacture of the product.
Page 40 • The warranty does not cover the replacement of the product(s). • Warranty does not cover warranty of functionality of the Product(s) • Warranty does not cover damage caused due to act of God & force majeure events including but not limited to fire or water damage, electrical disturbances etc.
Page 41 Limitation Of Liability OTPL makes no other express warranty either in writing or otherwise and expressly disclaims all warranties and conditions not stated in this limited warranty. OTPL does not warrant that the operation of the product(s) will be uninterrupted or error-free. To the extent allowed by the Indian laws, OTPL disclaims all implied warranties or conditions, including any implied warranties or conditions of merchantability, merchantable quality, and fitness for a particular purpose.
Page 42 FF3,Mardia Plaza, CG Road, Ahmedabad, Gujarat, India. Tel :+91 79 2656 6198, Fax :+91 79 26566333. www.onnettechnologies.com...
