Vitrum On-Off Wireless Installation And Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

EN
H O M E
C O N T R O L
Vitrum On-Off Wireless
INSTALLATION AND OPERATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the On-Off Wireless and is the answer not in the manual?

Questions and answers

Related Manuals for Vitrum On-Off Wireless

Summary of Contents for Vitrum On-Off Wireless

  • Page 1 H O M E C O N T R O L Vitrum On-Off Wireless INSTALLATION AND OPERATION...

  • Page 2: Table Of Contents

    1. Electrical connections ... 4 2. Positioning the glass decor panel . . . 8 3. Vitrum is intelligent ... . 9 4. Configuration of the type of switch 12 5.

  • Page 3: Before Starting

    Do not install Vitrum in the vicinity of sources of heat or in conditions of high humidity. IMPORTANT: Fit a rapid-acting fuse with a high switching capacity that is...

  • Page 4: Electrical Connections

    “C1...C3”. the device may be set to operate as a “Button” as well as a “Switch”. on-off Wireless on-off Wireless 1 channel EU 2 channels EU...
  • Page 5 Wireless on-off Wireless 3 channels EU 1 channel BS on-off Wireless on-off Wireless 2 channels BS 4 channels BS...
  • Page 6 the circuit diagram below shows how to connect without the use of the jumper in order to replace a button which controls a step relay for control of an existing lighting system: Step Relay Button to replace...
  • Page 7 IMPORTANT After connecting, check that the wires are correctly positioned inside the wall-mounting box. When securing Vitrum to the wall-mounting box, use the screws supplied but do not use electric screwdrivers, as these may exert excessive force which might damage the product.

  • Page 8: Positioning The Glass Decor Panel

    POSITIONING THE GLASS DECOR PANEL in order to refit the glass panel correctly, ensure that the four plastic tabs on the panel are in perfect alignment with the anchor holes. When the glass panel tabs are aligned with the holes, press the four corners of the glass panel evenly until it is fully inserted into the wall-mounting box.

  • Page 9: Vitrum Is Intelligent

    Vitrum units, to construct scenarios, and to control lights using a remote control unit. if you connect Vitrum into a pre- existing z-wave net working with third parts devices, please refer to instruction and procedure of your remote control.
  • Page 10 Place the HOME MASTER remote handset near the Vitrum unit to be included in the network. touch any of the keys on Vitrum to include the unit in the home wireless network. Vitrum indicates that it has been connected to the network...
  • Page 11 NOTE A Vitrum unit cannot be added to the network if it has already been included in a different network. in this case, it is necessary to perform the factory reset procedure > see Paragraph 6.

  • Page 12: Configuration Of The Type Of Switch

    CONFIGURATION OF THE TYPE OF SWITCH Vitrum is configured to operate as a normal on/oFF switch (i.e. to ‘toggle’ the on and oFF status with each touch). the individual channels can be configured as simple buttons. to do so, proceed as follows: •...
  • Page 13 • Press each of the Vitrum touch keys briefly to select the desired operating mode. FLASHING BLUE FLASHING RED Switch Button Each time the touch key is pressed, the cyclic status is ‘toggled’: Switch Button Switch -> -> …...
  • Page 14 Vitrum returns to normal operation after 12 seconds of inactivity or if the two service touch keys indicated by the yellow arrows in the figure below are pressed briefly (0.5 seconds). IMPORTANT the default operating mode is “Switch”.

  • Page 15: Advanced Functions

    ADVANCED FUNCTIONS: CREATION OF CONTROL LOGIC on all Vitrum Wireless units, it is possible to create control logic processes that associate the button on one Vitrum module to other buttons on OTHER Vitrum modules (up to a maximum of five). Every Vitrum Wireless on-off supports a number of groups equal to the number of the device’s channels (=device’s buttons);...
  • Page 16 • Press the button corresponding to the button/channel of the Vitrum unit to which the lights to be controlled are physically connected. the lED corresponding to the selected button/channel will flash magenta until the ‘association’ process has been completed. the user may select up to a maximum of...
  • Page 17 • Press the touch key on the Vitrum unit from which to control the lights connected to the buttons/channels of the Vitrum device(s) that have been selected previously. in this case, too, the corresponding lED will light magenta.
  • Page 18 Associations are possible only between separate Vitrum modules. It is not possible to control more than one channel of a Vitrum device using a single touch key on the same Vitrum unit. A touch key on a Vitrum device can be associated with a maximum of 5 touch keys on other devices.

  • Page 19: Factory Reset

    FACTORY RESET Proceed as follows to reset the Vitrum unit to the original factory settings: EXCLUSION from the home network using the hoME MAStER remote handset: “EXC” • Press on the hoME MAStER remote handset and wait until the yellow lED lights.
  • Page 20 • Vitrum will flash red three times and sound an acoustic signal to indicate that the original factory setting has been restored. FACTORY RESET a.using the hidden button • Remove the Vitrum unit from the wall-mounting box. • Press the hidden Factory Reset button and hold down for at least 3 seconds.

  • Page 21: Supervision

    , you will find that the “identification” function featured by every or iPad ® Vitrum unit is extremely useful. “Identification” status is indicated when all the illuminated rings light Magenta and begin to flash. this functional status is created directly by the supervision app as soon as the corresponding command is entered.

  • Page 22: Compatibility

    Vitrum wireless units. in this way, your system can easily be extended to operate with different applications and thus to adapt to your specific needs.

  • Page 23: Main Technical Specifications

    20 mt 20 mt 20 mt Configurable operating mode: switch or hold-down button Protection Rating iP 40 iP 40 iP 40 iP 40 * Resistive loads only. to discover further functions and products by VitRUM please visit our site: www.vitrum.com...
  • Page 24 H O M E C O N T R O L Think Simple SpA Head Office viale lino Zanussi, 3 tel +39 0434 516 216 33170 Pordenone Fax +39 0434 516 230 Sales Office corso Garibaldi, 86 tel +39 02 655 600 29 20121 Milano Fax +39 02 454 982 95 www.thinksimple.it...
