Handy Tech Modular Evolution 88 User Manual

Braille keyboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U s e r M a n u a l
M o d u l a r E v o l u t i o n
Version 1.2
Horb, December 2007
Handy Tech Elektronik GmbH
©
All Rights Reserved
Handy Tech Elektronik GmbH; Brunnenstraße 10; 72 160 Horb; Germany
Phone: +49 7451 55 46 0; Fax: +49 7451 55 46 67
E-Mail:
inf o@handytech.de
- Internet:
www.handytech.d e

Advertisement

Table of Contents
loading

Summary of Contents for Handy Tech Modular Evolution 88

  • Page 1 Version 1.2 Horb, December 2007 Handy Tech Elektronik GmbH © All Rights Reserved Handy Tech Elektronik GmbH; Brunnenstraße 10; 72 160 Horb; Germany Phone: +49 7451 55 46 0; Fax: +49 7451 55 46 67 E-Mail: inf o@handytech.de - Internet:...

  • Page 2: Table Of Contents

    B4] (Chord B) ......................12 3.4.1 Table of Key Commands for Controlling the PC ....... 13 Configuration Mode .................. 15 OPERATIONS SETTINGS FOR HANDY TECH BRAILLE DISPLAYS..... 17 Connection....................17 ATC ......................18 Status Cells ....................18 Fast Keys ....................19 Repeat Keys ....................
  • Page 3 H a n d y T e c h Modular Evolution General E lektronik G m bH ACTIVE TACTILE CONTROL (ATC) ..............21 ATC Assistant for Reading or Learning ..........22 Tips for Utilizing ATC to Learn Braille ............. 23 Tips for Utilizing ATC for the Experienced Braille Reader ....

  • Page 4: General

    The Modular Evolution has been developed and tested with great care. However, if you have any ideas or suggestions for improvements, please do not hesitate to contact your Handy Tech customer service representative or write to us at Idee@handytech.de. Your opinion is very important to us.
  • Page 5 Past the Braille modules is the Modular Evolution's base for attaching a modular keyboard or a modular Braille keyboard. If your model is the Modular Evolution 88, a modular numbers block can also be snapped on to either the left or right side of the unit. The 16 keys on the modular numbers block are arranged in four rows of four keys each.

  • Page 6: Terms And Stylistic Conventions Used In This Manual

    H a n d y T e c h Modular Evolution General E lektronik G m bH Top row Second row Third row Bottom row Move your hand along the right side of the housing towards the back, and you will feel the main power switch.

  • Page 7: Installation

    You can attach either a standard PC keyboard or a Braille keyboard to your Modular Evolution, as desired. In addition, the Modular Evolution 88 also features an option for attaching a 16-key numbers block. These components are mated securely to the...

  • Page 8: Modular Evolution 64

    2.3.2 Modular Evolution 88 The top face of the Modular Evolution 88 housing includes a recessed keyboard base with integrated snap-on connections on both the left and right side. You have the choice of attaching the keyboard on either the left or the right side. Position the...

  • Page 9: Technical Specifications

    USB driver first, as described above. Technical Specifications In the following you find the technical specification for the components of the Modular Evolution 64 and 88. 2.5.1 Modular Evolution 88  88 Braille elements  704 (88x8) ATC sensors  2 navigation keys ...

  • Page 10: Modular Braille Keyboard

    H a n d y T e c h Modular Evolution Installation E lektronik G m bH 2.5.4 Modular Braille Keyboard  8 Braille keys (P1 to P8)  2 space keys  Function keys F1 to F12, Escape key, Numlog, ScrLog, Print ...

  • Page 11: Start-Up

    Please make sure that your Modular Evolution is properly connected and switched on, and that the appropriate Braille display driver by Handy Tech is installed, before starting up the screen reader program (see Section 2.2). As a rule, the screen reader will display the selected position within the active window on the Braille display.

  • Page 12: Braille Input With The Modular Evolution's Function Keys [L + B1 + B3 + B4] (Chord B)

    Evolution. If you want to utilize this function, you will need your screen reader's most recent driver for Handy Tech Braille systems. We recommend installing the driver that was included with your software package (please refer to Section 2.2, Software Installation).

  • Page 13: Table Of Key Commands For Controlling The Pc

    H a n d y T e c h Modular Evolution Start-Up E lektronik G m bH  Initiating the Enter key.  Initiating the Escape key.  Initiating the Backspace key.  Initiating the Delete key.  Moving the cursor. ...
  • Page 14 H a n d y T e c h Modular Evolution Start-Up E lektronik G m bH PC Key(s) Chord Emulated on the Modular Commands Evolution by Ctrl + Shift + Escape TLC + L + 1 5 7 or TLC + L + B1 + B4 + B6 Shift + character Chord s...

  • Page 15: Configuration Mode

    H a n d y T e c h Modular Evolution Start-Up E lektronik G m bH PC Key(s) Chord Emulated on the Modular Commands Evolution by character followed by character Lock/unlock Screen Reader L + R + 2 3 4 8 or L + R + B2 + B3 + B5 + B8 Configuration Mode Configuration mode can be activated by holding down [3 7] or [B1 + B2] for longer...
  • Page 16 H a n d y T e c h Modular Evolution Start-Up E lektronik G m bH minutes. If a value of higher than 120 is entered a period of 3 minutes will automatically be set. Text messages language in configuration mode: Text messages can be provided in either German or English.

  • Page 17: Operations Settings For Handy Tech Braille Displays

    Settings window, activate the [1 8] or [B4 + B8] keys simultaneously. As an alternative, you can also use the [B12] key on the Modular Evolution 88's numbers block. The Settings window can also be started up from the Start menu, under "Programs –...

  • Page 18: Atc

     When changing device or interface: The pop-up box appears only if you have connected a different Handy Tech Braille display to the PC, or if you have connected the same Braille display to a different interface on your PC.

  • Page 19: Fast Keys

    H a n d y T e c h Modular Evolution Operations Settings for Handy Tech Braille Displays E lektronik G m bH position inserted between the status modules and the remaining positions on the Braille line. The blank element has no function.

  • Page 20: Repeat Keys

    In the field “Driver properties” the type of screen reader, you are using is listed, as well as the version of your driver. At “Your dealer” you get the contact details of your Handy Tech dealer with postal address, telephone number and E-mail.

  • Page 21: Active Tactile Control (Atc)

    A certain action can be assigned to each of these four behaviors. There are two customizable modes for the so-called assistant functions. The two modes are "Reading" and "Learning". The tab "ATC" in the Settings menu of the Handy Tech Braille system is used to specify what your Modular Evolution and your screen reader should do when each reading behavior is detected, depending on whether you selected either Reading or Learning mode.

  • Page 22: Atc Assistant For Reading Or Learning

    H a n d y T e c h Modular Evolution Active Tactile Control (ATC) E lektronik G m bH monitor at a later time, you can go into this menu and activate the button "Start monitor now". If you check the "Generate protocol" check box at "Reading protocol", everything you enter or read on the Braille display will be logged in a protocol file as of the moment when you click "OK"...

  • Page 23: Tips For Utilizing Atc To Learn Braille

    In the default setting, the Assistant Mode is "Reading". Under the tab ATC in the Settings window for Handy Tech Braille displays, change the Assistant Mode to "Learning". Now, after you have read an entire word, the word will be spoken as speech output.

  • Page 24: Tips For Utilizing Atc For The Experienced Braille Reader

    German words, correctly, you can first switch your speech output to German. Then, set the Assistant Mode under the tab ATC in the Settings window for Handy Tech Braille displays to "Learning". We recommend setting a speech output delay of approximately 2000 milliseconds, i.e., 2 seconds.

  • Page 25: Atc-Monitor Settings

    H a n d y T e c h Modular Evolution Active Tactile Control (ATC) E lektronik G m bH With "reading normal" we recommend to use "say character attribute changes". Now you can easily follow attribute changes at the reading position without a hassle switching to attribute information.

  • Page 26: Operating A Pc With A Screen Reader

    H a n d y T e c h Modular Evolution Operating a PC with a Screen reader E lektronik G m bH Operating a PC with a Screen reader The so-called screen reader programs' task is to output the information displayed on a PC monitor screen, converting it into speech and Braille for blind users.

  • Page 27: Screen Reader Under Windows, Example Jaws

    H a n d y T e c h Modular Evolution Operating a PC with a Screen reader E lektronik G m bH Screen reader under Windows, Example JAWS The functionality of JAWS for Windows is so extensive that only the basic functions for operating the Braille display can be described in brief in this section.
  • Page 28 [B11] or [B3 + B8] / [2 8] Toggle between 6/8 dot Braille. [B12] or [B4 + B8] / [1 8] Handy Tech configuration dialog (as of Handy Tech JAWS Driver version 3.x) [B13] or [B5 + B8] / [4 8] Toggle between focused text on Braille display/same text as on screen.

  • Page 29: Screen Reader Under Windows, Example Hal/Supernova

    H a n d y T e c h Modular Evolution Operating a PC with a Screen reader E lektronik G m bH m [B2 + B4 + B5] / [1 3 4] Alternative for activating the menu bar [B2 + B3 + B5] / [2 3 4] Start menu [B2 + B3 + B6] / [2 3 5] Toggle 6/8 dot Braille...

  • Page 30: Overview

    [B11] or [B3 + B8] / [2 8] Eight dot / six dot Braille [B12] or [B4 + B8] / [1 8] Handy Tech configuration dialog [B13] or [B5 + B8] / [4 8] Expand gap on/off [B14] or [B6 + B8] / [5 8]...

  • Page 31: Screen Reader Under Windows, Example Window-Eyes

    H a n d y T e c h Modular Evolution Operating a PC with a Screen reader E lektronik G m bH By entering letters in Braille, you can in addition input the so-called mnemonic commands that are listed below: % [B2 + B3 + B4 + B5 + B6 + B7] Activate system control / [1 2 3 4 5 6]...

  • Page 32: Overview

    E lektronik G m bH 6.3.1 Overview Your Modular Evolution, just like all the other Handy Tech Braille displays, is supported by Window-Eyes. The following table provides an overview of Window- Eyes commands that can be entered with the control keys on the Braille display. We have not included an exhaustive description of each of the functions, because they are already contained in the Window-Eyes manual.
  • Page 33 H a n d y T e c h Modular Evolution Operating a PC with a Screen reader E lektronik G m bH [B5 + B7] / [4 6] [B2 + B4] / [1 3] Shift Tab [B3 + B4 + B5 + B6] / [1 2 4 5] Grade 2 on/off m [B2 + B4 + B5] / [1 3 4] Alternative for activating the menu bar...

  • Page 34: Important Information

    200 V. The device contains no user-serviceable parts. In the event of a defect, please contact your dealer, or Handy Tech directly. Only an authorized Handy Tech dealer has permission to service the device.

  • Page 35: Handling The Braille Display

    H a n d y T e c h Modular Evolution Important Information E lektronik G m bH Avoid switching your Braille system on immediately after moving it from a cold room into a warm environment. Under unfavorable conditions, condensation can damage the device.

  • Page 36: Warranty

    Please always consult this handbook first if you encounter difficulties. All procedures are described here. If this does not solve your problem, you have the option of reviewing possible solutions in the download area on Handy Tech's web page, www.handytech.de.
  • Page 37 H a n d y T e c h Modular Evolution Important Information E lektronik G m bH Page 37...

  • Page 38: Copyright Notice

    Copyright Notice E lektronik G m bH Copyright Notice All rights reserved, copyright Handy Tech Elektronik GmbH. No portion of this manual may be reproduced in any form without prior written permission from Handy Tech Elektronik GmbH. Windows is a registered trademark of Microsoft, Inc.

  • Page 39: Appendix

    H a n d y T e c h Modular Evolution Appendix E lektronik G m bH Appendix Guidance manufacturer's declaration electromagnetic emissions Guidance and manufacturer's declaration - electromagnetic emissions The Braille display is intended for use in the electromagnetic environment specified below. The customer or the user of the Braille display should assure that it is used In such an environment.

  • Page 40: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    H a n d y T e c h Modular Evolution Appendix E lektronik G m bH it is recommended that the 70 % U 70 % U Braille display be powered (30 % dip in U (30 % dip in U from an uninterruptible For 25 cycles For 25 cycles...

  • Page 41: Recommended Separation Distances Between Portable And Mobile Rf Communications Equipment And The Braille Display

    H a n d y T e c h Modular Evolution Appendix E lektronik G m bH NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.
