INSTRUCTION MANUAL
SAFETY INSTRUCTIONS
33 kV Portable Voltmeter
Double test light
AND
FOR
and
Advertisement
Table of Contents
Summary of Contents for Maeraj PHV-20
-
Page 1: Safety Instructions
INSTRUCTION MANUAL SAFETY INSTRUCTIONS 33 kV Portable Voltmeter Double test light WARNING: Improper and unsafe use of this device can result in death or serious bodily injury! This manual contains important information about product safety. Please read and understand this manual before operating the device. Please keep this manual available for others before they use the device. - Page 2 Instruction Manual Portable HV Voltmeter Double Test Light Thank you for purchasing this 33kV Portable Voltmeter. WARNING • Before using, read these user's manuals of this Portable HV Voltmeter to ensure correct usage through understanding. After reading, store them in a safe place for future reference.
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION Safety Warnings and Precautions WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury. Save all warnings and instructions for future reference. 1. Electrical shock can cause death or injury! NEVER TOUCH exposed conductors of electricity. 2. -
Page 4: Operating Instructions
13. Do not operate meter if under the influence of alcohol or drugs. Read warning labels on prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If there is any doubt, do not operate the meter. 14. - Page 5 3. Push ENT and enter measurement menu. By connection of the two components, the green LED starts flashing (handshaking) and “less than 1 kV” will appear in voltage section. 4. The distance between the transmitter (probe) and the receiver is 21m at most. 5.
- Page 6 IV. Setting time and date Time and date displays on the screen, so the time will be saved as well when a measured value is saved. Setting time: Go to setup icon on the main page using the dial, and press the ENT to enter. There are two options on this page: a.
- Page 7 On “data management” page, choose “view data” and press ENT. The data of the first measurement will display on the screen. Scroll down to see the other saved data. The data include the location – entered at the time of saving, time and date of measurement. Erase data On “data management”...
