Summary of Contents for TICCTV T72

  • Page 1 HD COMBINE TESTER User Manual...

  • Page 2: Table Of Contents

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual Table of Contents 1. Safety Information…………………………………………………………………… 3.6 Analog Video Generator……………………………………………………………… 2. HD Combine Tester Introductions………………………………………………… 3.6.1 Analog Video Generator Screen…………………………………………………… 2.1 General Introduction…………………………………………………………………… 3.6.2 Connection of Analog Video Generator…………………………………………… 2.2 Product Highlights…………………………………………………………………… 3.7 RJ45 Cable TDR Test *………………………………………………………………...

  • Page 3: Safety Information

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 1. Safety Information 2. HD Combine Tester Introductions When using the instrument, be sure to comply with local electrical rules. Avoid ◆ 2.1 General Introduction hospitals, gas stations, and other places where electrical use is not allowed. This device is designed for video surveillance installation and maintenance.

  • Page 4: Product Functions

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 2.3 Product Functions 2.3.6 Video Snapshot, Recording and Playback Under the condition of video play via ONVIF testing and analog video testing (including 2.3.1 POE power and POE Powered, 12V/2A Output. SD and HD), this function can take snapshot and recording.

  • Page 5: Device Portions And Parts

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 2.5 Device Portions and Parts Power Indicator: Lights up when power on Data Transmission Indicator: Red light flashes when data is be- ing transferred Charge Indicator: Red when charging, off when fully charged Battery Level Icon: Indicates battery level Displays current function mode and system time Title Bar...
  • Page 6 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual TOP side TOP side LED Torch Light Analog Video Input BNC Connector Analog Video Output BNC Connector Left side Network Port 1 (Blue) with POE Power Supply Left side Right side POE Power Supply Indicator (Orange) Network Port 1 Link and Data Indicator (Green) Network Port 2 (Green), with POE Power Accept;...

  • Page 7: Operation Instructions

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3. Operation Instructions 3.2 Lanyard Wearing Users can choose to install the lanyard. The lanyard can help handling the device, 3.1 Installing and Recharging the Battery prevent dropping the device, avoid damage to the device, and prevent loss. The tester device uses a rechargeable lithium-ion polymer battery.

  • Page 8: Onvif Test

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual Ethernet Data Flow Monitor 3.4 ONVIF Test This icon shows the current Ethernet traffic flow. The ONVIF test function is designed to act as a 3 step trouble shooting guide. It combines Ethernet tests, IP settings, camera discovery, camera authorization, video ←...
  • Page 9 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual B. Operation 2 Connect to POE Switch and Charge the Internal Battery at the Same Time. Use a RJ45 cable to connect the POE switch and tester network port 2 ( green ). The 1.

  • Page 10: Onvif Test Step 2: Discovering Cameras

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3 Static IP Mode When inputting, character ‘d’ and symbol ‘.’ need no switching..Need Switching, used key, After inputting, press to be sure. This mode is suitable when connecting a camera or network that uses a static IP. When the input is complete, press to confirm.
  • Page 11 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual In this interface, pressing will clear the camera list and restart the discovery process. 3.4.2.3 Viewing Camera Video Snapshot and Video Use the arrow keys to select a camera in the left side list. After 1 to 3 seconds, a Some cameras may not respond the ONVIF discover request, or cannot reply due to video snapshot from the corresponding camera will show on the right for quick user different IP sub-net settings.
  • Page 12 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual Used the flip keyboard type in the user name and password, then press key to 3.4.2.5 Camera Settings authentication. On the interface of authentication, press keys to enter password Press the key to enter the camera settings screen.

  • Page 13: Onvif Video Test

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual When finished setting, press the key to confirm. The tester will send new settings to 3.4.3.2 ONVIF PTZ Control the camera. If the camera accepts the new settings, the setup successful prompt will Pressing the key will switch to full screen video display mode, and all display show.
  • Page 14 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.4.3.4 Video Capture and Video Video Recording Video Capture In the Image display Interface, Press “Z” key to start recording the current broadcast Video, Press “Z” key again end of the video recording. Video recording end will show In image display interface, Press “A”...

  • Page 15: Connecting To Analog Camera

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.4.3.5 ONVIF Video Digital Zoom 3.5.2 Analog Video Test On video display screen, pressing the 1 key will digitally zoom in, while pressing the Q Press the key to select analog video test. Wait 2 seconds, or press the arrow key will zoom out.

  • Page 16: Full Screen And Portion Display Of Analog Video Image

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.5.3 Full Screen and Portion Display of Analog Video Image 3.5.5 HD Coaxial PTZ Control After entered the analog video test function, press the key to enter or exit full On the analog video screen, pressing the key will bring up the RS485 PTZ setting screen mode.

  • Page 17: Rs485 Ptz Control

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual Use the RS485 cable to connect the PTZ RS485 wire then use 3.5.6 RS485 PTZ Control keys to control the PTZ. On the analog video screen, pressing the key will bring up the RS485 PTZ setting Call some special preset number, can used the ball machine OSD menu function.

  • Page 18: Connection Of Analog Video Generator

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.6.2 Connection of Analog Video Generator As below : Open -9.3dB/100m Length or break point -9.3dB/100m Cable attenuation -10.3dB/100m 1 9 9 -9.4dB/100m Short A. Network Port 1 Icon: A tape measure icon flashes on the screen when a cable is being tested.

  • Page 19: Network Analysis ( Network Tools )

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.8.1 Ethernet Sniff Operation When a cable is perfectly terminated due to really weak reflection from the cable end and there may be stronger reflection from other cable junction, then the measurement result may be shorter than actual cable length.

  • Page 20: List Sub-Net Function Operation

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.8.2 List Sub-Net Function Operation 3.8.3.2 Use Method: To use the list sub-net function, IP and mask should be setup, and the subnet mask To use the ping function, IP address, masks and destination are needed. If the destination should be 24bits wide (that is the sub-net size of 256 devices).

  • Page 21: Record Playback

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.8.3.3 Save Report 3.9 Record Playback ( HD Coaxial can not support video ) In Ping function can save the test report. Press the SCR button to generate the report. The tester can take snapshots or record input video and save them to internal storage.
  • Page 22 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual In this interface, you can operate the folder: Press keys to view the folder up and down. When more files, press the keys can be turned to view the folder. Press to delete the folder, press to delete, press other keys to cancel.

  • Page 23: Digital Multimeter

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual In the partial magnification mode, an enlarged scale legend is displayed at the bottom To use the multimeter function, please press button repeatedly or combine use of right of the screen. Figure : “Up”/ “Down”...
  • Page 24 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual ii. Current testing Connect the probe as shown in b.3 Please cut off the power of Target circuit first. Cut off the target wire also, connect the red and black probe to the test point in series connection. And turn on the power of the target circuit.
  • Page 25 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual iii. Resistance Testing Note: The capacitor should be tested by alone, instead of installed in a circuit. Otherwise, it may get This function can test resistor or circuit’s resistance value. a wrong testing result or cannot get the data readout.
  • Page 26 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual g) Data Recording Function Note: The circuit conductive or open is a relative concept. User should judge according to particular The device has data recording function.Press SCR button to start recording. The circuit and measured value, instead of judge it base on the buzzer.
  • Page 27 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual i) Technical Data-sheet / Parameter Table DC Voltage, DC Current, 5 reading/s Data rate Resistance measurement, Measuring Range and Accuracy Diode testing, Conductivity Reading Minimum Item Range Accuracy 2 reading/s AC Voltage, AC Current testing Range Resolution...

  • Page 28: Data Monitor

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.11 Data Monitor 3.12 Device Setup This function can be used to receive and display data on the RS485 bus while maintaining This function allows users to setup some system parameters. USB storage and software the front Dome camera.
  • Page 29 HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 3.12.1 Setting Up Automatic Power Off Time 3.12.6 System Upgrade Select the auto power off item, and adjust its settings using the keys. Automatic The tester software can be upgrade online. power off can be set between 5 minutes ( minimum ) and 60 minutes ( maximum ).

  • Page 30: Audio Test

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual If the network is using DHCP, the tester will automatically detect the IP settings. Use a USB mini-B cable to connect the tester to a computer. Further operation is the Otherwise, the IP settings should be entered by the user.

  • Page 31: Specifications

    HD COMBINE TESTER User Manual HD COMBINE TESTER User Manual 4. Specifications Model HD Combine Tester Model HD Combine Tester IPC Test TDR RJ45 Cable Test Protocol ONVIF, RTSP, RTP RJ45 Cable Test Test the length of four wire pairs. Maximum 200 meters, the resolution of 1 meter 10/100/1000M Ethernet link test, loop detect, DHCP client and server Ethernet Test Power...
