Dimensions - Mityvac MV7201 User Manual

Dipstick
Tubes
Model MV7201 Service Items
Item Description
1 Vacuum tube Kit
2 Handle kit
3 Valve Kit *
4 Tube Connector Kit **
5 Pump Assembly Kit ***
6 Base Kit ****
* Consists of three tubes, three 8 mm connectors
** Consists of three 8 mm connectors and three 10 mm connectors
*** Consists of two 8 mm connectors, two tubes and pump assembly
**** Consists of base and foot bracket
***** Consists of top and overfill float.
Page Number - 2
To order call 1-800-548-1191 or visit www.partdeal.com - info@partdeal.com
12.38 in.
314,4 mm
approximately
4
1
12
x 6 pieces
2
8
4
Main
Suction
Tube
3
4
5
11
6
Part No. Item Description
822559 7 Evacuator Top Kit *****
822561 8 Pump Strap Kit (Quanity 2)
822563 9 Expandable Plug Kit
822566 10 Top Seal Kit
822572 11 Tube Connector with Check Kit
822574 12© Field Service Kit
13© Replacement Tube
9.25 in.
125, 7 mm
approximately
4,12
3, 13
9
10
12
7
Part No.
822576
822578
822593
822821
822998
MVM9000
801671
23.92 in.
607,5 mm
approximately
Form 801672F
