DOUBLE
HINGED DOOR
15'
19'
WORKSHOP
1015HDDA, 1019HDDA - 1.78m WALL HEIGHT
1015HDDA2, 1019HDDA2 - 2m WALL HEIGHT
OPTIONAL SINGLE HINGED DOOR INSTRUCTION MANUAL INCLUDED
(AvAILAbLE IN AUSTRALIA ONLy)
TRECO SHEDS ARE MANUFACTURED TO COMPLY WITH ALL AUSTRALIAN STANDARDS
TR1519HDD
www.oldfields.com.au/treco/index.htm
- 08/05/07
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Oldfields Treco
- Page 1 15’ 19’ WORKSHOP 1015HDDA, 1019HDDA - 1.78m WALL HEIGHT 1015HDDA2, 1019HDDA2 - 2m WALL HEIGHT OPTIONAL SINGLE HINGED DOOR INSTRUCTION MANUAL INCLUDED (AvAILAbLE IN AUSTRALIA ONLy) TRECO SHEDS ARE MANUFACTURED TO COMPLY WITH ALL AUSTRALIAN STANDARDS TR1519HDD www.oldfields.com.au/treco/index.htm - 08/05/07...
- Page 2 Optional Single Hinged Door they are available from your local Treco Agent. If your shed contains the Optional Single Hinged Door Please read the installation instructions on page 27 bEFORE starting construction of the shed.
- Page 3 INSTALLATION ADvICE TOOLS REQUIRED All the tools listed are required for the erection of the shed. These tools should be at hand before starting work. Step ladder Dyna bolts 6.5mm x 40mm Masonary Drill Bit 6.5mm and suitable power drill Multi grips Tape measure 2.8mm and 10mm Steel Drill Bit...
- Page 4 1015HDD2 1015HDD 1019HDD2 1019HDD PARTS LIST (2M WALL) (1.78M WALL) (2M WALL) (1.78M WALL) CONTENTS OF PACK “A” (FLAT PACK) Right hand gable Left hand gable Hinged door SCHDX2 SCHDX SCHDX2 SCHDX Roof end panel Door jamb Door jamb supporter HD52 HD52 K frame...
- Page 5 PARTS - PACK A Note: Packing procedures may differ for larger items in packs A & D however they will still contain the correct amount of parts. Models containing the optional skylight will consist of one less roof sheet. HARDWARE KIT BAG X13b SELF TAPPING SCREW...
- Page 6 PARTS - PACK A - Continued SCHDX/SCHDX2 - Door K/K2 - Wall Panel L6/L62 - Door Jamb Roof Ends Gables F/F2 - Corner Panel S1- Roof Panel Packed in bottom of box PARTS - PACK D S1 - Roof Panel SKY10 - Skylight K/K2 - Wall Panel Optional...
- Page 7 PARTS - PACK b P7/P9 SM7/SM9 H7/H9 B7/B9 PARTS - PACK C PF1/PF12 PARTS - PACK E P8/P1 B8/B1 SM8/SM1 H8/H1...
- Page 8 FOUNDATIONS Roof Width = 3.07m 1015HDDA / 1015HDDA2 1019HDDA / 1019HDDA2 Roof Recommended Roof depth = 4.64m Slab depth = 4.740m 1015HDDA 1015HDDA 1015HDDA2 1015HDDA2 Roof Roof depth = 5.88m Recommended 1019HDDA Slab depth = 5.980m 1019HDDA2 1019HDDA 1019HDDA2 Recommended Slab width = 3.170m 1015HDDA / 1015HDDA2 1019HDDA / 1019HDDA2...
- Page 9 WALL PANEL LAyOUT Note: Codes for sheds with 2m wall height may differ from codes with shed with a 1.78m wall height. eg K = 1.78m wall sheet as shown in 1015HDDA diagram K2 = 2m wall sheet as shown in 1019HDDA2 diagram As shown in the diagrams below the Double Hinged Doors can be placed on any side of the shed where there is a 3 Wall Panel K/K2 space.
- Page 10 STEP 1 PRE-AssEmBLE ALL PARTs IN sTEP 1 - 8 BEfORE EREcTING sHED. Fix Gables 'O1' and 'N1' to the Top Rail 'I1' from the centre towards each end with screws 'X12'. Note If Double Hinged Doors are to be placed underneath the Gable fix 'X26' bracket to centre of Gable as shown in diagram below as this gives support to the Gable over the door opening.
- Page 11 STEP 2 - Roof Beams - P For 10x15 For 10x19 X13b Note: Top holes for roof fixing must be parallel X13A Note: The Roof beams 'P' have THREE OvAL SLOTS AT EACH END not round holes as the Side Midwalls 'SM'. Do not fix nuts and bolts in these slots.
- Page 12 STEP 3 - Side Midwall Brace - SM For 10x15 For 10x19 X13b Note: Line up the four end holes X13A Note: The Side Midwall braces 'SM' have FOUR ROUND HOLES AT EACH END not oval slots as the Roof beams 'P'. Do not fix nuts and bolts in these holes.
- Page 13 STEP 4 - Gable End Midwall Brace - RM1 10x15 RM1 For 10x19 X13b Note: Line up the two end holes X13A Note: The Gable End Midwall brace 'RM1' have TWO ROUND HOLES AT EACH END not four round holes as the Side Midwall braces 'SM'. Do not fix nuts and bolts in these holes.
- Page 14 STEP 5 - Base Rails NOTE Throughout this manual all doubled up codes that refer to 10x15 shed code first followed by the 10x19 shed code. eg (B7/B9) B7= Short Side Base Rail for 10x15 shed b7/b9 B9 = Short Side Base Rail for 10x19 shed. Gable End Base Rail Overlap the Gable End Base Rail 'A1' on top of the Short Side Base Rail 'b7/b9'.
- Page 15 STEP 6 - Portal Frame PF1 = 1.78m Wall Height Note: Repeat on both sides of 'PF2'. PF12 = 2m Wall Height X13A X13b PF1/PF12 Note: Repeat on second 'PF1/PF12'. PF1/ PF12 TR01074A Side profile of PF2 PF1/PF12 TR01074A PF1/PF12...
- Page 16 STEP 7 - Corner Panels and Portal Frame Corners 'F/F2' are supplied with a 45° bend. With F/F2 a supporter (any sized straight edge that is longer F/F2 than the panel NOT SUPPLIED) bend the panels 90° manually. (Do not over bend). F/F2 Corner Panel Supporter...
- Page 17 STEP 8 - Wall Panels and Gables Note: The wall panel overlaps the PF1/PF12 towards the long side by half a panel as shown in diagram 1. Please study the screw fixing procedure in step one closely. you may need to squeeze the bottom of the PF1/PF12 to line it up with the holes in the PF3 correctly.
- Page 18 STEP 9 - Wall Panels and Midwalls NOTE The Double Hinged Door can be placed on any side of the shed where there is a three wall sheet gap between the corner panels or the portal frame. Do not fix the Midwall to the shed where the Double Hinged Doors are to be placed until STEP 10. To attach the Long Side Midwalls 'SM8 = 1015', 'SM1 = 1019'.
- Page 19 STEP 10 - Double Door Frame Construction Note. The diagrams below show construction of the door fame on the long side of the shed. Adjust codes if the door opening is to be placed elsewhere on the shed TOP vIEW FIX WITH THE SELF Place rib of door jamb 'L6/L62' under TAPPING SCREWS 'X12' OR...
- Page 20 STEP 11 - Roof Beams Use nuts and bolts for step 11. Slide the pre-assembled Centre Roof Beams 'P' down over each side of the 'X34' on the Portal Frame and down over each side of the join in the gable. Fix the pre-assembled Centre Roof Beams 'P's into position using nuts and bolts in the end slots as in diagram Fix back centre 'P'.
- Page 21 STEP 12 - Roof End Panels All fasteners on roof need washers 'X11' attached. Panel to Fix all four Roof Ends 'RQ' with Bolts, Nuts and washers from top of Panel appex to the side wall, as shown in diagram below. X13A Fix screws &...
- Page 22 STEP 13 - Roof Panels If your shed model is supplied with the optional skylight use a metal Roof Panel 'S1' as a template and using the self tapping screws provided screw holes into the skylight. The skylight is designed to be fixed on top of the Roof Panels each side of it.
- Page 23 STEP 14 - Roof Edge Trim Fix the Roof Ridge End Cap 'X10' on top of the Roof End Capping 'U3'. To hide any joins, fix the Roof Edge Trim 'T6' to the roof starting from the back of the shed towards the front overlapping each Roof Edge Trim as you proceed.
- Page 24 STEP 15 Dyna-bolting base Rails to Concrete and sealing floor Ensure shed is square then drill 6.5mm holes into the foundation through the base rail where holes are provided. Fix 6.5mm x 40mm dynabolts. Do not seal shed before anchoring to foundation. 6.5mm x 40mm Dynabolt Before sealing the base rail ensure all dust has been removed.
- Page 25 STEP 16 - Door Assembly Note: When assembling double hinged doors ensure the K Frame is installed on opposite diagonals of each door to make a pair as in step 18. Drill 2.8mm holes where holes are not pre-punched. Hinged Door Kits vary from a non assembled door that needs to be fully constructed as in diagram - .
- Page 26 STEP 17 - Door Assembly continued Note 'C1525' is not needed when Fix three self tapping screws or doors are place under the gables pre-drill three 2.8mm holes into the double door support 'C1525' then fix to the long top rail 'H' C1525 with 'X12' screws as shown in diagram 1 and 2.
- Page 27 STEP 18 - Door Assembly continued C1525 C1525 Fix the Padbolt and Padbolt Spacer to the inside of the Door frame Padbolt with 'X12' Screws. HA01000A Mark the 'C1525' (or 'A1' if doors under Gable) drill a 10mm diameter hole C1970 for the Padbolt shaft Padbolt...
- Page 28 OPTIONAL sINGLE HINGED DOOR SINGLE HINGED DOOR 1.78m WALL HEIGHT 2m WALL HEIGHT TRECO SHEDS ARE MANUFACTURED TO COMPLY WITH ALL AUSTRALIAN STANDARDS TRX16SD www.oldfields.com.au/treco/index.htm - 08/05/07...
- Page 29 Not all 1015 / 1019 models are provided with the Optional Hinged Door. This item is an extra if you require an Optional Hinged Door they are available from your local Treco Agent. ASSEMbLED DOOR PARTS LIST 1.78m Wall...
- Page 30 STEP 10a - Door Jamb construction for Optional Hinged Door The door can be placed on any side of the shed, by leaving out DRILL 2.8mm HOLES Two Wall Sheets when sheeting Door Jambs AND FIX WITH SELF up the shed. The ¼ Wall Panel can be fixed TAPPING SCREWS 'X12' and the two Door Jambs are...
- Page 31 STEP 19 - Construction of Optional Single Hinged Door Single Hinged Door Kits vary from a non assembled door that needs to be fully constructed as in diagram 1 – 4. To a pre-assembled door that only needs the Hinges and K Frame 2 - 4. FRONT OF DOOR SIDE VIEW OF DOOR FRONT OF DOOR...
- Page 32 STEP 20 - Hanging the Optional Hinged Door Fix one 'HD5/HD52' over the door jamb 'L' on the side you want the door to be hinged from either the (L1/L8) or (L12/L82). Fix the hinges on the door to the 'HD5/HD52' with Screws 'X12'.
- Page 33 WARRANTy AND SPARE PARTS PLEASE CALL (02) 4627 0777 This material is copyright C 2006 Oldfields Pty Ltd. Apart from any use as permitted under the Copyright Act 1968, all other rights are reserved. You may download, store in cache, display, print and reproduce the material in unaltered form only (retaining this notice, or links to it where they appear) for your personal, non-commercial use. You are not permitted to re-transmit, distribute or commercialise the information or material without seeking prior written approval from Oldfields Pty Ltd.
