  • Page 1 W&T PC cards for ISA bus systems Manual PC Cards for ISA Bus Systems Type 13001, 13401 13601, 13801, 13802 W&T Release Subject to error and alteration...
  • Page 2 W&T PC cards for ISA bus systems © 09/2002 by Wiesemann & Theis GmbH Subject to error and alteration: Since it is possible that we make mistakes, you mustn’t use any of our statements without verification. Please, inform us of any error or misunderstanding you come about, so we can identify and eliminate it as soon as possible.
  • Page 3 W&T W W W . W u T . D E Manual W&T PC cards Part.-No. Page 2 x RS232, without isolation 13801 2 x RS232, 1 kV isolated 13802 2 x 20mA, 1 kV isolated 13401 2 x RS422/485, 1 kV isolated 13601 2 x serial PC card, 1 kV isolated 13001...

  • Page 4: Esd Protection

    PC card 2 x RS232 W&T #13801 W W W . W u T . D E Function The W&T PC card 13801 equip your PC with two independent RS232 serial interfaces. Both serial ports are equipped with type 16C550 FIFO UARTs; this makes them functionally compatible with standard RS232 interfaces, so that the cards can easily be used with your available software.

  • Page 5: Interrupt Settings

    W&T on request. Setting both ports to the same base address should be strictly avoided. Please see the following tables for an explanation of the address DIP switch settings: Port 1 SW 1.9 SW 1.10 SW 1.11...

  • Page 6: Technical Data

    PC card 2 x RS232 W&T #13801 W W W . W u T . D E Connectors and pin assignment The two ports of the W&T RS232 PC card 13801 use DB9 male connectors with identical pin configuration. The connector pin assignments are shown in the table below: pin assignment RS232 interface...
  • Page 7 PC card 2 x RS232 W&T #13802 W W W . W u T . D E Function The W&T PC card 13802 equip your PC with two independent RS232 serial interfaces with an insulation of up to 1000 Volts. Both serial ports are equipped with type 16C550 FIFO UARTs;...
  • Page 8 W&T on request. Setting both ports to the same base address should be strictly avoided. Please see the following tables for an explanation of the address DIP switch settings: Port 1 SW 1.9 SW 1.10 SW 1.11...
  • Page 9 PC card 2 x RS232 W&T #13802 W W W . W u T . D E Connectors and pin assignment The two ports of the W&T RS232 PC card 13802 use DB9 male connectors with identical pin configuration. The connector pin assignments are shown in the table below: pin assignment RS232 interface...
  • Page 10 PC card 2 x 20mA W&T #13401 W W W . W u T . D E Function The W&T PC card 13401 equip your PC with two independent 20mA serial interfaces with an insulation of up to 1000 Volts. Both serial ports are equipped with type 16C550 FIFO UARTs;...
  • Page 11 W&T on request. Setting both ports to the same base address should be strictly avoided. Please see the following tables for an explanation of the address DIP switch settings: Port 1 SW 1.9 SW 1.10 SW 1.11...

  • Page 12: Connectors And Pin Assignment

    PC card 2 x 20mA W&T #13401 W W W . W u T . D E Connectors and pin assignment The two ports of the W&T 20 mA PC card 13401 use DB9 male connectors with identical pin configuration. The connector pin assignments are shown in the table below: pin assignment 20mA interface...
  • Page 13 PC card 2 x 20mA W&T #13401 W W W . W u T . D E Technical data base adresses: 03F8H, 02F8H, 03E8H, 02E8H interrupts: IRQ3, IRQ4, IRQ5, IRQ7 IRQ9, IRQ10, IRQ11, IRQ12 baudrate: 50..57600 Baud data format: any data format operation modes: 20mA active mode / 20mA passive mode independently selectable for Tx and Rx current loop...
  • Page 14 PC card 2 x RS422/485 W&T #13601 W W W . W u T . D E Function The W&T PC card 13601 equip your PC with two independent RS422/RS485 serial interfaces with an insulation of up to 1000 Volts. Both serial ports are equipped with type 16C550 FIFO UARTs;...
  • Page 15 W&T on request. Setting both ports to the same base address should be strictly avoided. Please see the following tables for an explanation of the address DIP switch settings: Port 1 SW 1.9 SW 1.10 SW 1.11...

  • Page 16: Operating Mode

    PC card 2 x RS422/485 W&T #13601 W W W . W u T . D E Connectors and pin assignment The two ports of the W&T RS422/RS485 PC card 13601 use DB9 male connectors with identical pin configuration. The connector pin assignments are shown in the table below: pin assignment RS422/RS485 interface pin#...
  • Page 17 PC card 2 x RS422/485 W&T #13601 W W W . W u T . D E Please see the following table for an explanation of the operating mode DIP switch: operating mode SW1 SW2 SW3 SW4 SW5 RS422, RS485, 4 wire bus master, DTR handshake OFF OFF OFF ON RS422, RS485, 4 wire bus master, RTS handshake OFF OFF OFF OFF ON...
  • Page 18 PC card 2 x RS422/485 W&T #13601 W W W . W u T . D E Technical data base adresses: 03F8H, 02F8H, 03E8H, 02E8H interrupts: IRQ3, IRQ4, IRQ5, IRQ7 IRQ9, IRQ10, IRQ11, IRQ12 baudrate: 50..115200 Baud data format: any data format operation mode: RS422 RS485, 2 wire and 4 wire applications...
  • Page 19 Serial PC card W&T Module mainboard #13001 W W W . W u T . D E Function The W&T serial module mainboard equip your PC with two independent serial interfaces with an insulation of up to 1000 Volts. The integration of interface specific components in the form of exchangeable interface modules offer the possibility of an optional card equipment with various types of interfaces.
  • Page 20 W&T on request. Setting both ports to the same base address should be strictly avoided. Please see the following tables for an explanation of the address DIP switch settings: Port 1 SW 1.9 SW 1.10 SW 1.11...
  • Page 21 Serial PC card W&T Module mainboard #13001 W W W . W u T . D E Connectors and pin assignment The serial TTL interfaces of the W&T serial module mainboard use pin header connectors with identical pin configuration. The connector pin assignments are shown in the table below: Pin 1 of the pin head connector has a square pad while the other pins have round pads.

This manual is also suitable for:

Sw 1.10Sw 1.11Sw 2.9Sw 2.11Sw 2.10Sw 2.12 ... Show all
