This guide is designed to help you operate your Commander Echo
Console in a few easy steps. For more detailed information, please
refer to the Commander Echo User Manual.
© 2016 JTECH Medical MN042_E
Prior to testing, it is crucial you follow the steps in this
guide, or refer to the more comprehensive Commander
Echo User Manual.
®
Quick Start Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JTECH Commander Echo
Summary of Contents for JTECH Commander Echo
- Page 1 ® Quick Start Guide This guide is designed to help you operate your Commander Echo Console in a few easy steps. For more detailed information, please refer to the Commander Echo User Manual. Prior to testing, it is crucial you follow the steps in this guide, or refer to the more comprehensive Commander Echo User Manual.
- Page 3 • Hold the Control Stick to the left to return to the Main Menu (Note: this does not work in certain menus. Select Exit on these occasions). • Hold the Control Stick to power-off the Console. © 2016 JTECH Medical MN042_E...
- Page 4 Using the provided Power Supply and Daisy Chain, charge the console and up to three instruments simultaneously. Note: The Commander Echo and its Instruments are not designed to be used while charging. Allow the instruments to fully charge, and then remove them from the charger prior to use.
-
Page 5: Select Instrument
Select Instrument Commander Echo allows multiple instruments to be paired with a single console for different types of tests. Instruments are pre-registered on the console, but additional devices or missing devices may be added. Refer to pg. 18 of the manual for more detailed information. -
Page 6: Perform Test
Perform Test Once zero calibration is complete, the test will start. Once all tests have been completed, press the Control Stick to return to the Main Menu. Reviewing Test Results 1) From the Main Menu, highlight Review and press the control stick 2) Move the control stick up or down to cycle through tests 3) Move the control stick left or right to view additional data 4) Hold down the Control Stick to delete individual tests... -
Page 7: Installing The Software
Installing the Software 1) Insert the JTECH Medical Commander Echo Downloader USB Flash Drive into one of your computer’s available USB ports. When the “AutoPlay” Menu shows up; click the Commander Echo option. i. If the Commander Echo option isn’t available, click the Open folder to view files option. - Page 8 User Manual included on the USB Flash Drive. If you have any questions, concerns, or are interested in purchasing the full version of the Commander Echo Downloader Software, please contact JTECH Medical Customer Service at 800-985-8324 or 385-695-5000.
- Page 9 A Return Material Authorization (RMA) number must be obtained from JTECH Customer Ser- vice prior to returning any merchandise. JTECH reserves the right to refuse or to return-collect any merchandise sent back without prior authorization of our Customer Service department.
- Page 10 Echo Downloader Software License JTECH grants the customer rights to use this software on a single computer at a single location as long as the customer complies with the terms of this license. If you are using a trial version, software login will not be possible after 30 days.
- Page 11 MEDICAL MEASURING HUMAN PERFORMANCE Manufacturer Authorized Representative for EU JTECH Medical Industries, Inc Atlantico Systems 7633 Main Street 34 Oldfield, Kingston, Galway, Republic Midvale, UT 84047 of Ireland United States of America Company number: 443142 Email: Info@AtlanticoSystems.com 800 985-8324 Phone: +35391443609...
