Summary of Contents for eWON eFive 100
-
Page 1: Installation Guide
Installation Guide IG 013 / Rev 1.3 eFive 100 Installation Guide This short guide explains how to install the eFive 100 Firewall and to get started with the embedded configuration web site. -
Page 2: Table Of Contents
Table of Contents 1. What is eFive 100 ? ........................... 3 2. Compliance ............................3 3. Hardware description ........................4 3.1 Package contents ........................4 3.2 Housing interfaces ........................4 3.2.1 Front Panel ........................4 3.2.2 Back panel ........................5 3.3 Markings ............................. -
Page 3: What Is Efive 100
100 is a rackmount hardware platform featuring a Virtual Private Network (VPN) gateway with OpenVPN. It has been designed to be a perfect match with the eWON range to build a VPN network. The eFive 100 acts as OpenVPN Server and the eWONs as OpenVPN Clients. -
Page 4: Hardware Description
3. Hardware description Package contents The eFive 100 VPN server hardware platform x 1 AC power cords (1 x NEMA 5-15p + 1 x CEE 7/7 France/Germany) Plastic adhesive stands x 4 (small adhesive stands to affix on the bottom of the unit) -
Page 5: Back Panel
Outlets of the system fans AC inlet and power switch Markings The identification label of the eFive 100 is placed on the bottom plate of the housing. The different parts of the label are shown below: Device type Serial number... -
Page 6: Mechanical Outline
Chapter 3. Hardware description Mechanical outline All dimensions are in millimeters. eFive 100 Installation Guide (How to) Page 6/13... -
Page 7: Software Configuration
WAN range is compliant with the current IT-policy. For more information about the different networks used by the eFive, please see the eFive User Guide, AUG- 050-0-EN which is available from the eWON Support website http://wiki.ewon.biz/Support/07_Documentations.Fi st connection Connect your PC with the LAN-port of your eFive (Port 1 - green). -
Page 8: Setting The Lan Ip (Green) Address
Chapter 4. Software configuration The home page of the eFive opens. 4.2.2 Setting the LAN IP (green) address Click Network, Interfaces from the main menu. The interfaces window opens. (see next page) eFive 100 Installation Guide (How to) Page 8/13... -
Page 9: Setting The Wan (Red) Address
In this area, you also have to configure the DNS server address(es) and the default gateway. The WAN/DMZ and VPN configuration are described in the software document AUG-050-0-EN (eFive – Client configuration & device access). eFive 100 Installation Guide (How to) Page 9/13... -
Page 10: General Specifications Of Efive 100
Chapter 4. Software configuration 5. General specifications of eFive 100 Mechanical/Power/Environmental Form factor 1U Rack mount Dimensions 44mm (1.73”) (H) x 430mm (16.93”) (W) x 248mm (9.76”) (D) Weight 7kg (15.43 lb) Power supply AC to DC 84W open frame, Input 100-240 VAC 50/60 Hz 1A typ. -
Page 11: Appendix 1 - Serial Console Access
Appendix 1 - Serial Console Access Appendix 1 - Serial Console Access The VPN server platform eFive 100 features a serial port allowing to connect a terminal console. This access is a useful rescue solution when it appears impossible to connect with the Ethernet interface. - Page 12 To reset the unit to its factory settings (IP 10.0.0.153 and the admin password to admin) type 0 and hit [enter]. Wait for the reboot to complete (takes some time). eFive 100 Installation Guide (How to) Page 12/13...
-
Page 13: Revision History
Add terminal emulator port + cable + power cords 14/06/13 Add serial console access 09/05/14 eFive 25 supports up to 50 VPN Clients eFive 100 supports up to 200 VPN Clients Helsinki St. Petersburg Moscow tel. +358 9 540 4940 tel.
