- Page 1 DRIVING VIDEO RECORDER Instruction Manual DR-400N Thank you for purchasing this product. For correct usages and application, please read this instruction manual thoroughly. ver. 1.0 PRINTED IN KOREA * Design and Specifications are subject to change without notice.
-
Page 2: Table Of Contents
CONTENTS SAFEGUARD INSTRUCTIONS ............. 3 PRODUCT FEATURE ..............6 COMPONENTS ................6 PARTS .................... 7 INSTALL IN YOUR CAR ............... 8 PRODUCT OPERATION .............. 10 ......- Power ON/OFF ............10 - FIRM WARE UPDATE ................. 11 - Event Recording ................ -
Page 3: Safeguard Instructions
SAFEGUARD INSTRUCTIONS Please read the “Safety Rules” carefully before using this product. Following the safety rules prevents users from damages related with the misuse of the product. It is very important to follow these safety rules. We state “Caution” and “Warning” to clarify any potential risk for a damage associated with the misuse of the product. NOTICE This information is for user’s reference for better usability. - Page 4 WARNING Please do not install the product where has lots of vibration or not fixed securely. - It may cause traffic accident and injury due to an interruption from detaching the product by vibration during driving. Please avoid wiring of connected codes from high fever. - It may cause electric shock and fire from melting of covering for codes.
- Page 5 CAUTION Do not shock to the product. - It may cause damage or malfunction for product. Do not place near magnet. - It may cause malfunction and trouble. Keep the internal GPS without any obstacle near of it like high pass, navigation. - It may cause problem on GPS signal receipt rate.
-
Page 6: Product Feature
PRODUCT FEATURE - AUTO RECORDING (DIRIVING, ACCIDENT, ETC..) - H.264 - PC VIEWER MANAGER - 4 TRIGGERS - UP TO 1TB HDD OR SSD SUPPORT - LOCK SYSTEM FOR HDD OR SSD (2.5” HDD OR SSD) - EXTERNAL MIC. - BEEP SOUND (EVENT RECORDING, FIRM WARE UPDATE & ETC.) - Integrated 3G-Sensor - Trace of trajectory interlocked with map - Emergency battery equipped (with Super capacitor) -
Page 7: Parts
PARTS DR-400N Front of DVR body Back of DVR body 1. Camera Operation LED 6. MEMORY LOCK 2. Recording LED 7. TRIGGER 3. Remote Controller Sensor 8. MIC / GPS / REMOTE CONTROLLER 4. Hard Case 9. POWER CABLE 5. CASE LOCK REMOTE CONTROLLER 1. -
Page 8: Install In Your Car
INSTALL IN YOUR VEHICLE Please check the following points prior to installation: - Turn off the product before installation, and install the product with the ignition key removed. - Do not use any other cables; only use the supplied cables. - If the vehicle has a tinted or heated screen the GPS receiver rate may be 'poor' &... -
Page 9: Cable Connection
CABLE CONNECTION Camera (optional) Back of DVR body Monitor (optional) GPS antenna (Included) TRIGGER Cable (Optional) CAMERA 1 CAMERA 2 CAMERA 3 CAMERA 4 Video out cable (optional) Yellow (Video) White (Audio) Remote controller receiver MIC ( optional) Connection with GPS antenna (optional) When connected to the GPS antenna driving route, speed, time, direction and location information is also recorded. -
Page 10: Product Operation
PRODUCT OPERATION Please note: - Please do not operate/change settings during driving. - Please connect GPS, VIDEO OUT, MIC before turning the ignition on. - After unit power on, it may reboot. This is not a device fault. - Recording is only possible when the MEMORY tray is inserted & locked. - If the MEMORY is removed while in operation, some or all of the data may be lost. -
Page 11: Firmware Update
FIRMWARE UPDATE 1. CAM1/CAM2/CAM3/CAM4 LED flash at an interval of 1 sec during firmware update and a beep will be sound once the firmware update has completed. * Power should not be turned off during update. Event Recording 1. Event Recording : the unit records for 10 seconds before and 20 seconds after an event (accident) occurs (30 seconds in total). -
Page 12: Led Description
LED Description * Condition: 4 camera connection REC/EVENT STATUS CAM1 CAM2 CAM3 CAM4 LIGHT ON AFTER ON(Stand-by) LIGHT ON 15SECONDS Flashing ON(Recording) LIGHT ON LIGHT ON LIGHT ON LIGHT ON (1 second interval) Flashing LIGHT ON (1 second interval) Flashing EVENT RECORDING LIGHT ON (Quickly) -
Page 13: Pc Viewer Manager
PC VIEWER MANAGER Specifications of PC VIEWER MANAGER Memory : 2GB RAM at least HDD : Supported within 1TB CPU : Pentium 4 3.0GHz at least User Authority : Administrator OS : WINDOWS XP/ VISTA/ 7/ 8 / 10 Installation & Execution of PC VIEWER MANAGER PC VIEWER MANAGER needs to be installed. -
Page 14: Interface
Interface 1. Play screen Display quad recorded video 2. 3G sensor Display 3G sensor information. 3. Volume control Adjusts sound. (mute/volume +,-). 4. Movie control Previous File/Backward/Play(Pause)/Forward/Next File. 5. Play speed control Adjusts play speed (x1/4 ~ x4). 6. Minimize Minimizes the program (with the Taskbar). - Page 15 1. Time & Date Displays the present time and date. 2. GPS Displays the status of the GPS connection. (Connection : O, Disconnection : X). 3. Recording Displays the recording status (NORMAL / EVENT). 4. Version Displays the Firmware version. 5.
-
Page 16: How To Play Video
How to play video 1. Please open the software on the PC. 2. ①”Please click “file reading” ② Please select memory and click confirm. - Page 17 3. ③ Please double click the file for playing video.
-
Page 18: Menu
Menu 1. Click the right button of mouse at screen, following menu will be shown. Changing the playback screen : Playback screen changes as left and right. Screen ratio : Control recording data screen’s ratio. Video : It turns around upside and downside / I turns around left and right 1CH video : Video is displayed as full size. -
Page 19: Configuration
Configuration 1. Speed Indicator Unit Selects the speed indicator unit of GPS information (km/h, MPH). 2. Recording Quality Sets the recording quality (High-Definition / Standard). Set G-sensor Sensitivity 3. G-sensor Sensitivity (5steps : 1 (Low) - 5 (High). If speed goes beyond the setting speed, the file saves as event file. 4. - Page 20 “Timeset.cfg” file will be created after checking time setting and saving the value. This means time setting is correctly set. Please check this status be- fore device operation.
-
Page 21: Specification
SPECIFICATION DR-400N Video signal Input 4 Channel input Output 1 Output Audio signal 1 Input Recording Resolution Full HD 1920 x 1080 or 960H (960 x 480) Frame 30fps Mode normal / Event (G-sensor) Compression H.264/AVI Memory SSD (Min.128GB ~ max.1TB) Power supply DC 12~24V (with super cap) @max.32V... -
Page 22: Check Point Before Service Request
CHECK POINT BEFORE SERVICE REQUEST * You can solve some problems as below with simple check. If you still have a problem please contact the service centre or store that you purchased. Q Recording LED is not operating even though power is on. A - The key should be locked after inserting the memory tray. - Page 23 MEMO...
- Page 24 INSTRUCTION MANUAL...
