Summary of Contents for Maxell Seiki ME-KS01M48-A
- Page 1 RFID Reader/Writer Unit Model: ME-KS01M48-A Hardware Manual REV 1.00 February 28, 2011 Maxell Seiki, Ltd 2011@Maxell Seiki Ltd.
- Page 2 Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 2011@Maxell Seiki Ltd.
- Page 3 This part explains notice for safe use. If performed, these may cause injury or property damage. This part explains attentions and restrictions on the Advice operation or notice to avoid the wear and tear of RW and breakdown. Carefully read this part to avoid misoperation. 2011@Maxell Seiki Ltd.
- Page 4 Don’t close the RW vents. It may cause an electric shock and a fire. If unusual smell, smoke, ignition or unusual sound is present, unplug AC power cable from an electric outlet and the RW immediately and don’t use it. 2011@Maxell Seiki Ltd.
- Page 5 Dust on the antenna of RW may cause read error and write error. When cleaning the RW, turn the power off to avoid an electric shock. Don’t wipe the RW with moistened dustcloth or solvent such as a thinner. It may cause an electric shock. 2011@Maxell Seiki Ltd.
-
Page 6: Table Of Contents
1. Introduction ..........................1 2. Exterior features ........................1 3. Connecting instructions ......................2 4. Operating instructions ......................4 5. Care and Maintenance ......................5 6. Troubleshooting ........................6 7. Specifications ........................... 7 8. Dimensions ..........................8 2011@Maxell Seiki Ltd. -
Page 7: Introduction
CD for the installation of application software and device driver. ⑨ Manual For the RW and the application. *1 Cables are not included in the CE declaration of this R/W. Please prepare a AC power cable that matches the specifications of your country. Maxell Seiki Ltd. -
Page 8: Connecting Instructions
3) Confirm that the power is in the “off” position and then plug the AC power cable into the outlet of RW. CAUTION INSERT THE AC POWER CABLE INTO THE RW AND THE ELECTRICAL OUTLET SECURELY. 4) Plug the AC power cable into the electric outlet. Maxell Seiki, Ltd. - Page 9 PLUG THE AC POWER CABLE INTO AN ELECTRIC OUTLET THAT IS PROPERLY GROUNDED. USE AN ELECTRIC OUTLET THAT IS EASILY UNPLUGED. UNPLUG THE AC POWER CABLE FROM THE ELECTRIC OUTLET WHEN NOT IN USE. Maxell Seiki, Ltd.
-
Page 10: Operating Instructions
RW. It may cause a communication error. 5) After the completion of operation, turn the power off. When turning the power off, the switch of power turns off the lights. When not in use, unplug the power cable from the electric outlet. Maxell Seiki, Ltd. -
Page 11: Care And Maintenance
3) Wipe the antenna of RW with a cloth dampened with volatile alcohol when the dirt is stubborn. * Volatile alcohol: IPA, ethanol, etc Advice ● Don’t use the benzene and the solvent. ● Don’t put a large amount of volatile alcohol on the RW. It may cause a breakdown. Maxell Seiki, Ltd. -
Page 12: Troubleshooting
Check that the RW reads or Change microtubes. writes data other microtubes. Check dust on the antenna of Clean the antenna of RW. CAUTION DON’T DISMANTLE AND CUSTOMIZE THE RW TO AVOID AN ELECTRIC SHOCK AND A BREAKDOWN. Maxell Seiki, Ltd. -
Page 13: Specifications
6． Non-operating conditions 1) Ambient temperature : -10 to 50℃ 2) Relative humidity : 30 to 85%RH (no dew condensation) 7． Use environment Interior of room * Avoid direct sunlight, rain and dew. 8． Ground Ground resistance: Under 100ohms Maxell Seiki, Ltd. -
Page 14: Dimensions
ME-KS01M48-A 8. Dimensions 1. RW Unit: mm 2. Rack Unit: mm 119.05 86.25 75.45 129.55 Maxell Seiki, Ltd.
