Summary of Contents for Chatenet CH40
- Page 1 CH40 INSTRUCTIONS FOR USE INTEGRATED MAINTENANCE PLAN CH40 W W W . A U T O M O B I L E S - C H A T E N E T . C O M MANUFACTURED IN FRANCE...
- Page 2 THANK YOU FOR YOUR TRUST Your CHATENET is a vehicle equipped with the latest technological innovation, and has many comfort features that you will surely want to enjoy while driving everyday. BEFORE FIRST USE, READ THE INFORMATION CONTAINED IN THIS MAINTENANCE PLAN. TAKE IT INTO ACCOUNT TO FAMILIARIZE FULLY WITH ALL THE ASPECTS OF YOUR VEHICLE.
-
Page 3: Table Of Contents
CH40 GENERAL WARRANTY Engine oil CONDITIONS Maintenance and cleaning of the vehicle Dimensions Battery Specifications Lights SECURITY INSTRUCTIONS Tires Interventions Fuel / oil Levels Exhaust • brake liquid Battery • cooling liquid Identification of the vehicle • windshield liquid Roll Fuse box •... -
Page 4: General Warranty Conditions
GENERAL WARRANTY CONDITIONS 1. Any new vehicle in the CHATENET range is warranted 8. Non-warranty elements: • All non-original parts and equipment CHATENET for a period of two years from the date of delivery to the • maintenance operations, including... -
Page 5: Dimensions
CH40 DIMENSIONS (in mm) CHARACTERISTICS Bi-cylinder diesel engine: 480 cm Power: 6 kW/8,04 CV Maximum capacity of the tank: 14 liters Turning diameter: Number of seats: Inverter: Manual Automatic speed: Variator Maximum speed : 45 km/h... -
Page 6: Security Instructions
Any intervention (electrical circuit, engine, Handle the battery carefully as it contains seats, fasteners, belts, body ...) should acids. be held at AUTOMOBILES CHATENET Disconnect the ground cable from the dealers. battery whenever you do any work on a component of the electrical installation. -
Page 7: Opening / Closing
CH40 OPENING / LOCKING / UNLOCKING VEHICLE DOORS REMOTE CONTROL TRUNK Press the button with the logo luggage trunk To open the doors, press the open padlock to open the luggage trunk and possibly also (the warning and blinks will blink three the driver and passenger doors. - Page 8 OPENING / LOCKING / UNLOCKING LATERAL WINDOWS WARNING Do not drive if you do not have good visibility on all windows. Dirty, icy or foggy glasses reduce vision and increase the risk of accidents and serious injuries. The two control buttons are located on the CLOSING THE ENGINE HOOD center console.
-
Page 9: Seats / Seat Belt
CH40 SEAT / SEAT BELTS FRONT SEAT / BACKREST SEAT SEAT BELTS ADJUSTMENT Seat belt is required To move the seat forward or backward, use THREE POINT SAFETY BELT, IN BOBINE the center handle under each seat to the This type of belt is unnecessary to adjust desired position. -
Page 10: Seat Belt
SEAT BELTS RECOMMENDATIONS • Babies and children can not be carried in the lap of the occupants of the vehicle. • Regardless of the length or distance of • It is particularly dangerous to hold your the trip, you must wear your seat belt. child when he is sitting on your lap. -
Page 11: Cockpit
CH40 THE COCKPIT Barel / neiman Ventilation control Steering wheel Heating control (hot / cold) Lighting control / Flashing lights / Horn Option MULTIMEDIA radio (see the radio instruction manual supplied with Windscreen wiper / Washer control / the vehicle) - Page 12 SPEEDOMETER / PANEL Speedometer with analog needle Oil pressure indicator display Battery indicator Total mileage totalizer with digital Brake fluid indicator display (LCD) Rear defrost indicator Daily mileage totalizer with digital Engine preheat indicator display (LCD) Side or rear door open indicator Indicator of gear position with digital display (LCD) Water in fuel indicator...
-
Page 13: Panel Lights
(LIGHT TESTED WITH CONTACT ON) If the light comes on the road, stop the FRONT FOG LAMPS engine immediately, wait 10 mn, check the oil level. If the light stays on, contact your CHATENET dealer REAR FOG LAMPS immediately. BRAKING CIRCUIT HIGH BEAMS... -
Page 14: Set The Clock
CLOCK SETUP TOTAL OR DAILY QUILOMETRATION The clock setting is performed as follows: 1 - Press the "10" button for 5 seconds, the The total kilometers counter has a digital hours will flash. display (LCD) with 6 numbers. The maximum number of kilometers is 999 999 km. -
Page 15: Adjusting The Interior Light
ADJUSTING THE LIGHT INDOOR LIGHTING (8 LEVELS) CONTACT OFF Adjust and you can vary the brightness of The indoor lighting of the vehicle operates the kilometers counter and LCD reader by automatically, with ignition switched off, pressing the "10" button briefly (less than 3 when opening or closing the doors (2 seconds) (see panel on page 10) minutes after opening, 3 seconds after... -
Page 16: Lighting And Signaling
LIGHTING AND SIGNALING CLEAN WINDSHIELDS The joystick to the left behind the steering The joystick on the right behind the steering wheel allows you to change the lighting wheel allows you to operate the front levels. windshield wiper and the defroster. POSITION 0 POSITION 0 The LED daylights are on. -
Page 17: Central Console
CH40 CENTRAL PANEL Emergency lights / warning Ventilation control Indoor aerators Heating control (hot / cold) Button to close the doors Rear defroster Glove compartment Electric window lift buttons Radio Cigarette lighter Air diffuser position control... -
Page 18: Heating / Defrost Ventilation
FAN HEATING / DEFROST REAR GLASS DEFROST Press the joystick (ignition on) button to turn the rear window defrost. HEATING ADJUSTMENT Select the heating temperature using the center button: REVERSE LEVER • cold (-) FRONT-REAR REVERSE • hot (+) You also have the possibility to choose The lever has 3 positions: between 4 main directions (+4 intermediate) D = forward... -
Page 19: Start Up
CH40 START UP PARK ASSIST REVERSE RADAR (OPTIONAL) It can only be started if the gear lever is in position N (neutral). The radar will turn on automatically as soon as the speed lever is in position R (1 beep S =Stop + lock (direction lock). -
Page 20: Trunk
TRUNK LIGHTING OF THE TRUNK The light located on the right hand side illuminates the trunk in its entirety. The bottom of the flat trunk facilitates loading and unloading. Possibility of enlarging the volume by advancing and tilting the finding of the front passenger seat. -
Page 21: Sunshades
CH40 SUN VISOR 12 V OUTLET Fold one or both of the sun visors against The use of the 12V outlet on the dashboard the windshield in case of frontal discomfort panel allows you to connect or recharge or the side windows. -
Page 22: Engine Oil
Never ignore when the warning lights is on. Ignoring the warning lights that appear can cause damage to the vehicle. If too much oil is added above the MAX level, contact your local CHATENET representative. Choosing a suitable engine oil is important for engine operation and longevity. -
Page 23: Maintenance And Cleaning Of The Vehicle
CH40 MAINTENANCE AND CLEANING OF THE VEHICLE WARNING Improper maintenance and cleaning of vehicle parts can affect the proper functioning of the vehicle's safety equipment and can cause serious injury and serious damage. Regular and proper maintenance helps keep your vehicle in good condition. -
Page 24: Battery
We Stop recommend that you perform this Reversing lights 12 V / 21 W white procedure at your CHATENET dealer. Fog light 21 V / 21 W white Plate light 12 V / 5 W... -
Page 25: Tires
CH40 TIRES USING THE REPAIR KIT WARNING (under the passenger seat) Replace the tires with tires approved No tool or jack is required, the repair kit by the manufacturer. is intended for emergencies only, to allow you to drive to the nearest workshop. This Consider size, diameter, load capa- repair is temporary. -
Page 26: Brake Liquid
Insufficient brake liquid level and inadequate or too old brake liquid can lead to brake failure and reduce the braking effect. We recommend that this procedure be performed by a CHATENET distributor. BRAKE LIQUID LEVEL Make check or check the liquid level in the nozzle (the liquid level must always be between MIN and MAX). -
Page 27: Cooling Liquid
CH40 LEVELS VEHICLE FUSE BOX Start up Accessories Permanent COOLANT Make check or check coolant level (coolant level must always be between MIN and MAX). WARNING Do not cover the nozzle when the engine is hot. It should be done with a cold engine to avoid burns. -
Page 28: Engine
ENGINE FUSE BOX FUSE AND RELAY Electric fan fuse 15 A Pump fuse Diagnostic fuse 10 A Fuse 15 A Fuse 10 A Candle fuse 25 A Candle fuse 25 A Electric Fan Relay 30 A General relay 30 A Candle relay 70 A ATTENTION... -
Page 29: Maintenance Indicator
Service is displayed (spanner icon ON) (0km) 8sec Remaining service Ignition? distance ≤! 0km? Normal mode CH40 Service is displayed Service is displayed (spanner icon ON) (spanner blink) 8sec (0km) 8sec MAINTENANCE INDICATOR Service is displayed (digits steady) 8sec (Kilometers and duration in days) Normal mode Normal mode Service is displayed (spanner icon ON) Remaining service (spanner one year (0km) 8sec distance ≤! 0 days? service icon ON) Remaining service Ignition? Your vehicle is equipped with a maintenance indicator that appears for 5 seconds after Service is displayed distance ≤! 0km? -
Page 30: Engine
ENGINE MAINTENANCE TABLE The following maintenance operations must be performed to ensure good emissions controls and good performance. When mileage and periodicity are mentioned at the same time, the maintenance frequency is determined by the first expired term. BY QUILOMETRATION OR ALL YEARS MAINTENANCE PLAN C C C C C C C C C C C C C C C Air filter element... -
Page 31: General
CH40 GENERAL MAINTENANCE TABLE The following maintenance operations must be performed to ensure good emissions controls and good performance. When quilometration and periodicity are mentioned at the same time, the maintenance frequency is determined by the first expired term. BY QUILOMETRATION OR ALL YEARS... -
Page 32: Maintenance Interval
MAINTENANCE SCHEDULE OF REVISIONS Distributor Stamp Preparing for the road 7 000 km Distributor Stamp Date : Km : Distributor Stamp 14 000 km PREPARING FOR THE ROAD Engine Lombardini 480 HDI Workshop stamp making preparation for the road Date : Km : 0 km Distributor Stamp... - Page 33 CH40 Distributor Stamp Distributor Stamp 35 000 km 63 000 km Date : Date : Km : Km : Distributor Stamp Distributor Stamp 42 000 km 70 000 km Date : Date : Km : Km : Distributor Stamp Distributor Stamp...
- Page 34 MAINTENANCE NOTES Distributor Stamp 91 000 KM Date : Km : Distributor Stamp 98 000 KM Date : Km :...
- Page 35 CH40 NOTES...
-
Page 36: Warranty Certificate
VEHICLE MODEL CUSTOMER'S SIGNATURE DISTRIBUTOR / SELLER SIGNATURE AND COMMERCIAL STAMP IMPORTANT Maintenance and revision operations must be carried out on the CHATENET distribution. The undersigned acknowledges that he has read the CHATENET warranty terms and that he accepts without restriction. - Page 37 VEHICLE MODEL CUSTOMER'S SIGNATURE DISTRIBUTOR / SELLER SIGNATURE AND COMMERCIAL STAMP IMPORTANT Maintenance and revision operations must be carried out on the CHATENET distribution. The undersigned acknowledges that he has read the CHATENET warranty terms and that he accepts without restriction.
- Page 38 NOTES...
- Page 39 CH40 NOTES...
- Page 40 www.automobiles-chatenet.com...
