JIMU ZDrive ADAS Driver Assistant
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZDrive ADAS and is the answer not in the manual?

Questions and answers

Summary of Contents for Jimu ZDrive ADAS

  • Page 1 JIMU ZDrive ADAS Driver Assistant User Manual...
  • Page 2 Introduction JIMU ZDrive ADAS Driver Assistant, based on self-developed graphic processing technology, is capable of reducing collision accidents with early warning when it detects potential collision dangers during driving, which also helps to improve users’ driving behaviors. JIMU ZDrive features lane departure warning, forward collision warning, headway monitoring and warning, virtual bumper, front drive-off...
  • Page 3 Features • Driving Behavior Analysis • Front Collision Warning • In-Car WiFi • Headway Monitoring and Warning • Cloud Radar Detector • Lane Departure Warning • Voice Navigation • Virtual Bumper • One -Touch Snapshot • Front Drive-Off Warning Front Collision Warning When there’s urgent tailgating danger due to car cut-in or front cars’...
  • Page 4 ZDrive Accessories Main Unit Display Unit Smart Sensor Charger Cable TF Card...

  • Page 5: Device Binding

    Device Binding Before install the device, you have to activate it following these steps : 1) Search “JIMU ZDrive” on Google play / App Store to download ZDrive App. 2) Register the app, and log in. 3) In the settings, find My Device, click to bind the device.

  • Page 6: Device Installation

    Device Installation 1) Insert SIM and TF card 2) Main Unit and Base Installation Install the tubular spirit level on the base, and then fix the base to the middle of the windshield, as high as possible ,but ~4cm gap to the top is suggested to be reserved for future uninstallation.
  • Page 7 3) Display Unit Installation Take off the sticker, and put it at a proper location that not influence drivers’ sight and the power cord could be properly connected.
  • Page 8 4) Smart Sensor Installation Open the back cover, put the battery in, and then place the sensor on the steering lever. Make sure the sensor is on the top side of the lever, and the button is on driver’s side instead of passenger’s side.
  • Page 9 5) Line Layout Connect the main unit, and display screen, and power them on, then you will see a red dot on the bottom of the screen; lights on main unit turn to blue. Main Unit Smart Sensor Display Unit Charger...
  • Page 10 6) Device Connection Open ZDrive APP, click on【device connection】: select JIMU_XXXXX WiFi, and the default password is 123456789 if you’re prompted to input one.
...
  • Page 11 7) Camera Calibration After device is connected, click on the 【+】mark on the APP to start camera calibration. Use the paddle to slightly adjust the camera screw, make sure the green skyline on the screen could be align with the middle part of your front car’s rear windshield.
...
  • Page 12 Display Unit Binding Click on to go to devices settings, select Display Unit, and turn on【Display Unit Bind】. When the red dot on screen turns green, the binding finishes.
...
  • Page 13 9) Smart Sensor Calibration In the Settings, select Sensor Calibration, then follow the instructions on the App to finish. • First of all, press the button on the sensor to activate the calibration; • Then activate the right turn signal, and press the sensor button; •...
  • Page 14 Other Settings In the Settings, you should define your car type, ADAS warning frequency, and the enabling of some features before use. Notes: • Car Type : Define your car type before use, otherwise the warning precision would be affected. •...

  • Page 15: Specifications

    • FAR (false alarm rate): 1/16H Vehicle Detections • Vehicle types: Cars, SUV, Trucks, Van trucks, Hopper trucks, Buses, Tricycles, Motorcycles, Bicycles, Electric bicycles, Flat cars, Special cars JIMU Display Unit Model JMS_V2.0 Dimension 93.2mm x 50.2mm x 15.6mm Display 2.4-in LC, 400nit...
  • Page 16 NOTES Before using JIMU ZDrive ADAS Driver Assistant ( hereinafter referred to as JIMU ZDrive ) , carefully read the following notes this user manual contains. Please note that JIMU ZDrive is not a substitute for safe and alert driving.
  • Page 17 JIMU INTELLIGENT www.jmadas.com service@jmadas.com...
