Summary of Contents for S-Conn 77451-70-POE
- Page 1 User Manual 77451-70-POE Twisted Pair POE Extender...
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... - Page 3 NOTICE: Please read this user manual carefully before using this product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till September 13, 2016. Any changes of functions and parameters since then will be informed separately. Please refer to the dealers for the latest details.
-
Page 4: Table Of Contents
Table of Contents 1. Introduction ......................... 1 1.1 Introduction ......................1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Product Appearance ....................2 2.1 Transmitter ......................2 2.2 Receiver ......................3 3. System Connection ..................... 4 3.1 Usage Precautions .................... 4 3.2 System Diagram .................... -
Page 5: Introduction
1. Introduction 1.1 Introduction This is an HDMI/IR/RS232 twisted pair including transmitter and receiver. The Extender uses HDBaseT technology to deliver HDMI signal, max transmission distance up to 70 meters with CAT5e/CAT6 cable. CEC, bi-directional RS232&IR control, and POE are supported. -
Page 6: Product Appearance
2. Product Appearance 2.1 Transmitter ON: Working status indicator of this device. When the device works fine, this green LED will keep blinking. And it will get off when the device stops work. LINK: Twisted Pair Link status indicator, green LED. It will keep on when connection is successful. -
Page 7: Receiver
2.2 Receiver ON: Working status indicator of this device. When the device works fine, this green LED will keep blinking. And it will get off when the device stops work. LINK: Twisted Pair Link status indicator, green LED. It will keep on when connection is successful. -
Page 8: System Connection
3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safety. 3) All devices should be connected before power on. 3.2 System Diagram INPUT Rs232... -
Page 9: Application
3.4 Application The Extender has a good application in various occasions, such as computer realm, monitoring, big screen displaying, meeting room, education and bank & securities institution etc. 3.5 Twisted Pair Cable Connection The twisted pair used in this extender MUST be a straight-through cable. TIA/EIA T568B TIA/EIA T568A Cable color... -
Page 10: Specification
4. Specification Model Transmitter Receiver Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm mini 3.5mm mini jack, RJ-45, 3p Input Connector jack, 3p captive screw captive screw connector connector Video Signal HDMI1.4... -
Page 11: Troubleshooting & Maintenance
5. Troubleshooting & Maintenance 1) When images of terminal unit output with ghost, such as the projector output with ghost. Generally this is not a unit faulty, this may be caused by an incorrect setting on the projector or a bad quality of cable. Please check the projector’s setting or try another high quality connection cable. - Page 12 S-Impuls Handels GmbH Am Mühlberg 8 91477 Markt Bibart Germany Tel: 09162-98-96-0 Fax: 09162-98-96-21 Email: info@s-impuls.de Website: www.s-impuls.de...
