Page 3: Table Of Contents
T A B L E O F C O N T E N T S INTENDED USE WAKE CAMERA SAFETY VIEW (MONITOR, CAMERA) CAUTION DELETE FROM MONITOR CARE INSTRUCTIONS MULTI-CAMERA SET-UP KIT CONTENTS PAIR ADDITIONAL CAMERAS OVERVIEW UNPAIR CHARGING SELECT CAMERA SINGLE CAMERA SET-UP SCAN POWER ON... -
Page 4: Intended Use
I N T E N D E D U S E Hyndsight Vision Systems, Inc. wireless cameras and monitors are to be used as an aid for visualizing blind spot conditions or for monitoring locations not always in clear sight. CAPTURE cameras have a memory card slot, and the monitor has built- in memory allowing the user to record events. - Page 5 Monitor are buoyant, they are not life saving devices and are not guaranteed to float when mounting brackets are at- tached. Hyndsight Vision Systems, Inc. is not responsible for loss or damage due to mounting bracket failure. Do not subject unit to prolonged exposure to rain, snow, and other outside environments.
-
Page 6: Caution
C A U T I O N In order to prevent improper operation of the AC Adaptor, please read the user manual carefully. For your safety, please use only the AC Adaptor provided. The manufacturer will not be responsible for any losses caused by converters and chargers not provided by the manufacturer. -
Page 7: Care Instructions
C A R E I N S T R U C T I O N S • If wet, dry unit completely before putting away. • If unit is exposed to salt water, rinse with clean water and allow to dry completely before putting away. •... -
Page 8: Kit Contents
K I T C O N T E N T S 1 Recording Monitor with 4GB Internal Memory 1 Recording Camera 2 Flush Mounting Brackets 2 USB Chargers 2 Antennas 1 Cleaning Cloth 1 Custom Padded Carrying Case 1 Instructions for use MicroSD card not included for camera* MicroSD card not included for camera. -
Page 9: Overview
O V E R V I E W Top Row (left to right): Signal strength, Camera being viewed, Scan ON, MicroSD card inserted, Mirror mode (F when forward mode), Monitor recording, Monitor overwrite enabled, Camera recording, Camera overwrite enabled, Monitor battery life, Camera battery life Bottom Row: Date/Time stamp Buttons: Power Light (green when on, red when charging), Power button, Back or Menu button, Select or Zoom shortcut, Left/Down... -
Page 10: Charging
C H A R G I N G Fully charge both devices before using. Either charger can be used with the camera or the monitor. To Charge CAPTURE • Connect the USB cable to the Wall Charger. • Firmly insert the straight jack into the Camera. Repeat for Monitor. •... -
Page 11: Single Camera Set-Up
S I N G L E C A M E R A S E T - U P Hyndsight recommends pairing Camera before mounting it. Using your best judgment, attach Antennas either before or after mounting Devices to desired surfaces. Power On* •... -
Page 12: Irror Image View
D A T E A N D T I M E Menu/Back (Twice) Select to choose field, Up/Down to change number Back to exit 20**/**/** **:**:** PAIR SCAN MIRROR PLAY TIME BRIGHT TIME ZOOM RECORD M I R R O R I M A G E V I E W Menu/Back (Twice) ... -
Page 13: Brightness & Night Mode
B R I G H T N E S S A N D N I G H T M O D E Menu/Back (Twice) Down arrow to decrease brightness Back to exit Up arrow to increase brightness PAIR SCAN MIRROR PLAY... -
Page 14: Record (Monitor, Camera)
R E C O R D Recordings can be made using up to a 32GB MicroSD card in the camera or can be stored directly on the monitor if no SD card is available. Note that images stored directly on the monitor cannot be removed or transferred, only previewed. Battery life averages 3-4 hours during recording. - Page 15 R E C O R D ( C O N T . ) Camera: Be certain to insert MicroSD card into camera before recording. Instructions for MicroSD card insertion can be found on page 9. SD Card icon will appear on home screen once card is fully inserted into the camera. TX Format completely erases camera MicroSD card.
- Page 16 W A K E C A M Put camera(s) in sleep mode when not in use to save battery life. Turn back on when ready to use. Menu/Back (Once) Select paired camera (i.e. Camera 2) ON wakes camera OFF sleeps camera Back to exit PAIR UNPAIR WAKE CAM...
- Page 17 V I E W Monitor: RX Format completely erases internal memory card. Menu/Back (Twice) Play DCIM Select dated folder PLAY PAIR SCAN MIRROR BRIGHT TIME ZOOM RECORD Playback Menu Options Back to Main Menu Pause/Play Recording Retreat or Rewind by 2x Speed Up Viewing by 2x, 4x, 8x, or 16x Camera:...
- Page 18 D E L E T E Monitor: RX Format completely erases internal memory card. Menu/Back (Twice) Play DCIM Select dated folder Menu Yes to Delete No to exit PLAY PAIR SCAN MIRROR BRIGHT TIME ZOOM RECORD...
-
Page 19: Multi-Camera Set-Up
M U LT I - C A M E R A S E T U P : P A I R A D D I T I O N A L C A M E R A S Menu/Back Select available camera ... -
Page 20: Select Camera
S E L E C T C A M E R A Menu/Back (Once) Select to view a specific camera while multiple cameras are paired Camera selected displays (i.e. choose between watching camera 3 or 4) on home screen (i.e. CAM 4) PAIR UNPAIR SELECT CAM... -
Page 21: Record
R E C O R D Please see instructions on Page 14 to record from Camera and/or Monitor. Recordings can be made using up to a 32GB MicroSD card in the camera or can be stored directly on the monitor’s 4GB internal memory. Note that images stored directly on the monitor cannot be removed or transferred, only previewed. -
Page 22: Flush Bracket Mounting
F L U S H B R A C K E T M O U N T I N G To attach the Camera or Monitor to the desired smooth, clean, flat, non-po- rous surface, follow the instructions below. Note: The mounting surface and the Suction Cup should be clean and dry. -
Page 23: Troubleshooting
T R O U B L E S H O O T I N G P R O B L E M S OLUTI ON Camera won’t pair automotically Press the Menu button. Select Pair. Press the Menu button. Select Pair. Toggle to an unpaired Camera (no X across camera number) Camera 1 icon is displayed as in use, but Press Enter. - Page 24 8. Hyndsight Vision Systems, Inc. reserves the right to add, delete, or amend the terms and conditions at any time without prior notice on its website, www.hyndsightvision.com. 9. A two (2) year warranty is extended to all purchases made in the United Kindgom. A two (2) year warranty is also extended to the Flush Mount; however, Hyndsight Vision Systems, Inc. is not responsible for loss of or damage to the product as a result of improper use of the mounting bracket.
- Page 25 Hyndsight Vision Systems, Inc. or its designee. e. The damage arising from operation with components or accessories not officially authorized or provided by Hyndsight Vision Systems, Inc. or used in ways other than its intended use. f. The damage arising from exposure to abnormally corrosive conditions or operation with extreme heat/cold or humidity HYNDSIGHT VISION SYSTEMS, INC.
- Page 26 2017 Manufactured in China for Hyndsight Vision Systems...
