- Page 1 *** USER’S MANUAL *** FCC ID : SRKWPBT55X...
- Page 2 The Federal Communication Commission Statement This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radio communication.
- Page 3 Wonde Proud Bluetooth GPS Receiver User’s Guide Jun. 12, 2004 V 1.0 Wound Proud Corporation 21F, NO. 100, SEC. 1, SINTAL 5 RD., SIJHIH CITY, TAIPEI COUNTY 221, TAIWAN, R. O. C. Tel:886-2-26961179 Fax: 886-2-26968499 Web: www.wondeproud.com Email: sales@wondeproud.com...
-
Page 4: Button & Signals
BT-55 Button & Signals LED2 LED1 Power Button External Power Socket BT-55 Quick Tips After acquiring your BT-55, proceed with the following steps: 1. Install battery prior to use. Battery needs to be charged for at least eight hours at the first time. Battery low When LED 1 flashes green light, it signals battery low. - Page 5 Make sure Bluetooth is turned on Click here to access Bluetooth Bluetooth mode Off Notice the Bluetooth symbol changed Bluetooth mode ON...
- Page 6 4. Activate Bluetooth Manager & Established New Connections Click here Click here Before going to next step, press Bluetooth GPS key for 4 seconds until LED 2 starting to flash, signaling the connecting is in progress. Click here Click here...
- Page 7 Use PDA pen to tap and select Click here to Click here to select activate input installation device Click here to select service Enter Pass Key "0000", Then Press “Enter” Enter key...
- Page 8 Click Click here here 4.10 At this point, Bluetooth GPS connection has been successfully established Established connection 4.11...
- Page 9 5. Connecting Bluetooth GPS with Electronic Map Access Electronic Map via COM 8 Click here Click here How to access electronic map – take “Papago” for example Click here Click here...
- Page 10 Press here after finishing setting up Select Click here COM 8 Set up 9600 bps Click here When selection and set up in illustration 5.5 remain unchanged, user may skip to next step, illustration 5.6 direct. Click here When LED 2 flashes, it is signaling Bluetooth GPS and the electronic map connection is in progress.
-
Page 11: About Signals
6.Turn off BT55 Press power button for 2 second or until LED1 indicator flashing red and green lights simultaneously. At the point, power will be automatically shut off. Suggest turn off electronic map first, then GPS, to avoid possible PDA /PC freeze. 7.
