Summary of Contents for Amroad P5

  • Page 1 AMROAD P5 HOME STATION Installation Manual...

  • Page 3: Table Of Contents

    AMROAD P5 CONTENTS CONTENTS CONTENTS ......... i WIRE CONNECTING ......11 PACKAGE CONTENTS ......1 The illustration of sockets ......11 The illustration of cable ......11 DIMENSION ........2 Ethernet cable ..........12 RESET BUTTON ........3 Power and Signal Cable ......13 INSTALLATION INSTRUCTIONS ..

  • Page 4: Package Contents

    AMROAD P5 PACKAGE CONTENTS PACKAGE CONTENTS 1. P5 front panel x1 5. F4-L30 screw x4 2. P5 body x1 6. Nylon Wall Plug x4 3. P5 wall rack x1 7. Relay Board x1 4. M3-L6 screw x2  square junction box (optional)

  • Page 5: Dimension

    AMROAD P5 DIMENSION DIMENSION...

  • Page 6: Reset Button

    AMROAD P5 RESET BUTTON RESET BUTTON Reset Button is located on the right side of P5 body (illustrated above). 2. To long press the reset button (for about 6 1. To short press the reset button (for secs) for recovering the device into factory approximately 3 secs) for resetting the default status (DHCP mode).

  • Page 7: Installation Instructions

    (as shown as Method_1 below). If users don’t want to drill holes in the wall, they can also fix the Amroad P5 onto a wall rack which has been screwed on an existing (square) junction box (please check the illustration of NOTE：The screw-holes of the junction box...

  • Page 8: Method - 1

    METHOD- 1 To Determine the Drilling Hole Position METHOD – 1 The determination of the drilling hole position The distance between the bottom of a junction box and the bottom of AMROAD P5 should not be less than 10 mm.

  • Page 9: Drilling

    AMROAD P5 METHOD - 1 The Drilling Drilling The users need to drill two 5mm holes in the wall, and the distance between these two holes is 141 mm.

  • Page 10: Nylon Wall Plug

    AMROAD P5 METHOD - 1 The Use of Nylon Wall Plug Nylon Wall Plug To smash the wall plug into these two 5 mm holes.

  • Page 11: The Fixation

    AMROAD P5 METHOD - 1 The Fixation of P5 Body The Fixation To screw the P5 BODY levelly.

  • Page 12: Method - 2

    AMROAD P5 METHOD - 2 Wall Rack Attachment METHOD – 2 The attachment To screw the wall rack onto the junction box levelly.

  • Page 13: The Fixation

    AMROAD P5 METHOD - 2 The Fixation of P5 Body The Fixation To screw the P5 BODY levelly.

  • Page 14: Wire Connecting

    AMROAD P5 WIRE CONNECTING The Illustration of Connecting Port WIRE CONNECTING The illustration of sockets The illustration of cable The illustration of Ethernet cable, signal cable The use of signal cable (DI/DO) and power and power cable are shown above.

  • Page 15: Ethernet Cable

    AMROAD P5 WIRE CONNECTING The Illustration of cable & wire Ethernet cable Please use stander RJ45 connectors.

  • Page 16: Power And Signal Cable

    AMROAD P5 WIRE CONNECTING Power and Signal Cable Power and Signal Cable The recommended length of bare wire is within the range between 10 to 12 mm.

  • Page 17: The Tool

    AMROAD P5 WIRE CONNECTING The tool to assist user for putting a wire into a connector The tool 1.5mm hex key...

  • Page 18: Operation

    AMROAD P5 WIRE CONNECTING To put a wire into a connector Operation Press the hex key into the hole lightly. 2. Keep pressing the hex key and put the wire into the side hole simultaneously. 3. Release the hex key.

  • Page 19: Front Panel Attachment

    3. To ensure the bottom of front panel is they are officially move in. fasten onto the P5 body. 2. If users need to take the front panel off the P5 body, please release the bottom part of the front panel first.

  • Page 20: Application

    AMROAD P5 APPLICATION Magnetic sensor APPLICATION Magnetic Sensor  AMROAD P5 provides 3D1 and 1DO for extensional applications purposes. Amroad has provides a Web interface for configuring these DI & DO setting.  In terms of the practical wiring diagram...

  • Page 21: Push Button

    AMROAD P5 APPLICATION Push Button Push Button  The practical wiring diagram of push button application is provided above.

  • Page 22: Gas Sensor & Flash Alarm

    AMROAD P5 APPLICATION Gas Sensor & Flash Alarm Gas Sensor & Flash Alarm  The practical wiring diagram is provided above.
  • Page 24 AMROAD TECHNOLOGY INC. 17F.-1, No.16, Jian 8th Rd., Zhonghe Dist., New Taipei City 235, Taiwan (R.O.C.) 886-2-8226-5686 886-2-8226-5687 info@amroad.com.tw WWW.AMROAD.COM.TW...
