MS-D245&D247 printer user manual
content
OVERVIEW............................................................................................................................................. 2
SPECIFICATION....................................................................................................................................4
POWER CONNECTION & POWER SUPPLY................................................................................... 6
........................................................................................................................................ 6
.......................................................................................................................................7
INTERFACE............................................................................................................................................ 8
...................................................................................................................................... 11
..........................................................................................................................................12
DIMENSION.......................................................................................................................................... 14
MS-D245............................................................................................................................................. 14
MS-D247............................................................................................................................................. 15
INSTALLATION & OPERATION..................................................................................................... 17
......................................................................................................................................... 17
................................................................................................................................. 21
............................................................................................................................................................. 21
................................................................................................................................... 21
MATTERS NEED TO ATTENTION.................................................................................................. 28
.................................................................................................................................28
.................................................................................................................................. 28
.............................................................................................................................. 29
..........................................................................................................................20
........................................................................ 25
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-D245 and is the answer not in the manual?

Questions and answers

Related Manuals for Shenzhen Masung Technology MS-D245

Summary of Contents for Shenzhen Masung Technology MS-D245

  • Page 1: Table Of Contents

    MS-D245&D247 printer user manual content OVERVIEW............................. 2 SPECIFICATION............................4 POWER CONNECTION & POWER SUPPLY................... 6 ............................6 OWER CABLE ............................7 OWER SUPPLY INTERFACE............................8 ............................11 ERIAL CABLE ............................12 CABLE DIMENSION............................14 MS-D245............................. 14 MS-D247............................. 15 INSTALLATION & OPERATION..................... 17 ............................17 IX PRINTER ..........................20...

  • Page 2: Overview

    Overview Special attention: MS-D245 and MS-D247 are 58mm thermal kiosk printers with auto cutter.  Functions: Can print many barcodes ,EAN8,EAN13,CODE39,CODE128,etc and QR code.  Application Fields: ATM, fuel dispenser, ticket vendor, coupon machine, etc.  Driver support: WindowsXP/Windows7/Windows8/Windows10 Android 4.0 and above,Ubuntu system.
  • Page 3 MS-D247 Difference: only support serial port. Max speed 200 mm/s ,printing width 54mm, power supply range : DC24V only...

  • Page 4: Specification

    Specification Model MS-D245 MS- D247 Printing method Dot line thermal printing Total dots per 384 dots 432dots line Printing speed 150mm/s 200mm/s print Printing width 48mm 54mm Paper width 58±0.5mm Paper thickness 56～95μm...
  • Page 5 FONT A 12*24dots FONT B 9*17dots character GB18030 Chinese 24*24dots GB2312 Chinese 16*16dots Thermal head Thermal sensors temperature Thermal head Mechanical switch switch Detection Out of Paper Reflective infrared light sensor detection Cutter detection photoelectric sensor Working voltage 24V±10% 9～24V Power Mean 1.75A Mean 2.5A...

  • Page 6: Power Connection & Power Supply

    Activation pulse 100,000000 resistance Service life Abrasion 100KM 100KM resistance About About W127mm*D90m W91.4mm*D52 Dimension m*H103.5mm(wi mm*H97.5mm(w dth*depth*height idth*depth*heigh Mass 125g 135g Communication interface Serial & USB Serial only Power connection & power supply Power cable Outside of power cable is GND，its inner pin diameter is 2.5mm.

  • Page 7: Power Supply

    Note: this cable is made by MASUNG. Length : 0.3 m PIN color Definition +12～+24V Black Power supply...

  • Page 8: Interface

    1. Make sure the printer power switch is off 2. Supplying power voltage range: MS-D245 : DC 9～24V , MS-D247: DC24V. 3. Plug in power cable 4. Switch on the power switch，in the meantime , look at green LED on printer panel, it will light on normally, or please switch off printer power immediately .
  • Page 9 MS-D247...
  • Page 10 Power extension Definition +24V Serial extension Definitions...

  • Page 11: Serial Cable

    Serial cable length :1.2 M ( made by MASUNG) Cable Pin definition:...

  • Page 12: Usb Cable

    USB cable Length: 1.5 M ( made by MASUNG)
  • Page 13 Cable Pin definition:...

  • Page 14: Dimension

    Dimension MS-D245 front view side view...

  • Page 15: Ms-D247

    bottom view MS-D247...
  • Page 16 Notice: we can use two kind printer metal structures for both model MS-D245 & MS-D247. ( because those two model printer heads and control boards are same size)

  • Page 17: Installation & Operation

    Installation & operation Fix printer Step1. Refer to printer dimension , user should open screw holes on their kiosk tray which are used for fixing printers. MS-D245 MS-D247...
  • Page 18 Step2. how to fix printer. When user gets printer , user will see the location holes MS-D245 on both sides of the printer as below. Install printer on kiosk tray, which has been prepared in step , then tightening screws...
  • Page 19 MS-D247...

  • Page 20: Loading Paper Roll

    Loading paper roll 1. printer is equipped with paper roll bracket ,User can put roll spindle through thermal paper roll then put whole roll on bracket made by MASUNG. 2. Make sure the thermal layer upward and load paper.(The printer will feed paper automatically when the printer is power on)

  • Page 21: Led Indicators

    LED indicators  Green POWER LED on: power on.  Red ERROR LED flash fast:power voltage incorrect.  Red ERROR LED flash:out of paper.  When paper near end sensor is working,printer enter paper near end status,the Red ERROR LED will light on. Self test page how to print self-test page: how to print self-test page:...
  • Page 22  Press feed button on printer head panel. As below  Then power on printer and Wait 2～3 seconds,release finger out of feed button,then printer will go with a test-page.
  • Page 23 Method B: Send command: 1D 28 41 02 00 00 02 ,user can also get the self-test page. Sample “ self-test page”, as below...

  • Page 25: How To Open Printer Head And Clear Jam Paper

    How to open printer head and clear jam paper When paper jam happened on printers.  Turn off the power and tear the paper before the paper feed mouth  Press yellow knob under printer head to open printer head.
  • Page 26  Take away paper fragment and clear printer head.
  • Page 27 Finally, close printer head and reload power and thermal paper.

  • Page 28: Matters Need To Attention

    Matters need to attention Safety matters 1. Do not apply voltage or current to any pins excess of the absolute maximum ratings.If voltage or current in excess of the absolute maximum ia applied,excess current will flow through the device,which may result in heat damage. 2.

  • Page 29: Storage Matters

    5. Never touch the printer head or motor driver at once directly after the printer has been working a long time, or will get scald. 6. There is great frication between the rubber roll and thermal head, so user cannot press feed button or print anything when there is no paper, or it can damage thermal sheet.
  • Page 30 *MASUNG has the right to change the contents of the manual without advanced statement!
