Askey Computer RT410W 802.11 a Operation Manual

Rt410w series station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RT410W series
S
t
a
t
i
o
n
S
t
a
t
i
o
n
O
p
e
r
a
t
i
o
O
p
e
r
a
t
i
o
n
M
a
n
u
a
n
M
a
n
u
a
l
l
All other product names and
trademarks in this document
are trademarks of their
respective companies.
2003/08/25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT410W 802.11 a and is the answer not in the manual?

Questions and answers

Summary of Contents for Askey Computer RT410W 802.11 a

  • Page 1 RT410W series All other product names and trademarks in this document are trademarks of their respective companies. 2003/08/25...
  • Page 2 No part of this publication may be reproduced in any form by any means without the prior written permission. Other trademarks or brand names mentioned herein are trademarks or registered trademarks of their respective companies. 2003/08/25 Rev:01 Safety Notes For Installation Use only the type of power source indicated on the marking labels.
  • Page 3 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 4 This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users, 2) The antenna should be integral if the end device is intended to be operated in 5.15 ~ 5.25GHz frequency range.

  • Page 5: Table Of Contents

    Contents Chapter 1: Introduction..................................6 System Requirements................................. 6 Unpacking ....................................6 Physical Outlook..................................8 Chapter 2: Connection.....................................9 LAN Connection..................................9 Connecting the power adapter..............................9 Setting up a Host PC .................................. 9 Wireless Network Connection..............................9 Chapter 3: Configuration via Web Browser..............................12 Using the Web Configuration..............................

  • Page 6: Chapter 1: Introduction

    Chapter 1: Introduction RT410W is 802.11a or 802.11b/g dual band wireless Ethernet dangle device. Below figure shows the general constitution of the system that uses the Ethernet dangle. An Ethernet dangle is a device that connected to a client (e.g., PC, CE - Consumer Electronics devices) with one to one with Ethernet.
  • Page 7 Ø This device Ø 12V Power Adapter and power cord Ø One Ethernet cable Ø Manual...

  • Page 8: Physical Outlook

    Physical Outlook Front Panel It is equipped with five LEDs on the front panel as described in the table below (from left to right): Color Status Description Active White Slowly Blinking RF work normally Status Blinking Blinking when firmware upgrade, production test indicate.

  • Page 9: Chapter 2: Connection

    Chapter 2: Connection LAN Connection Attach one end of the Ethernet cable with RJ-45 connector to the LAN port on a computer, and the other end to this device directly or through a hub. Connecting the power adapter Please connect the Station to the power connector port of the Power Adaptor and the other end of the Power Adaptor to a power outlet.

  • Page 12: Chapter 3: Configuration Via Web Browser

    Chapter 3: Configuration via Web Browser Using the Web Configuration Once your host PC is properly configured, start the web browser and type the URL 192.168.1.200 to enter the Web configuration page. You will be prompted to enter username and password. By default, the username and password are left blank.

  • Page 13: Home Page

    Home Page The Station comes with the default IP address of 192.168.1.200 and subnet mask of 255.255.255.0. Status This is the web page for the system information. It lists the firmware, MAC address and IP address for this Station.
  • Page 14 Firmware Version: It displays the version number of this device’s firmware. Connection Mode: It displays the connection mode such as Ad-Hoc or Infrastructure . Connected to SSID: It displays the SSID of the device that associated with this device. Using Channel: It displays the frequency that you selected for this device.

  • Page 15: Configuration

    Netmask: It displays the Netmask of this device. Configuration Wireless Setting To set the 802.11g security and encryption options for this AP, please open the Wireless Configurtion page. Any new setting will become effective after the Station is rebooted. Network Type: Select the one that the Station will be used to connect to.
  • Page 16 an AP connecting to a wired LAN, the clients in a Ad-Hoc network can only share resources with the peers but not be able to access resources on a wired network. When this device is configured as a Station and operates in Infrastructure mode, it will associate with an available AP installed on Ethernet network.
  • Page 17 this function. WEP Key Lengths: Select the WEP mode for the WEP key function. You can choose 40, 104 or 128-bit for your necessity. Choose the typing method of encryption key. You have to click either Hexadecima l digits or ASCII Text characters.
  • Page 18 IP address mode: If your network had implemented a DHCP server to assign an IP to this AP, you can select DHCP as the IP Address mode. And you don’t need to type the IP address below, subnet mask and gateway for the DHCP server will provide the required IP information for this device.
  • Page 19 Username: You can change the username for your necessity. Please type in the new username on this box. Password: Please enter the new password on this box. Re-enter Password: You have to retype the new password on this box for confirmation. After you click Apply, you have to enter the new password when you want to get into this web browser next time.

  • Page 20: Clone Mac

    Clone MAC If you want to connect to more than one PC through this Station, choose Disabled. Otherwise, click Enabled. Wireless LAN Mode Choose one of the wireless LAN mode listed below as the wireless communication way. 802.11a: The transmission speed is fast. Most countries support this function. 802.11a turbo: Faster than 802.11a, yet not all countries support this one.

  • Page 21: Appendix: Specifications

    Appendix: Specifications Appendix: Specifications Frequency Bands Feature Description Frequency & bands 2.4GHz : 2.412 to 2.462 GHz 2.412GHz(1ch),2.417GHz(2ch),2.422GHz(3ch),2.42 7GHz(4ch),2.432(5ch),2.437GHz(6ch),2.442GHz(7c h),2.447GHz(8ch),2.452GHz(9ch),2.457GHz(10ch), 2.462GHz(11ch) 5GHz Japan: 5.15 to 5.25 GHz USA: Band I : 5.18GHz(36ch),5.20GHz(40ch), 5.22GHz(44ch),5.24GHz,(48ch), Band II :5.26GHz(52ch),5.28GHz(56ch), 5.30GHz(60ch),5.32GHz(64ch) The wireless bands are factory preset. Standard IEEE 802.11a/g IEEE 802.3 and IEEE 802.3u...
  • Page 22 Wireless Features Feature Description 11a/g selection Configuration from Web page or HTTP commands SSID Name of the WLAN group. The same SSID can form the WLAN group Architecture Infrastructure (default) or Ad-Hoc mode Scan Scan the available AP list on the air, so dongle can choose which AP to associated.
  • Page 23 Appendix: Specifications...
  • Page 24 Physical Characteristics Feature Description PoE Port One 8-pin connector, including power and Ethernet LED(s) 2 LEDs Active – Slowly blinking while RF work normally (White) Status – Diagnostic and system states (RED) Dimensions PWB 77 x 78 mm Housing Palm-size housing Weight Humidity 10 to 90% non-condensing...
