Technical Manual

WHOLEHOUSE WATER FILTER

Models: SOF-WHF-

TM-EN-SOF-WHF-Rev2017.01

Table of Contents

Need help?

Do you have a question about the SOF-WHF series and is the answer not in the manual?

Questions and answers

Summary of Contents for Erie water treatment SOF-WHF series

Page 2: Table Of Contents
TABLE OF CONTENT Table of content ........................Page 2 Warning & Safety instructions ....................Page 3 Operating conditions & Requirements .................Page 4 Installation ...........................Page 5 Commissioning ........................Page 6 Electronic control panel .......................Page 7 Maintenance ........................Page 10 Troubleshooting ........................Page 12 Electrical wiring diagram ......................Page 13 Default configuration parameter settings................Page 14 Exploded view - System ......................Page 15 Exploded view - Timer assembly ..................Page 17...
Page 3: Warning & Safety Instructions
WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the appliance, we advise you read  and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in this Technical Manual.
Page 4: Operating Conditions & Requirements
OPERATING CONDITIONS & REQUIREMENTS OPERATING PRESSURE MIN-MAX: 2,0-8,3 bar / 29-120 psi   check water pressure regularly; it may fluctuate severely depending on the time of day, the day of the week or even the season of the year. ...
Page 5: Installation
INSTALLATION INLET & OUTLET DRAIN   We strongly recommend the use of flexible hoses to We recommend the use of a stand pipe with P-trap. connect the appliance to the water distribution system; use  To prevent backflow from the sewerage system into the hoses with a large diameter in order to limit the pressure appliance, always install and use the included drain adaptor loss.
Page 6: Commissioning
COMMISSIONING ELECTRICAL  Picture 4 1. Plug the transformers output lead into the socket on the control valves power cord; secure it by means of the TwistLock clamp. 2. Plug the transformer into an electrical outlet. PRESSURIZING 1. Make sure the bypass system is in 'bypass' position. 2.
Page 7: Electronic Control Panel
ELECTRONIC CONTROL PANEL  Picture 5 8:01 7 DAY REM symbol button function REGENERATION MODE to advance to the next SCROLL parameter In regeneration mode the display shows the remaining to increase the value of the regeneration time and the remaining cycle time: parameter to decrease the value of the Rgn:XXX CycY:ZZZ...
Page 8 ELECTRONIC CONTROL PANEL PROGRAMMING INSTRUCTIONS - PROGRAMMING INSTRUCTIONS - BASIC SETTINGS CONFIGURATION PARAMETERS   Before entering the programming mode, make sure that Before entering the programming mode, make sure that the appliance is in the service mode. the appliance is in service mode. ...
Page 9 ELECTRONIC CONTROL PANEL DIAGNOSTICS MODE  In the Diagnostics mode several operating parameters can be consulted; particularly during a service intervention, these parameters can be helpful to identify the cause of a problem or malfunction.  Before entering the Diagnostics mode, make sure that the appliance is in service mode.
Page 10: Maintenance
MAINTENANCE WITH 3-VALVE BYPASS SYSTEM (not included) RECOMMENDATION  Picture 7.a Notwithstanding the reliability of the appliance, we strongly recommend to have it serviced and maintained on a regular SERVICE POSITION basis by a competent and duly trained technician. He will be ...
Page 11: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Untreated water to Open or defective bypass Close or replace bypass service Appliance in regeneration Wait until regeneration finishes or manually advance regeneration to end Excessive water usage Initiate regeneration manually Change in raw water hardness Verify composition of incoming untreated water and adjust regeneration frequency accordingly Appliance fails to regenerate...
Page 12: Electrical Wiring Diagram
ELECTRICAL WIRING DIAGRAM   = position switches    = power lead  = drive motor  = auxilliary contact (24 VAC, max. 500mA)  = key pad      Page 12...
Page 13: Default Configuration Parameter Settings
DEFAULT CONFIGURATION PARAMETER SETTINGS Model SOF-WHF- Filter media Units Metric Metric Metric MaintInt (mths) Cycle 1: BACKWASH (min) Cycle 2: SLOW RINSE (min) Cycle 3: PURGE (min) Regen @ 0:00 0:00 0:00 Page 13...
Page 14: Exploded View - System
EXPLODED VIEW - SYSTEM Page 14...
Page 15 1 cuft A2000 Quartz sand multiple of 25 kg (=17 ltr) A1000 Gravel multiple of 25 kg (=17 ltr) 39004 Dome label ‘erie water treatment’ 39099 Label ‘Softena’ (mini) 39100 Label ‘Softena’ (midi) 39101 Label ‘Softena’ (maxi) J/1018(W)
Page 16: Exploded View - Timer Assembly
EXPLODED VIEW - TIMER ASSEMBLY Page 16...
Page 17 EXPLODED VIEW - TIMER ASSEMBLY Item Description Remark  70971 Power lead with plug 72263 Clamp 28/244/1 Plug (large) 71502 Screw, timer cover (3x) 15/222 Screw, back plate (2x) 70962 Back plate 75157 Worm coupling  15/222 Screw, drive motor assembly (2x) 74267 Cable clamp 70312...
Page 18: Exploded View - Valve Body
EXPLODED VIEW - VALVE BODY Page 18...
Page 19 EXPLODED VIEW - VALVE BODY Item Description Remark 21/83 Drain connection 568/271/M Backwash flow control M (18,9 ltr/min) 72678 Bolt, valve cover (6x) 568/254/3 Valve cover 185/154/1 O-ring, valve cover 186/112 O-ring, Teflon 72327 Washer, PE 568/260 Worm gear 568/259 Rotor cam 185/041/1 O-ring, rotor...
Page 20: Technical Data
TECHNICAL DATA Technical specifications: Model SOF-WHF- Filter media (cuft) Operating pressure min/max (bar) 2,0/8,3 Operating temperature min/max (°C) 2/48 Electrical connection (V/Hz) 230/50 Max. power consumption (VA) Hydraulic connection inlet/outlet 1” BSP Male Hydraulic connection drain 13 mm hose barb Pressure tank 10x18 10x35...
Page 21 Page 21...
Page 22 Page 22...
Page 23 Page 23...
Page 24 Manufactured & Assembled by erie water treatment a division of Aquion, Inc. www.eriewatertreatment.com...
