Summary of Contents for GGS-Data Style-Note M74xTG

  • Page 1 V09.2.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

  • Page 6: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 9: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.

  • Page 10: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 11: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 12: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 15: Lcd Screen Care

    Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
  • Page 16 Preface...

  • Page 17: Table Of Contents

    Preface Contents Notice .................I Hot Key Buttons ............1-10 FCC Statement .............II Keyboard - Models A & B ...........1-11 FCC RF Radiation Exposure Statement: ....III Keyboard - Model C ............1-12 Instructions for Care and Operation ......V Function/Hot Key Indicators ........1-13 Power Safety .............VII System Map: Front &...
  • Page 18 Preface TouchPad and Buttons/Mouse ........2-8 Proper handling of the Battery Pack ......3-13 Audio Features .............2-10 Battery FAQ ..............3-14 Adding a Printer ............2-11 Drivers & Utilities USB Printer ..............2-11 Parallel Printer ............2-11 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-4...
  • Page 19 Preface BIOS Utilities Set User Password (Security Menu) ......5-12 Fixed disk boot sector: (Security Menu) ......5-12 Overview ................5-1 Password on boot: (Security Menu) ......5-12 The Power-On Self Test (POST) ........5-2 Boot Menu ..............5-13 Failing the POST ............5-3 Exit Menu ..............5-14 Fatal Errors ..............5-3 Non-Fatal Errors ............5-3 Upgrading The Computer...
  • Page 20 Preface Contacts ..............7-25 Interface (Ports & Jacks) Messages ..............7-26 Overview ...............A-1 Settings ..............7-27 Notebook Ports and Jacks ..........A-2 Mobile Partner ............7-29 Mobile Partner Application Installation ....7-29 Intel Video Driver Controls Mobile Partner Application ........7-30 Intel Video Driver Installation ........B-1 Profile Management ..........7-30 Video .................
  • Page 21 Preface Interface ................ C-3 CardReader ..............D-11 Card Reader ..............C-3 Hot Key ...............D-11 Slots ................C-3 Optional Drivers ............D-11 Communication ............. C-3 Wireless LAN Module..........D-12 Power Management ............C-3 Intel® Wi-Fi Link Series Driver Installation ....D-13 Power ................C-3 3rd Party 802.11b/g Driver Installation ......D-13 Security .................
  • Page 22 Preface...

  • Page 23: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 24: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 25: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows Vista/Windows 7) and applications (e.g. word processing, spreadsheet and da- tabase programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 26: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported.

  • Page 27: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 28: System Map: Lcd Panel Open - Model A

    Quick Start Guide System Map: LCD Panel Open - Model A Figure 1 - 2 LCD Panel Open (Model A Computers) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic trans- mission devices aboard aircraft is usual- Speakers ly prohibited.

  • Page 29: System Map: Lcd Panel Open - Model B

    Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 3 LCD Panel Open (Model B Computers) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic trans- mission devices aboard aircraft is usual- Speakers ly prohibited.

  • Page 30: System Map: Lcd Panel Open - Model C

    Quick Start Guide System Map: LCD Panel Open - Model C Figure 1 - 4 LCD Panel Open (Model C Computers) Wireless Device Built-In PC Camera Operation Aboard Aircraft (Optional) The use of any portable electronic Power Button transmission devices aboard air- Hot Key Buttons craft is usually prohibited.

  • Page 31: Led Indicators

    Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Green Hard Disk Activity Green Number Lock Activated Green Caps Lock Activated Green Scroll Lock Activated (to activate press Fn & Scr Lk) Orange DC Power is Plugged In Green...

  • Page 32: Hot Key Buttons

    Quick Start Guide Hot Key Buttons These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode on/off with one quick button press. Hot Key Function Activate the Default E-Mail Browser (Note that In Windows 7 without Outlook/Outlook Express installed this button has no function.

  • Page 33: Keyboard - Models A & B

    Quick Start Guide Keyboard - Models A & B The keyboard has a numerical keypad for easy numeric data input, and features func- Other Keyboards tion keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 13 for full function key combination details.

  • Page 34: Keyboard - Model C

    Quick Start Guide Keyboard - Model C The keyboard (Model C only) has a numerical keypad on the right for easy numeric data input, and features func- tion keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 13 for full function key combination details.

  • Page 35: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...

  • Page 36: System Map: Front & Left Views

    Quick Start Guide System Map: Front & Left Views Figure 1 - 7 Front & Left Views LED Power & Com- munication Indica- tors DC-In Jack External Monitor Port RJ-45 LAN Jack Vent/Fan Intake/ Outlet 2 * USB 2.0 Ports 7-in-1 Card Reader ExpressCard Slot The card reader allows you to use the most popular digital storage card formats:...

  • Page 37: System Map: Right & Rear Views

    Quick Start Guide System Map: Right & Rear Views Figure 1 - 8 Right & Rear Views S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack USB 2.0 Port Optical Device Drive Bay (for CD/ DVD Device - see page RJ-11 Phone Jack Changing DVD Regional Codes Security Lock Slot CD/DVD Emergency Eject...

  • Page 38: System Map: Bottom View - Models A & B

    Quick Start Guide System Map: Bottom View - Models A & B Figure 1 - 9 Bottom View (Models A & B) Battery Information Battery Bluetooth Module Always completely discharge, then fully Cover charge, a new battery before using it. Com- Model A RAM &...

  • Page 39: System Map: Bottom View - Model C

    Quick Start Guide System Map: Bottom View - Model C Figure 1 - 10 Bottom View (Model C Computers) Battery Information Battery Always completely dis- charge, then fully charge, a RAM & CPU Bay new battery before using it. Cover Completely discharge and Vent/Fan Intake/ charge the battery at least...

  • Page 40: Windows Vista Start Menu & Control Panel

    Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 41: Video Features

    Quick Start Guide Video Features This computer features Intel integrated video. You can switch display devices, and configure display options, from the Display Settings control panel (in Personalization) in Windows Vista. To access Display Settings in Windows Vista: Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Adjust screen resolution under the Appearance and Personalization menu (or double-click Personalization >...

  • Page 42: Display Settings & Video Control Panel

    Quick Start Guide Display Settings & Video Control Panel Figure 1 - 12 - Display Settings & Video Control Panel 1 - 20 Video Features...

  • Page 43: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 17) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
  • Page 44 Quick Start Guide 1 - 22...

  • Page 45: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 7-in-1 Card Reader • ExpressCard Slot •...

  • Page 46: Hard Disk Drive

    Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.

  • Page 47: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 2). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 48: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.

  • Page 49: Dvd Regional Codes

    Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 50: 7-In-1 Card Reader

    Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 51: Expresscard Slot

    Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you install the Card Reader driver (see “CardReader”...

  • Page 52: Touchpad And Buttons/Mouse

    Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse (see pages 1 - 6/1 - 7/1 - There are two touchpad versions (and driver/application software) available for this computer model series.
  • Page 53 Features & Components Figure 2 - 6 Mouse Properties TouchPad and Buttons/Mouse 2 - 9...

  • Page 54: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).

  • Page 55: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
  • Page 56 Features & Components 2 - 12...

  • Page 57: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 58: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.

  • Page 59: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...

  • Page 60: Power Plans

    Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.

  • Page 62: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.

  • Page 63: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Hibernate Mode In power failure occurs the system can restore your work from the hard disk; if a power Windows Vista SP1 failure occurs when work is saved only to memory, then the work will be lost.

  • Page 64: Configuring The Power Buttons

    Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.

  • Page 65: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...

  • Page 66: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.

  • Page 67: Conserving Battery Power

    Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 68: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.

  • Page 69: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 70: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 71 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 72 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 73: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.

  • Page 74: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers/Option Drivers (button).
  • Page 75 Drivers & Utilities Manual Driver Installation Driver - Windows Vista Service Pack 2 Page Click Browse CD (button) in the Drivers Installer ap- plication and browse to the executable file in the ap- Chipset Page 4 - 5 propriate driver folder. Video Page 4 - 5 Audio...

  • Page 76: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...

  • Page 77: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Chipset Insert the Device Drivers & Utilities + User’s Manual 1. Click 1.Install Chipset Driver > Yes. disc and click Install Drivers (button). 2. Click Next > Yes > Next > Next. 3. Click Finish to restart the computer. Video Driver Installation General Guidelines 1.

  • Page 78: Audio

    Drivers & Utilities Audio 1. Click 3.Install Audio Driver > Yes. 1. Click 5.Install LAN Driver > Yes. 2. Click Next. 2. Click Next > Install. 3. Click Finish to restart the computer. 3. Click Finish. 4. The network settings can now be configured. Modem TouchPad 1.

  • Page 79: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- Windows Update tion. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- dates etc.

  • Page 80: Pc Camera Module

    Drivers & Utilities Bluetooth Module Note: The operating system is the default setting for Bluetooth control in Windows Vista, and does not re- quire a driver. See “Bluetooth Module” on page 7 - 2 for configuration instructions. PC Camera Module See the introduction in “PC Camera Module”...

  • Page 81: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.

  • Page 82: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...

  • Page 83: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 84: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds...

  • Page 85: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.

  • Page 86: Main Menu

    BIOS Utilities Main Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [04/18/2008] <Tab>, <Shift Tab>, or SATA Port 1 [FUJITSU MHW2080BH PL] <Enter> selects field. SATA Port 2 [Optiarc DVD RW AD-75] SATA Port 4...

  • Page 87: Sata Port 1/2/4 (Main Menu)

    BIOS Utilities SATA Port 1/2/4 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a hard disk or op- tical device drive on the computer’s SATA Ports. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable.

  • Page 88: Advanced Menu

    BIOS Utilities Advanced Menu Phoenix SecureCore(tm) Setup Utility Main A A dvanced Advanced Security Boot Exit Item Specific Help Advanced Chipset Control Installed O/S: [Vista] Select options for SATA Mode Selection: [AHCI] Figure 5 - 3 Advanced Chipset Legacy USB Support: [Enabled] features.

  • Page 89: Installed O/S (Advanced Menu)

    BIOS Utilities Installed O/S (Advanced Menu) This setting tells the computer what kind of operating system you’re using. Make sure you choose the correct setting for your O/S in order to prevent system problems. SATA Mode Selection (Advanced Menu) This menu is only available if you select the Vista O/S as your operating system. You can configure SATA (Serial ATA) control to operate in either IDE (native/ compatible) or AHCI (Advanced Host Controller Interface) modes from this menu.

  • Page 90: Legacy Os Boot: (Advanced Menu)

    BIOS Utilities Legacy OS Boot: (Advanced Menu) Enable this item to support only system boot from the Legacy OS (e.g Windows Vis- ta). If disabled the system will attempt to boot from the EFI (Extensible Firmware Interface) before the Legacy OS. Reset Configuration Data: (Advanced Menu) This item is set to No as default.

  • Page 91: Security Menu

    BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Security Menu Security Main Advanced S S e e c c u u r r i i t t y y Boot Exit changes Item Specific Help Supervisor Password Is: Clear make here affect the User Password Is: Clear access to the Setup...

  • Page 92: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the PhoenixBIOS Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you Password Warning choose to set a Password on Boot (see below). Many menu items in the Phoenix- If you set a boot pass- BIOS Setup Utility cannot be modified in user mode.

  • Page 93: Boot Menu

    BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: IDE CD: TSSTcorp CDDVDW TS-L633A-( Keys used to view or USB CDROM: configure devices: IDE HDD: FUJITSU MHY2120BH-(PM) USB KEY: Up and Down arrows USB HDD:...

  • Page 94: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...

  • Page 95: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...

  • Page 96: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...

  • Page 97: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.

  • Page 98: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (see...
  • Page 99 Upgrading The Computer Grip the tab and slide the hard disk in the direction of arrow Lift the hard disk out of the bay Model A Figure 6 - 3 HDD Removal Model B Model C Upgrading the Hard Disk Drive 6 - 5...
  • Page 100 Upgrading The Computer Remove the screw(s) & and the adhesive cover (depending on your model type/design). Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers). Figure 6 - 4 HDD Cover Removal Hard Disk Screws &...

  • Page 101: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Model A: Locate the RAM & CPU bay cover and remove screws Fan Cable Carefully (a fan and cable are attached to the under side of the cover) lift up Make sure you recon- the bay cover.
  • Page 102 Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device. Model A Models B & C Figure 6 - 6 (Only one model pictured) Removing the Optical Device...

  • Page 103: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 104 Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable , and remove the cover Figure 6 - 8 CPU/RAM Bay Cover Removed Fan Cable Make sure you reconnect the fan cable before screwing down the bay cover.
  • Page 105 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 9 RAM Module Release Latches Contact Warning The RAM module will pop-up, and you can remove it.
  • Page 106 Upgrading The Computer Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket (see sidebar note if you are inserting a single module). The module’s pin alignment will allow it to only fit one way.
  • Page 107 Upgrading The Computer 12. Restart the computer to allow the BIOS to register the new memory configuration as it starts up. Figure 6 - 12 Cover Pin Alignment Model A Model B Cover Pins Note that these comput- er models have cover pins that need to be aligned with slots in the case to insure a proper...
  • Page 108 Upgrading The Computer 6 - 14...

  • Page 109: Modules & Options

    Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.

  • Page 110: Bluetooth Module

    Modules & Options Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Wireless Device Bluetooth settings in Windows Vista, and therefore does not require a driver. Use Operation Aboard the Fn + F12 key combination (see Table 1 - 4, on page 1 - 13) to toggle power to Aircraft...

  • Page 111: Bluetooth Configuration In Windows Vista

    Modules & Options Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon To Turn the Bluetooth Module On If you cannot see the...
  • Page 112 Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Bluetooth Settings. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it, and click OK. Pairing Options Click Add Wireless Device in the Bluetooth Devices control panel.
  • Page 113 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure 7 - 3 Pairing Codes Pairing Code The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
  • Page 114 Modules & Options To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...

  • Page 115: Pc Camera Module

    Modules & Options PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is Latest PC Camera on. Use the Fn + F10 key combination (see Table 1 - 4, on page 1 - 13) to toggle Driver Information power to the PC Camera module.

  • Page 116: Pc Camera Driver Installation

    Modules & Options PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3. Click 1.Install WebCam Driver > Yes. The PC Camera module 4.
  • Page 117 Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel).
  • Page 118 Modules & Options Figure 7 - 6 Audio Setup for PC Camera Right-click 7 - 10 PC Camera Module...
  • Page 119 Modules & Options Camera Application The WebCam application is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Size/Space Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see “Set Capture File”...
  • Page 120 Modules & Options Set Capture File Prior to capturing video files you may select the Set Capture File... option in the File menu, and set the file name and location before capture (this will help avoid ac- cidentally overwriting files). Set the name and location then click Open, then set the "Capture file size:"...
  • Page 121 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
  • Page 122 Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
  • Page 123 Modules & Options Zoom The WebCam program allows you to zoom the camera in and out. Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 8 Zoom/Setting Taking Still Pictures The WebCam program allows you to take still pictures.

  • Page 124: 3.75G/Hspa Module

    Modules & Options 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module 3.75G/HSPA Module (see “Communication” on page C - 3 for specification details) in your purchase op- Options tion, you will have the appropriate software provided for your module. Follow the instructions overleaf to install the USIM card (supplied by your service provider), There are two optional and then install the appropriate application.
  • Page 125 Modules & Options Turn off the computer, and turn it over and remove the battery. Access the SIMLOCK as follows: • For Model B: Locate the SIM card cover and loosen screw , and then remove Power Safety the SIM card cover Warning •...
  • Page 126 Modules & Options Insert the USIM card as you would into your mobile phone. Slide the SIMLOCK towards the hinge in order to release the lock and lift it up. Insert the USIM card as illustrated in (Figure 7 - 10) and close the SIMLOCK.
  • Page 127 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 4, on 3.75G/HSPA page 1 -...

  • Page 128: Hspa Modem Interface

    Modules & Options HSPA Modem Interface With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the HSPA Modem Interface. The HSPA Modem In- Wireless Device terface allows you to directly access your HSPA internet service from the computer. Operation Aboard Aircraft HSPA Modem Interface Installation...

  • Page 129: Hspa Modem Interface

    Modules & Options HSPA Modem Interface The connection information is stored on the USIM card supplied by the service pro- vider. HSPA Modem Help Power on the 3.75G/HSPA module using the Fn + key combination. To get help on 3.75G/ Access the HSPA Modem Interface from the Start menu (Start >...
  • Page 130 Modules & Options Click Connect to connect to your service provider. Figure 7 - 13 Connecting to Network The message “Network is connected” will be displayed when the network connection is successful. Figure 7 - 14 Network is Connected You can then access the internet, download e-mail etc. as per any internet connection.

  • Page 131: Adding A Profile

    Modules & Options While you are connected the upper right corner of the HSPA Modem interface will display the upload and download rates, and the taskbar icon will display the connection speed. Figure 7 - 15 Uploading/ Downloading Rates and Speed 10.
  • Page 132 Modules & Options Click Add (button) and input any Network Settings required by your service provider. Click OK to save the profile. Figure 7 - 17 Network Settings & Profiles You can Edit or Delete profiles from the Profiles tab. To use a profile click to select it, and then click Apply (button) and the settings will be transferred to Connection Manager.

  • Page 133: Contacts

    Modules & Options Contacts Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. Click Contacts (button). Figure 7 - 18 Network Settings & Profiles Click Refresh (button) to download the contacts from the USIM card to the computer.

  • Page 134: Messages

    Modules & Options Messages Access the HSPA Modem Interface from the Start menu (Start > Programs/All Programs > HSPA Modem > HSPA Modem), or by clicking the desktop icon. SMS Service Click Messages (button). In addition to standard in- ternet services you may also send and receive SMS text messages us- ing the HSPA Modem In-...

  • Page 135: Settings

    Modules & Options Click to select a contact from the list and then click Add (button) and the phone number will automatically be added to the recipient field. Type the message information into the message body and click Send (button) to send it, or Save to draft (button) to save the message.
  • Page 136 Modules & Options Click OK alongside any of the options to configure the settings. The Network can be configured for an Automatic (usually from the USIM card) or Manual connection. The Network Mode can be configured for any appropriate mode required. Figure 7 - 21 Settings - Network/ Network Mode...

  • Page 137: Mobile Partner

    Modules & Options Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard puter.

  • Page 138: Mobile Partner Application

    Modules & Options Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
  • Page 139 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
  • Page 140 Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 25 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
  • Page 141 Modules & Options 11. The module will still be on, and you will need to press the Fn + key combination to turn it off. 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection.

  • Page 142: 7 - 34 Wireless Lan Module

    Modules & Options Wireless LAN Module If you have included an Intel® Wi-Fi Link 1000 Series (802.11 b/g/n) or 3rd Party Wireless Device 802.11b/g/n WLAN module in your purchase option, make sure that the Wireless Operation Aboard LAN module is on before installing the driver. Aircraft Use the Fn + F11 key combination (see “Function/Hot Key Indicators”...

  • Page 143: Intel® Wi-Fi Link 1000 (802.11 B/G/N) Series Driver Installation

    Modules & Options Intel® Wi-Fi Link 1000 (802.11 b/g/n) Series Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.

  • Page 144: Connecting To A Wireless Network

    Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 28 Taskbar Menus Click icon...
  • Page 145 Modules & Options Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network).
  • Page 146 Modules & Options To disconnect from the wireless network you can click the taskbar wireless icon and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make...

  • Page 147: Intel My Wifi Installation & Configuration

    Modules & Options Intel My WiFi Installation & Configuration ® Intel® My WiFi Technology uses your WLAN module to allow you to connect up to eight other WiFi enabled devices (e.g. digital cameras, other computers, cell Intel® My WiFi Help phones, handheld devices etc.) to your computer (similar to Bluetooth), while still To get help on Intel®...

  • Page 148: Intel® Wi-Fi Link 1000 (802.11 B/G/N) Series Driver Installation

    Modules & Options Intel® Wi-Fi Link 1000 (802.11 b/g/n) Series Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.
  • Page 149 Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon Click Enable (on the first run of the program there will be no connected...
  • Page 150 Modules & Options Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Network and Sharing Center (Network and Internet). Click Manage Network Connections. Click Manage Network Connections Figure 7 - 36 Network and Sharing Center Right-click Intel WiFi STA (Station) in Network Connections and select Properties.
  • Page 151 Modules & Options Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Intel My WiFi PAN under Home Networking Connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”.
  • Page 152 Modules & Options 10. A message will appear to inform you that the LAN adapter will be set to use the IP address 192.168.0.1. Figure 7 - 39 11. Click Yes to enable Internet Connection Sharing. IP Address Warning IP Addresses The Intel®...
  • Page 153 Modules & Options 14. Click Profiles, click Intel Wireless PAN and click Edit. Figure 7 - 41 IP Address Warning 15. You can change the Profile Name and Network Name to your personal preferences in General (tab). Profile and Network Names The Profile Name is the name as Figure 7 - 42 displayed on your computer in the...
  • Page 154 Modules & Options 16. Click Security (tab). 17. Change the Security Type to WEP and the Encryption Type to 64bit. 18. Enter a password (5 characters long) in the Passphrase box. 19. Click OK. Figure 7 - 43 Intel® My WiFi Profile Settings - Security 7 - 46 Wireless LAN Module...
  • Page 155 Modules & Options 20. Click Sharing (tab). 21. Make sure Filter Network Traffic and DHCP and DNS Server are Disabled. 22. Click OK. Set Filter Network Traffic & DHCP and DNS Servers Figure 7 - 44 to Disabled. Intel® My WiFi Profile Settings - Sharing Wireless LAN Module 7 - 47...
  • Page 156 Modules & Options 23. Click Advanced (tab). 24. Make sure the Default Channel is set to Channel 1, 6 or 11. 25. Click OK. Figure 7 - 45 Intel® My WiFi Profile Settings - Advanced 7 - 48 Wireless LAN Module...
  • Page 157 Modules & Options 26. Double-click Intel My WiFi PAN (Personal Area Network) in Network Connections. 27. Click Details to display the Network Connection Details. Figure 7 - 46 Intel My WiFi PAN Network Connection Details (Network Connections) Wireless LAN Module 7 - 49...
  • Page 158 Modules & Options 28. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon 29. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.

  • Page 159: Windows Mobility Center

    Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
  • Page 160 Modules & Options 7 - 52...

  • Page 161: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 162: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 163: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 164: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 165: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 166 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 167: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
  • Page 168 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...

  • Page 169: Table

    Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
  • Page 170 Troubleshooting Problem Possible Cause - Solution Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
  • Page 171 Troubleshooting Problem Possible Cause - Solution The PC Camera module cannot be The module is off. Press the Fn + F10 key combination in order to enable the detected. module (see “Function/Hot Key Indicators” on page 1 - 13). Run the BisonCap program to view the camera picture.
  • Page 172 Troubleshooting Problem Possible Cause - Solution The Hibernate function has disappeared. You have a computer with 4GB of RAM and have installed Windows Vista Serv- ice Pack 1. This is a known issue if your computer has 4GB of RAM and is run- ning Windows Vista Service Pack 1.

  • Page 173: Screen Resolution Error

    Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
  • Page 174 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. 8 - 14 Screen Resolution Error...

  • Page 175: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 176: Notebook Ports And Jacks

    Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
  • Page 177 Interface (Ports & Jacks) Item Description RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store.
  • Page 178 Interface (Ports & Jacks) A - 4...

  • Page 179: Intel Video Driver Controls

    Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Intel Video Driver Installation Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - Video 1.

  • Page 180: Dynamic Video Memory Technology

    Intel Video Driver Controls Dynamic Video Memory Technology ® Intel DVMT automatically and dynamically allocates as much (up to 512MB) sys- tem memory (RAM) as needed to the video system (the video driver must be in- DVMT Notes stalled). DVMT returns whatever memory is no longer needed to the operating DVMT is not local video system.

  • Page 181: Intel Graphics Properties

    Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for mobile control panel. The Intel GMA control Open the Display Settings control panel (see “Video Features” on page 1 - panel can also be ac- and click Advanced Settings (button).
  • Page 182 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Help Menus Right-click on many of the items in the tabs to bring up the “What’s This?”...

  • Page 183: Scheme Options

    Intel Video Driver Controls Scheme Options Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate Open the Display Settings control panel and click Advanced Settings (button).

  • Page 184: Attaching Other Displays

    Intel Video Driver Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor/flat panel display, Function Key connected to the external monitor port at the rear of the computer, as your display Combination device. The following are the display options: You can use the Fn + F7 The built-in LCD OR an external monitor/flat panel display connected to the exter- key combination to tog-...
  • Page 185 Intel Video Driver Controls ® Configuring Other Displays from Intel GMA Driver for Mobile Attach your external monitor to the external monitor port, and turn it on. Go to the Intel(R) GMA Driver for mobile control panel (see “Intel Graphics Display Selection Properties”...

  • Page 186: B - 8 Display Modes

    Intel Video Driver Controls Display Modes Single Display Video Settings Only one of your attached displays is used. Click Video Settings (button) in the Intel(R) Intel(R) Dual Display Clone (mirrored) GMA Driver for mobile This mode will drive multiple displays with the same content. Each device may be control panel to access settings for Video Qual- configured independently for different resolutions, refresh rates, color quality etc.
  • Page 187 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Attach your external monitor to the external monitor port, and turn it on. Go to the Intel(R) GMA Driver for mobile control panel (see “Intel Graphics Properties” on page B - 3) and click Display Devices.
  • Page 188 Intel Video Driver Controls To Enable Extended Desktop Attach your external monitor to the external monitor port, and turn it on. Go to the Intel(R) GMA Driver for mobile control panel (see “Intel Graphics Display Settings Properties” on page B - 3) and click Display Devices.
  • Page 189 Intel Video Driver Controls Using Windows Vista to Enable Extended Mode Attach your external monitor to the external monitor port, and turn it on. Go to the Windows Mobility Center control panel (Mobile PC > Adjust Display Settings commonly used mobility settings) and click Connect display. Extended Desktop Click to select Show different parts of my desktop on each display (extended).
  • Page 190 Intel Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external monitor to the external monitor port, and turn it on. Open the Display Settings control panel (see “Video Features” on page 1 - 19). Click the monitor icon (e.g. ), and make sure you have checked “Extend the desktop onto this monitor”...

  • Page 191: Intel Clear Video Technology

    Intel Video Driver Controls Intel Clear Video Technology Intel Clear Video Technology (for Windows Vista 32-bit versions only) is designed TV Wizard to help users get high-quality video playback, sharp image quality, precise color con- trol and advanced support for the latest High Definition displays without the need Use the TV Wizard to for expensive video cards etc.
  • Page 192 Intel Video Driver Controls B - 14...

  • Page 193: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.

  • Page 194: Processor

    Specifications Processor Display BIOS Intel® Celeron® Processor Model A: One 16Mb SPI Flash ROM T3100 (1.9GHz), T3000 (1.8GHz) 14.1” WXGA (1280 * 800) TFT LCD Phoenix™ BIOS 45nm (45 Nanometer) Process Model B: Storage Technology, 1MB L2 Cache & 800MHz 15.4”...

  • Page 195: Interface

    Specifications Interface Communication Power Management Three USB 2.0 Ports Built-In 56K MDC Modem, V.90 & V.92 Supports Wake on LAN Compliant One Headphone-Out Jack Supports Wake on USB One Microphone-In Jack Supports Wake on Modem Ring Built-In Gigabit Ethernet LAN One S/PDIF-Out Jack 802.11b/g Wireless LAN Mini-Card Power...

  • Page 196: Environmental Spec

    Specifications Environmental Spec Optional Temperature Super Multi Optical Device Drive ° ° Operating: C - 35 802.11b/g Wireless LAN Mini-Card Non-Operating: -20°C - 60°C Module with USB Interface Relative Humidity Intel® WiFi Link 1000 Series (802.11b/g/ Operating: 20% - 80% n) Wireless LAN PCIe interface Half Mini- Non-Operating: 10% - 90%...

  • Page 197: Windows 7 Information

    Windows 7 Information Appendix D: Windows 7 Information This Appendix contains information on the driver installation for the Windows 7 OS. Note that control panels (e.g. power and video) and configuration of certain items in Windows 7 may be different from Windows Vista. Consult your Windows 7 documentation, or item specific help for further information.

  • Page 198: Windows 7 Start Menu & Control Panel

    Windows 7 Information Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 199: Video Features

    Windows 7 Information Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see Chapter B“Intel Video Driver Controls” from page B - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.

  • Page 200: Screen Resolution

    Windows 7 Information Screen Resolution Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display as your display device. Figure D - 2 - Screen Resolution & Intel GMA Driver for Mobile Control Panel D - 4 Video Features...

  • Page 201: Attaching Other Displays

    Windows 7 Information Attaching Other Displays Configuring an External Display in Windows 7 Attach your external monitor to the external monitor port, and turn it on. Go to the Screen resolution control panel. Click the Detect button. The computer will then detect any attached displays. Video Options Note that card types, specifications and drivers are subject to continual...
  • Page 202 Windows 7 Information You can configure the displays from the Multiple Displays menu. Figure D - 4 - Screen Resolution - Multiple Display Options • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...

  • Page 203: Windows 7 Driver Installation

    Windows 7 Information Windows 7 Driver Installation Check the driver installation order from Table D - 1, on page D - 8 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc into an attached CD/DVD drive and click Install Drivers Installer menu below.

  • Page 204: Windows 7 Driver Installation

    Windows 7 Information Driver - Windows 7 Page # Video Page D - 10 Audio Page D - 10 Modem Page D - 10 Page D - 10 TouchPad Page D - 11 CardReader Page D - 11 Hot Key Page D - 11 Wireless LAN Module Page D - 13...

  • Page 205: Updating/Reinstalling Individual Drivers

    Windows 7 Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do this go Driver Installation General Guidelines to the Control Panel in the Windows OS and double- click the Programs and Features item (Programs > The driver installation procedure outlined in this Uninstall a program).

  • Page 206: Driver Installation Procedure

    Windows 7 Information Driver Installation Procedure Modem Insert the Device Drivers & Utilities + User’s Manual 1. Click 3.Install Modem Driver > Yes. disc and click Install Drivers (button). 2. Click OK. 3. The modem is ready for dial-up configuration. Video 1.

  • Page 207: Touchpad

    Windows 7 Information TouchPad Optional Drivers 1. Click 5.Install Touchpad Driver > Yes. The following pages provide driver installation proce- dures for any modules included in your purchase op- 2. Click Next. tion. Refer to Chapter 7 as indicated for further 3.

  • Page 208: Wireless Lan Module

    Windows 7 Information Wireless LAN Module If you have included an Intel® Wi-Fi Link 1000 Series (802.11 b/g/n) or 3rd Party 802.11b/g/n WLAN mod- ule in your purchase option, make sure that the Wireless LAN module is on before installing the driver. Use the Fn + F11 key combination (see “Function/Hot Key Indicators”...

  • Page 209: Intel® Wi-Fi Link Series Driver Installation

    Windows 7 Information Intel® Wi-Fi Link Series Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive.

  • Page 210: Pc Camera Module

    Windows 7 Information PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is on. Use the Fn + F10 key combination (see Table 1 - 4, on page 1 - 13) to toggle power to the PC Camera module. Make sure you in- stall the drivers in the order indicated in Table D - 1, on page D - There are a number of different camera modules available with this computer model series.

  • Page 211: Pc Camera Driver Installation

    Windows 7 Information PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 2.Install WebCam Driver > Yes. 4. Choose the language you prefer and click Next > Next. 5.

  • Page 212: 3.75G/Hspa Module

    Windows 7 Information 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module (see “Communication” on page C - 3 for specification details) in your purchase op- 3.75G/HSPA Module tion, you will have the appropriate software provided for your module. Follow the Options instructions Page 7 - 17...
  • Page 213 Windows 7 Information Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 4, on 3.75G/HSPA page 1 -...

  • Page 214: Hspa Modem Interface Installation

    Windows 7 Information HSPA Modem Interface Installation 1. Enable power to the module by pressing the Fn + key combination (give the module about 10 sec- onds to power on - the on-screen icon will indicate the module’s power status). 2.

  • Page 215: Mobile Partner Application Installation

    Windows 7 Information Mobile Partner Application Installation 1. Enable power to the module by pressing the Fn + key combination (give the module about 10 sec- onds to power on - the on-screen icon will indicate the module’s power status). 2.

  • Page 216: D - 20 Other Notes

    Windows 7 Information Other Notes: Bluetooth Module Note: The operating system is the default setting for Bluetooth control in Windows 7, and does not require a driver. See your Windows 7 documentation for specific information. D - 20 Other Notes:...

This manual is also suitable for:

Style-note 874xtg

Table of Contents
