cetis EXA100 User Manual

Wireless ap router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EXA100
Wireless AP Router
User Manual
Version A1.0, November 29, 2012

Advertisement

Table of Contents
loading

Summary of Contents for cetis EXA100

  • Page 1 EXA100 Wireless AP Router User Manual Version A1.0, November 29, 2012...

  • Page 2: Important Safety Instructions

    Preface This manual provides information related to the installation and operation of this device. The individual reading this manual is presumed to have a basic understanding of telecommunications terminology and concepts. Important Safety Instructions With reference to unpacking, installation, use, and maintenance of your electronic device, the following basic guidelines are recommended: Do not use or install this product near water, to avoid fire or shock hazard.
  • Page 3 Copyright Copyright© 2012 Cetis Corporation. All rights reserved. The information contained herein is proprietary to Cetis Corporation. No part of this document may be translated, transcribed, reproduced, in any form, or by any means without the prior written consent of Cetis Corporation.

  • Page 4: Table Of Contents

    Table of Contents   Chapter 1 Introduction ....................5   1.1 Features ......................... 5   1.2 Application......................6   Chapter 2 Installation ...................... 7   Chapter 3 Web User Interface..................9   3.1 Default Settings ..................... 9   3.2 IP Configuration..................... 9   3.3 Login Procedure....................11   Chapter 4 Device Information ..................14   4.1 Statistics....................... 15   Chapter 5  Wireless Setting ................... 16  ...
  • Page 5   6.6 Reboot ......................... 37   6.7 Configuration....................... 38     6.7.1  Backup Settings..................38     6.7.2  Update Settings..................38     6.7.3  Restore Default ..................39   Appendix A ‐ Pin Assignments ..................40   Appendix B – Specifications................... 41   Appendix C –Parameter Rules ..................43 4   ...

  • Page 6: Chapter 1 Introduction

    Chapter 1 Introduction The EXA100 is a Wi-Fi AP module which can be inserted into wall-mounted customized housing. The EXA100 is an 802.11n (300Mbps) Wireless AP and is backward compatible with existing 802.11b (11Mbps) and 11g (54Mbps) equipment. The EXA100 is customized for Hotel environment applications. It...

  • Page 7: Application

    1.2 Application The following diagrams depict typical applications of the EXA100.               6   ...

  • Page 8: Chapter 2 Installation

    Chapter 2 Installation FRONT PANEL     The figure below shows the front panel of the device. LED Status Status Descriptions System is power off or system status Solid OFF is abnormal or disabling ‘LED ON’ in Power web UI. Solid ON System is operational Wi-Fi is disabled or disabling ‘LED ON’...
  • Page 9 REAR PANEL The figure below shows the rear panel of the device. Caution 1: If the device fails to power up, or it malfunctions, first verify that the power cords are connected securely and then power it on again. If the problem persists, contact technical support. Caution 2: Before servicing or disassembling this equipment, disconnect all power cords and telephone lines from their outlets.

  • Page 10: Chapter 3 Web User Interface

    Chapter 3 Web User Interface This section describes how to access the device via the web user interface (WUI) using an Internet browser such as Internet Explorer (version 5.0 and later). 3.1 Default Settings The factory default settings of this device are summarized below. 　...
  • Page 11 STEP 1: From the Network Connections window, open Local Area Connection (You may also access this screen by double-clicking the Local Area Connection icon on your taskbar). Click the Properties button. STEP 2: Select Internet Protocol (TCP/IP) and click the Properties button. STEP 3: Change the IP address to the 192.168.1.x (1<x<255) subnet with subnet mask of 255.255.255.0.

  • Page 12: Login Procedure

    3.3 Login Procedure Perform the following steps to login to the web user interface. NOTE: The default settings can be found in 3.1 Default Settings. STEP 1: Start the Internet browser and enter the default IP address for the device in the Web address field. For example, if the default IP address is 192.168.1.254, type http://192.168.1.254.
  • Page 13 Chapter 4 Device Information screen and login with remote username and password. STEP 2: A dialog box will appear, such as the one below. Enter the default username and password, as defined in section 3.1 Default Settings. Click OK to continue. NOTE: The login password can be changed later (see 8.6.1...
  • Page 14 STEP 3: After successfully logging in for the first time, you will reach this screen. 13   ...

  • Page 15: Chapter 4 Device Information

    Chapter 4 Device Information The web user interface window is divided into two frames, the main menu (at left) and the display screen (on the right). The main menu has several options and selecting each of these options opens a submenu with more selections.

  • Page 16: Statistics

    4.1 Statistics Select Interface Statistics from the Device Info submenu to display the following. 15   ...

  • Page 17: Chapter 5 Wireless Setting

    Chapter 5 Wireless Setting 5.1 Basic You can configure the minimum number of wireless settings for communication, such as network name (SSID) and channel. Wireless Network Field Description Driver Version Displays the version of the driver. Radio On/Off: Enable or disable the wireless LAN. Network Mode: There are 5 modes: 11b only, 11g only,11n only,11b/g mixed mode, and 11b/g/n mixed...
  • Page 18 Multiple SSID 1/2/3/4: This router supports multiple SSIDs called Guest SSIDs or Virtual Access Points. Broadcast Network Name Select Enable to allow the SSID broadcast (SSID): on the network, so that the STA can find it. Otherwise, the STA cannot find it. AP Isolation: Enable or disable AP Isolation.
  • Page 19 Field Description Operating Mode Two modes: Mixed Mode and Green Field Default is Mixed Mode. Channel BandWidth Set the channel bandwidth of wireless radio 20MHz and 20/40 MHz Default is 20/40 MHz Guard Interval Guard Interval is used to avoid that distinct transmissions do not affect with one another.

  • Page 20: Advanced

    5.2 Advanced Use this page to make detailed settings for the AP. Advanced Wireless Settings page includes items that are not available in the Basic Wireless Settings page, such as basic data rates, beacon interval, and data beacon rate. Advanced Wireless Field Description BG Protection Mode:...
  • Page 21 RTS Threshold: Request to send (RTS) is designed to prevent collisions due to hidden nodes. An RTS defines the biggest size data frame you can send before an RTS handshake is invoked. The RTS threshold value is between 1 and 2347. The default value is 2347.

  • Page 22: Security

    5.3 Security Choose Wireless Settings>Security and the following page will be displayed. It allows you to modify the settings to prevent unauthorized accesses. Select SSID SSID choice: Select SSID from the drop-down list. “default” Security Mode: There are 11 options, including Disable, OPEN, SHARED, WEPAUTO, WPA, WPA-PSK, WPA2, WPA2-PSK, WPAPSKWPA2PSK, WPA1WPA2, and 802.1X.

  • Page 23: Access Policy

    Cetis AP Security Mode: There are 11 options, including Disable, OPEN, SHARED, WEPAUTO, WPA, WPA-PSK, WPA2, WPA2-PSK, WPAPSKWPA2PSK, WPA1WPA2, and 802.1X. Wire Equivalence Protection (WEP) WEP Key (1-4): Input the key to encrypt wireless data. To allow encrypted data transmission, the WEP Encryption Key values on all wireless stations must be the same as the router.

  • Page 24: Wds

    5.4 WDS Wireless Distribution System (WDS) WDS Mode: There are four options, including Disable, Lazy Mode, Bridge Mode, and Repeater Mode. • Disable Select Disable to disable the WDS mode. • Lazy Mode Field Description WDS Mode: Select Lazy Mode. The EXA100WDS Lazy mode allows the other WDS bridge / repeater mode to link automatically.
  • Page 25 • Bridge Mode/ Repeater Mode Field Description WDS Mode: Select Bridge Mode or Repeater Mode. Phy Mode: It provides 4 options, including CCK, OFDM, HTMIX, and GREENFIELD. Encryp Type: It provides 4 options, including None, WEP, TKIP, and AES. AP MAC Address: It provides 4 AP MAC Addresses.
  • Page 26 Dynamically assigned and rotated encryption key are not supported in a WDS connection. This means that WPA and other dynamic key assignment technologies may not be used. Only Static WEP keys may be used in a WDS connection, including any STAs that are associated with a WDS repeating AP.

  • Page 27: Wps

    5.5 WPS You can enable or disable the WPS function on this page. Select Enable from the WPS drop-down list. Click Apply and the following page will be displayed. 26   ...
  • Page 28 27   ...

  • Page 29: Station List

    WPS Summary It displays the WPS information, such as WPS Current Status, WPS Configured, and WPS SSID. Reset OOB: Reset to out of box (OoB) configuration. WPS Progress WPS mode: There are two ways for you to enable the WPS function: PIN, PBC.

  • Page 30: Ap Wireless Statistics

    AP Wireless Statistics This page shows the Wireless Statistics of EXA100. 29   ...

  • Page 31: Chapter 6 Management - Configuration Backup

    6.1 Management IP IP Address: Web LAN IP address for management. Config Version: Shows the current configuration version. The EXA100 can update the configuration automatically via TFTP server. Gateway IP for remote management: Disable Local management: When disable the local management (ticking the checkbox .), user can not...

  • Page 32: Led Control

    6.2 LED Control Select Disable or Enable from the drop‐down menu and click the Apply button. 31   ...

  • Page 33: Snmp Agent

      6.3 SNMP Agent Simple Network Management Protocol (SNMP) allows a management application to retrieve statistics and status from the SNMP agent in this device. Select Enable from the drop-down menu, configure options, and click Apply to activate SNMP. 32   ...

  • Page 34: Tr-069 Client

    6.4 TR-069 Client WAN Management Protocol (TR-069) allows an Auto-Configuration Server (ACS) to perform auto-configuration, provision, collection, and diagnostics to this device. Select desired values and click Apply/Save to configure TR- 069 client options. The table below is provided for ease of reference. Field Description TR-069 Settings...
  • Page 35 Field Description ACS Password Password used to authenticate the WIFI AP when making a connection to the ACS using the WIFI AP WAN Management Protocol. This password is used only for HTTP-based authentication of the WIFI AP. Inform Interval The duration in seconds of the interval for which the WIFI AP MUST attempt to connect with the ACS and call the Inform method.

  • Page 36: Update Software

    6.5 Update Software This option allows for firmware upgrades from a locally stored file. Update Firmware STEP 1: Obtain an updated software image file from your ISP. STEP 2: Enter the path and filename of the firmware image file in the Software File Name field or click the Browse button to locate the image file.
  • Page 37 Chapter 4 Device Information screen with the firmware version installed, to confirm the installation was successful. 36   ...

  • Page 38: Reboot

    6.6 Reboot To save the current configuration and reboot the router, click Save/Reboot. NOTE: You may need to close the browser window and wait for 2 minutes before reopening it. It may also be necessary, to reset your PC IP configuration.

  • Page 39: Configuration

    6.7 Configuration 6.7.1 Backup Settings To save the current configuration to a file on your PC, click Backup Settings. You will be prompted for backup file location. This file can later be used to recover settings on the Update Settings screen, as described below.

  • Page 40: Restore Default

    PC IP configuration to match any new settings. NOTE: This entry has the same effect as the Reset button. The EXA100 board hardware and the boot loader support the reset to default. If the Reset button is continuously pressed for more than 5 seconds, the boot loader will erase the configuration data saved in flash memory.

  • Page 41: Appendix A - Pin Assignments

    Appendix A - Pin Assignments ETHERNET Ports (RJ45) ETHERNET LAN Ports (10/100Base-T) Connection # PIN # Descriptions +12Vdc Input +12Vdc Input Ethernet TX (+)/LAN1 Ethernet TX (-)/LAN1 Ethernet RX (+)/LAN1 Ethernet RX (-)/LAN1 Ground Ground PoE (+) Input PoE (+) Input Ethernet TX (+)/LAN2 Ethernet TX (-)/LAN2 Ethernet RX (+)/LAN2...

  • Page 42: Appendix B - Specifications

    Appendix B – Specifications Hardware Interface Power Jack X 1, Two Punch IDC connectors Reset button X 1, Active LED X 2, Antenna internal LAN Interface IEEE 802.3, IEEE 802.3u ADSL ADSL standard ITU-T G.992.5, ITU-T G.992.3, ITU-T G.992.1, ANSI T1.413 Issue 2, G.992.5 (ADSL2+): G.992.3 (ADSL2):...
  • Page 43 Management SNMP, Telnet, Web-based management, Configuration backup and restoration RFC1213 Management information base for Network management of TCP/IP-based internets : MIB-II Software upgrade via HTTP Power Supply Input: 100 - 240 Vac Vac/ 50-60Hz Output: 12 Vdc / 1 A Certifications EN 55022 + EN55024 EN 300328...

  • Page 44: Appendix C -Parameter Rules

    Appendix C –Parameter Rules Setting Settings parameters parameters in value default in Web GUI Config file Basic 0: disable Wireless Radio On/Off RadioOff=0 1: enable Setting Network SSID1=wireless wireless Name(SSID) Multiple SSID2= blank SSID1 Multiple SSID3= blank SSID2 Multiple SSID4= blank SSID3 Multiple...
  • Page 45 Network Mode-11n WirelessMode=6 only(2.4G) Operating 0: Mixed Mode HT_OpMode=0 Mode 1: Green Field Channel 0: 20 HT_BW=1 BandWidth 1: 20/40 Guard 0: long HT_GI=1 Interval 1: Auto (SSID1;SSID2;SSID3;SSID4;SSID5) HT_MCS=33 from: 1-15 and 32 33: Auto Reverse Direction HT_RDG=1 Grant(RDG) STBC HT_STBC=1 Aggregation MSDU(A-...
  • Page 46 CountryRegion=0 CountryRegionABand=7 CountryCode=US CountryRegion=5 CountryRegionABand=6 CountryCode=JP CountryRegion=1 CountryRegionABand=2 CountryCode=FR CountryRegion=0 Country CountryRegionABand CountryRegion=0 Code CountryRegionABand=8 CountryCode=US CountryCode=TW CountryRegion=1 CountryRegionABand=1 CountryCode=IE CountryRegion=1 CountryRegionABand=0 CountryCode=HK NONE: CountryRegion=5 CountryRegionABand=7 CountryCode= WmmCapable=1 Capable APSD Capable APSDCapable=0 0: disable 1: enable DLS Capable DLSCapable=0 Multicast-to- M2UEnabled=0 Unicast Security...
  • Page 47 0: Hex KeyType=0 Key2Str1= WEP Key 2 1: ASCII Key2Type=0 Key3Str1= WEP Key 3 Key3Type=0 Key4Str1= WEP Key 4 Key4Type=0 Security AuthMode=WEPAUTO Mode- EncrypType=WEP WEPAUTO (SSID1;SSID2;SSID3;SSID4;SSID5) Default Key DefaultKeyID=1 1,1,1,1,1 from:1-4 Key1Str1= WEP Key 1 Key1Type=0 Key2Str1= WEP Key 2 (SSID1;SSID2;SSID3;SSID4;SSID5) KeyStr1=blan Key2Type=0...
  • Page 48 PMK Cache PMKCachePeriod=10 Period Pre- PreAuth=0 Authentication IP Address RADIUS_Server= (SSID1;SSID2;SSID3;SSID4;SSID5) blank Port RADIUS_Port=1812 (SSID1;SSID2;SSID3;SSID4;SSID5) 1812 RADIUS_Key1= RADIUS_Key2= Shared Secret RADIUS_Key3= blank RADIUS_Key4= RADIUS_Key5= Session session_timeout_inter (SSID1;SSID2;SSID3;SSID4;SSID5) Timeout val=0 Security Mode-WPA2- AuthMode=WPA2PSK (SSID1;SSID2;SSID3;SSID4;SSID5) EncrypType= Algorithms TKIP or AES WPAPSK1= WPAPSK2= Pass Phrase WPAPSK3= WPAPSK4=...
  • Page 49 Security AuthMode=OPEN Mode-802.1x EncrypType=WEP 802.1x WEP IEEE8021X= blank IP Address RADIUS_Server= (SSID1;SSID2;SSID3;SSID4;SSID5) blank Port RADIUS_Port=1812 (SSID1;SSID2;SSID3;SSID4;SSID5) 1812 RADIUS_Key1= RADIUS_Key2= Shared Secret RADIUS_Key3= blank RADIUS_Key4= RADIUS_Key5= Session session_timeout_inter (SSID1;SSID2;SSID3;SSID4;SSID5) Timeout val=0 0: Disable Policy AccessPolicy0=0 1: Allow 2: Reject Add a station AccessControlList0= blank Wireless...
  • Page 50 (SSID1;SSID2;SSID3;SSID4;SSID5) EncrypType WdsEncrypType= NONE NONE，WEP，TKIP，AES Wds0Key= Wds1Key= Encryp Key blank Wds2Key= Wds3Key= AP MAC WdsList= blank Address Wi-Fi default is 7 Protecte WscModeOption=7 7=enable d Setup 0=disable Setting parameters Web GUI Config file value default IP Address lan_ipaddr=192.168.1.254 192.168.1.254 Gateway IP for Remote lan_gateway=0.0.0.0 0.0.0.0 Management...
