LG-Ericsson PCI-1020 User Manual

Hide thumbs Also See for PCI-1020:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI-1020 and is the answer not in the manual?

Questions and answers

Related Manuals for LG-Ericsson PCI-1020

Summary of Contents for LG-Ericsson PCI-1020

  • Page 2: Table Of Contents

    Introduction .............. 1 The LG-Ericsson Interface - Wi-Fi Protected Setup Tab ................ 25 Product Overview ............2 The LG-Ericsson Interface - About Tab ....26 Package Contents ........... 2 Connecting to a Wireless Router Manually ... 27 System Requirements ..........2 Connect to an Access Point ........
  • Page 3 Table of Contents Using WPS in Windows XP ........69 LG-Ericsson PCI-1020 Shortcuts ......70 Uninstalling the LG Ericsson PCI-1020 Utility ..71 Glossary ..............74 Warranty and Technical Support ......75 LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 4: Introduction

    Introduction The LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter is the ideal solution for connecting your desktop to a high speed Wireless-N network. With wireless transfer speed at up to 150Mbps, the PCI-1020 significantly improves your wireless connectivity and signal while staying backwards compatible with your 802.11g network. In addition to providing basic connectivity, the LG-Ericsson PCI-1020 provides Wireless-N speed for simultaneous downloads, music and video streaming, and online gaming.

  • Page 5: Product Overview

    System Requirements For best results, the following minimum requirements are recommended on any system used to configure and use the LG-Ericsson PCI-1020 Desktop Adapter: „ Computer with: 1Ghz processor / 512 MB RAM / 200 MB available space / CD-ROM drive „...

  • Page 6: Features

    Features The LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter is designed for easy installation and allows remote access to important data via LAN or WAN. The LG-Ericsson PCI-1020 offers seamless roaming and is fully interoperable with different networks : „ Fully compatible with IEEE 802.11n draft standard to...

  • Page 7: Hardware Overview

    While a steady light indicates a connection to a wireless network. COMPONENT DESCRIPTION PCI Connectors The PCI connectors fit into the PCI slot on your computer One antenna for stable frequency Antenna LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 8: Installation

    This section will walk you through the installation process. If you have another built-in wireless adapter in your PC, disable it in Device Manager before installing the LG-Ericsson PCI-1020 Desktop Adapter. Also, if you have previously installed another wireless adapter, make sure the software is uninstalled.

  • Page 9: Disabling Old Wireless Adapters

    Right-click the adapter you would like to disable and select disable. Step 4: Click Yes to disable the adapter. The adapter is disabled when a red X covers the icon. Disabling the adapter will not remove the drivers LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 10: Wireless Considerations

    Ericsson The LG- PCI-1020 Wireless 802.11n PCI Adapter allows you to access your wireless network within the operating range of your wireless router or access point. Consider the following when installing wireless devices: the number, thickness and location of walls; ceilings; and other object that may limit the range the wireless signal must pass through. Wireless ranges vary depending on the types of material and background radio frequency noise.

  • Page 11: Hardware Installation

    Hardware Installation Step 1: Open the side panel of your computer Step 2: Remove the metal cover bracket LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 12: Hardware Installation

    Hardware Installation Step 3: Insert the LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter firmly into the PCI slot and screw it in place LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 13: Getting Started

    Before inserting the wireless adapter, please note that you have to install the software. Step 1: Turn on your computer and insert the LG-ERICSSON CD (included in the package contents of this product) into the drive. Installed on the CD is an auto-run application that allows you to quickly access the contents of of the CD easily The introduction screen appears.
  • Page 14 Step 2: The LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter welcome screen will appear. Click Next to continue. Step 3: Choose a Destination Location and click Next. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 15 Step 4: Select the Program Folder where you want the program to be installed. Click Next when complete. Step 5: The installation process begins LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 16 Windows 7 security feature will prompt you about the validity of the software. Click “Install this driver software anyway”. Step 7: The LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter software installation process is complete. Click Finish. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 17: Configuring The Lg-Ericsson Pci-1020 In Windows 7

    Configuring the LG-Ericsson PCI-1020 in Windows ® This section shows you how to configure the LG-Ericsson PCI-1020 Adapter using the LG-Ericsson Wireless Utility. Step 1: In Windows® 7, click the Start button, All Programs, LG-Ericsson Wireless Utility, LG- Ericsson Wireless 802.11n PCI Adapter.
  • Page 18 Step 2: The program interface lists “Available Networks”. There is a report on Network Names, MAC addresses, range percentages, security, and Channels. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 19 Step 3: Select the SSID or wireless router you wish to connect to and click Connect. Connect Button Wireless Access Point LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 20 If you are trying to connect to an unsecured wireless network, Windows prompts you to acknowledge that you are entering an unsecured network. It is strongly recommended that you set up wireless security for your network. Step 5: Click OK to continue LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 21 Step 6: The LG-Ericsson PCI-1020 adapter attempts to connect to the wireless router and prompts you to enter a network key. This only occurs if the router has security enabled. Step 7: Enter the network key your network administrator has provided to you amd click Connect.
  • Page 22 Step 8: Windows verifies that you are connected to a wireless network and asks you to confirm the network location. Step 9: Click Close. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 23 Step 10: Under Control Panel, Network and Sharing Center, the wireless router appears that you are connected to. The Wireless Network LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 24: Understanding The Interface

    Understanding the Interface The LG-Ericsson Wireless Utility has a detailed user interface. Let’s take a look at the different parts of the interface. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 25: The Lg-Ericsson Interface - Available Networks

    The LG-Ericsson Interface - Available Networks Available Network Tab SSID Name Channel ID IP Address Encryption Type Close Button LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 26: The Lg-Ericsson Interface - Available Network Tab

    The LG-Ericsson Interface - Available Network Tab Refresh Button N e t w o r k N a m e o r SSID Connect Button Signal Strength in % Wireless Channel Security Method Disabled Security MAC Address Signal Strength LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 27: The Lg-Ericsson Interface - Profile Management Tab

    The LG-Ericsson Interface - Profile Management Tab Profile Management Tab Profile Name Profile Name SSID Network Type Authentication Type Encryption Type Channel Number Encryption Type IP Address LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 28: The Lg-Ericsson Interface - Wi-Fi Protected Setup Tab

    The LG-Ericsson Interface - Wi-Fi Protected Setup Tab WPS Tab PIN Code SSID Channel Encryption Type LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 29: The Lg-Ericsson Interface - About Tab

    The LG-Ericsson Interface - About Tab About Tab MAC Address Utility Version Driver Version LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 30: Connecting To A Wireless Router Manually

    Connecting to a Wireless Router Manually In Windows® 7, click the Start button, All Step 1: Programs, LG-Ericsson Wireless Utility, LG- Ericsson Wireless 802.11n PCI Adapter. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 31 Step 2: The program interface lists “Available Networks”. There is a report on Network Names, MAC addresses, range percentages, security, and Channels. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 32: Connect To An Access Point

    Connect to an Access Point Step 3: There are two options available here: Unencrypted, encrypted. 1. Locate the SSID/network you wish to connect to. 2. Click the designated SSID/network. Step 4: Click Connect. Once connected click Properties. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 33: Selecting Your Network

    Ad-hoc mode is also referred to as peer-to-peer mode and is useful at a departmental scale or SOHO operation. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 34 WPA2-PSK \ AES - Good Select your security preference. Step 8: If you have selected a security method, enter the Network Key and click Connect. Check the Display Key if you wish to see the Network Key digits. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 35 Step 9: The LG Ericsson PCI-1020 will now connect to the wireless router. Windows® 7/Vista will prompt you to select a network type. Choose your location and click LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 36 Step 10: Windows® also creates a Quick bar which indicates your connection to the wireless network. The LG-Ericsson software also installs a quick detection icon in the taskbar Quick Selection Tool LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 37: Connecting In Infrastructure Mode

    Connecting in Infrastructure Mode Step 1: Click LG-Ericsson Wireless 802.11n PCI Adapter Step 2: Select a wireless hotspot or access point from the list provided. Click Connect. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 38: Connecting In Infrastructure Mode

    Connecting in Infrastructure Mode Step 3: Under the Settings File tab, the Profile Name is automatically selected. Enter a Network Name (SSID). Under Network Type, select Infrastructure mode. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 39: Connecting In Infrastructure Mode

    Advanced security features. (At the beginning, we connected via Basic Security) Select Advanced Security. Under Advanced Security, the Authentication Type and Encryption Type changes accordingly. Default Advanced Security settings leaves authentication open and encryption disabled. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 40: Security Settings

    NB: The recommeded security for the wireless network is WPA2-PSK with AES if you wish to use an encryption type. Select Open if the network you are trying to connect to Step 2: does not have security enabled. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 41: Security Settings - Shared/Wep

    Step 4: Enter a Network key password. This can be obtained from your network administrator or if you have access to your Access Point. Click OK when done. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 42: Security Settings - Wpa-Eap (Enterprise)

    Selecting EAP_TLS mode, enter a User Certificate Type in a User Name, Password and Domain Name to authenticate your wireless device. Click Server Settings to configure your server for your device. Check the Appendix for a list of definitions. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 43 IP address and click OK. If you do not have the specific details please consult with your network administrator. Step 3: Once you have filled in all the details click OK to continue. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 44: Security Settings - Wpa-Psk (Personal)

    Step 1: Under WPA-PSK (Personal), there are two options for the Encryption type. TKIP or AES. Select TKIP or AES, enter the network Key and click Step 2: Enter the Network Key and click OK. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 45: Security Settings - Wpa2-Eap (Enterprise)

    Selecting EAP_TLS mode, enter a User Certificate Type in a User Name, Password and Domain Name to authenticate your wireless device. Click Server Settings to configure your server for your device. Check the Appendix for a list of definitions. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 46 IP address and click OK. If you do not have the specific details please consult with your network administrator. Step 3: Once you have filled in all the details click OK to continue. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 47: Security Settings - Wpa2-Psk (Personal)

    Select TKIP/AES, enter the network Key and click OK. Step 2: Enter a Network Key and click OK. Please Note: The recommended security settings is WPA2-PSK (Personal) with AES. However, please check with your network administrator to confirm the router settings. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 48: Connect To The Wireless Network Using Wps

    Connect to the Wireless Network using WPS This section guides you through the process of connecting the LG-Ericsson PCI-1020 Desktop Adapter to your wireless network. Step 1: Click Start, All Programs, LG-Ericsson Wireless 802.11n PCI Adapter. Step 2: Click the WPS Tab...
  • Page 49 WPS button on your router. This function will remain active for 2 minutes (depending on manufacturer). Click the “Connect Now” button on the router. Step 4: Click PBC on the WPS tab and click Next. Next LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 50 Step 5: The software gvies an illustration of the connecting devices. Click Start to sync the devices. Next NB: Make sure you have pressed the WPS button on the router to activate WPS. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 51 Step 6: On your router, locate the WPS settings. Click the Add A Wireless Device with WPS button Step 7: Click the PBC radio button and click Connect LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 52 The LG-Ericsson PCI-1020 Adapter will now search for a WPS Access Point. Step 9: Once the LG-Ericsson PCI-1020 has found a WPS device, it will register it and confirm the connection to the router by sending a network key to the access point.
  • Page 53 Step 10: Windows automatically recognizes the new wireless location and prompts you to select a location. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 54 Step 11: Windows registers the new wireless location LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 55: Connect To The Wireless Network Using A Pin Code

    Connect to the Wireless Network using a PIN code Step 1: Click Start, All Programs, LG-Ericsson Wireless 802.11n PCI Adapter. Step 2: Check the PIN Code box under the WPS Tab. Click Next. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 56 PIN code and provides a PIN code. Use this PIN code to authenticate with your router. Step 4: On your router, locate the WPS settings. Click the Add A Wireless Device with WPS button. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 57 Step 5: Enter the PIN code on your LG-Ericsson PCI-1020 device and click Connect. The wireless adapter syncs with the router. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 58 Step 6: The LG-Ericsson PCI-1020 adapter establishes a relationship with the Network key Once the connection is established the PIN Code activation is set. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 59: Lg-Ericsson Pci-1020 - About

    Click the About Tab to see details about the MAC Address, Utility Version, and driver Version. Here it also shows the SSID, Channel and Encryption Type of the Access Point you are connected to. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 60: Installing The Lg-Ericsson Pci-1020 In Windows Xp

    Installing the LG-Ericsson PCI-1020 in Windows XP This section shows you how to install the LG-Ericsson PCI-1020 using Windows XP Step 1: Install the LG-Ericsson PCI-1020 into a PCI slot on your Windows XP machine. Make sure the device is secured in the PCI slot by screwing it in place.
  • Page 61 Step 2: Once you turn on your PC, Windows XP automatically recognizes the new hardware and provides a Found New Hardware Wizard. Step 3: In the Wizard, select Cancel. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 62 Step 4: Put the LG-Ericsson PCI-1020 PCI Adapter CD in your CD-ROM. The CD will autorun. Step 5: The PCI-1020 InstallShield Wizard appears. Click Next. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 63 Step 6: Select the Destination Folder where you want the software to reside. Otherwise leave the default settings and click Next Step 7: Select the Program Folder and click Next. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 64 Step 8: The program installs on your drive. Step 9: Windows prompts you to verify the software. Click Continue Anyway. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 65 Click Finish when the software is complete. Step 11: Windows detects a new wireless network and prompts you to view a list of Access Points. Step 12: The LG-Ericsson utility also appears in the toolbar. LG-Ericsson Utility LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 66: Setting Up The Lg-Ericsson Pci-1020 In Windows Xp

    Setting up the LG-Ericsson PCI-1020 in Windows XP This section shows you how to configure the LG-Ericsson PCI-1020 using Windows XP Step 1: Click Start, All Programs, LG-Ericsson Wireless Utility. LG-Ericsson Wireless 802.11n PCI Adapter. Step 2: The Program starts with four main tabs.

  • Page 67: Understanding The Interface

    Understanding the Interface Available Network Tab Profile Management Tab WPS Tab About Tab Refresh Button Connect Button Network Name Channel Number MAC Address Security SSID Channel Close Button Encryption Type Signal Strength Signal Strength Bar LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 68: Connecting To An Access Point

    Step 3: Click the Refresh button to get the latest view of Access Points available. Refresh Button Step 4: Select the Access Point you wish to connect to and click the Connect button. Connect Button LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 69 Once connected, the LG-Ericsson PCI-1020 software will show the SSID, Channel number, Encryption Type, MAC Address, Signal Strength, and IP Address. The LG-Ericsson PCI-1020 Taskbar icon will turn green to indicate it’s connected to the Access Point. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 70: Connecting To A Secured Access Point

    Connect to a secured wired network Step 2: Follow all the instructions as above. When prompted to enter a Network Key, enter the details or ask your network administrator for assistance. Click Connect when complete. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 71 Step 3: The LG-Ericsson Wireless Utility will show all connection details. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 72: Using Wps In Windows Xp

    Using WPS in Windows XP The WPS setup under Windows® XP is the same as Windows® 7. Please refer to the configuration method for WPS under the Windows 7 section above. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 73: Lg-Ericsson Pci-1020 Shortcuts

    LG-Ericsson PCI-1020 Shortcuts This section shows you how to access the LG-Ericsson PCI-1020 using shortcuts. Step 1: Right-click the LG-Ericsson PCI-1020 icon in the Taskbar. LG-Ericsson Utility Step 2: A box appears with a few shortcut connections. Preferred WLANS - Are networks you have already connected to and it’s on your shortlist.

  • Page 74: Uninstalling The Lg Ericsson Pci-1020 Utility

    Uninstalling the LG Ericsson PCI-1020 Utility This section shows you how to uninstall the LG-Ericsson PCI-1020 Utility. Step 1: Click Start, All Programs, LG-Ericsson Wireless Utility, Uninstall. Uninstall Step 2: Click Start, All Programs, LG-Ericsson Wireless Utility, Uninstall. Click OK to confirm.
  • Page 75 Step 3: Click OK to confirm the uninstall. Step 4: The wizard continues deleting the program. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 76 Step 5: The wizard prompts you to restart the PC for the changes to take effect. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 77: Glossary

    802.11n - The additional transmitter and receiver antennas allow for increased data throughput through spatial multiplexing and increased range by exploiting the spatial diversity. The speed is 100 Mbit/s, and so up to 4-5 times faster than 802.11g. 802.11n also offers a better operating distance than current networks. LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...

  • Page 78: Warranty And Technical Support

    Information furnished by LG-Ericsson USA, Inc. (LG-Ericsson USA) is believed to be accurate and reliable. However, no responsibility is assumed by LG-Ericsson USA for its use, nor for any infringements of patents or other rights of third parties, which may result from its use.
  • Page 79 LG-Ericsson PCI-1020 Wireless 802.11n PCI Adapter...
  • Page 80 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
