FlyTech P234 User Manual

Hardware system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Revision v1.0
July 2009
P234
Hardware
System
Flytech Technology co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P234 and is the answer not in the manual?

Questions and answers

Summary of Contents for FlyTech P234

  • Page 1 User Manual Revision v1.0 July 2009 P234 Hardware System Flytech Technology co., Ltd.
  • Page 2 Copyright Copyright 2009 July All Rights Reserved Manual Version 1.0 P/N: The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Revision History

    Revision History Changes to the original user manual are listed below: Version Date Description 2009/07 Initial release...
  • Page 4 Safety Regulatory Information: Caution: Only use approved and UL Listed accessories, battery packs and battery chargers. Do NOT attempt to charge damp/wet mobile computers or batteries. All components must be dry before connecting to an external power source. Power Supply Use only the approved power supply 50-14000-148 output rated 5 Vdc and minimum 2 A.
  • Page 5 Persons with Pacemakers: Persons with Pacemakers should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker when turned ON and hence they should not carry the device in a breast pocket . Should use the ear furthest from the pacemaker to minimize the potential for interference.
  • Page 6 belt-clips, holsters, and similar accessories may not comply with FCC RF exposure compliance requirements, and should be avoided. To comply with FCC RF exposure requirements, this device must be operated in the hand with a minimum separation distance of 2.5 cm or more from a person's body. Other operating configurations should be avoided.

  • Page 7: Battery Caution

    Battery Information Our rechargeable battery packs are designed and constructed to the highest standards within the industry. However, there are limitations to how long a battery can operate or be stored before needing replacement. Many factors affect the actual life cycle of a battery pack, such as heat, cold, harsh environmental conditions and severe drops.

  • Page 8: Notational Conventions

    Notational Conventions The following conventions are used in this document: Italics are used to highlight specific items in the general text, and to identify chapters and sections in this and related documents. bullets (•) indicate: action items • lists of alternatives •...

  • Page 9: Table Of Contents

    Table of Contents Introduction ..........1 System Overview..............1 Standard Components ..............2 Optional Accessory..............3 Hardware Description ...............4 System Feature Description .............8 Getting Started ........11 Installing the Main Battery ............11 Removing the Main Battery ............12 Installing / Uninstalling SD Card ..........13 2-3-1 Installing the SD Card............
  • Page 10 Backup and Restoring the System .........38 3-3-1 4 5 B B ackup the System ............38 3-3-2 Restoring the System ............39 Switching the Admin / User mode...........40 Power Management Settings..........41 3-5-1 CPU Power Mode Settings..........41 3-5-2 System Configuring Power Mode Settings....... 42 3-5-3 Display Backlight Settings ..........

  • Page 11: Introduction

    Introduction This chapter lists the parts, accessories, hardware System Overview ③ ① ④ ④ ⑤ ⑥ ② ⑦ ⑦ ⑧ ⑦ System Overview table -1 Location Description LED Indicator Show the Status of Wi-Fi connection and battery. Power & 4 Programmable Keys Hold 5 seconds to power on/off the system.

  • Page 12: Standard Components

    Standard Components Items Mobile System Travel Charger (Note: Only for power charge use, not for data transfer use) Main Battery Holster Power Adapter (AC-USB connector) Hand Strap Wrist Strap Neck Strap...

  • Page 13: Optional Accessory

    Optional Accessory Items Standard Battery Charger Power Brick of Standard Battery Charger Power Cord of Standard Battery Charger Note: Power cord are various according to the shipping country. MSR Module 2-in-1 MSR & Scanner Module USB Cable for synchronization & programming...

  • Page 14: Hardware Description

    Hardware Description Item Features Descriptions Main Processor Marvell PXA270 416MHz (Xscale Core) System Memory 128Mbytes SDRAM Around 115MB use for system operation, otherwise for storing system loader and system data System Storage 1Gbytes Flash (ROM file system) More than 300MB for storing WindowCE image and OEM application programs Around 600MB leaved for system and user storage, emulated as folders in all system directories...
  • Page 15 Item Features Descriptions Touch Panel LCD panel with touch panel design Resistor 80% Transparency (Film to Glass type) Audio Stereo audio system with mono speaker design 05W speaker amplifier Headphone stereo output (Optional) Secure Digital SD memory card (Support up to: 2Gbytes) Socket WiFi IEEE Auto fallback mode : 6M~54M(80211g),...
  • Page 16 Buttons Keypad – 4 programmable buttons...
  • Page 17 Item Features Descriptions Power / Reset Power Button : Suspend/ Resume Device and buttons “Enter” Key Reset Button : Warm Reset Press Power and Reset buttons simultaneously: Cold Reset LED indicators Green: ON – device power on , OFF – device off / suspend Blue: Link Status of WiFi manager Red: Flash –...

  • Page 18: System Feature Description

    System Feature Description Item Features Descriptions Application File Explorer Internet Explorer 6.0 for Windows CE Windows Media Player Windows CE standard shell (Windows XP-like skin) File System ROM File system with hive registry Graphic / Display 480x272x16 (Landscape mode) as panel default mode 272x480x16 (Portrait mode) as system default mode...
  • Page 19 Item Features Descriptions Storage Removable storage : SD memory (up to 2GB) : USB storage (optional) Persistent storage: NAND flash memory (On Board) Data Support seamless roaming in Communication IEEE802.11b/g WLAN authentication WLAN infrastructure Support single SSID Support fast Wi-Fi roaming Support always on Wi-Fi WPA and 802.11i security standard (AES/CCMP and WEP with TKIP...
  • Page 20 Item Features Descriptions Network Features NDIS network driver architecture TCP/IP Windows Networking API /Redirector [SMB] WinSock Support Security Authentication Services (SSPI) Credential Manager CrytoAPI 1.0 Applications and .NET compact framework 2.0 Service Active Template Library (ATL) Development C Libraries and Runtimes COM and DCOM Microsoft Foundation Classes (MFC) Object Exahange Protocol...

  • Page 21: Getting Started

    Getting Started Installing the Main Battery Battery Battery Bay Main Door Battery Rotate the lock screw counter-clockwise with a flat-head screw driver or a coin to release the lock. Slide the battery door outwards as direction of the arrow and open the battery door.

  • Page 22: Removing The Main Battery

    Removing the Main Battery Open the battery door described in Chapter 2-1 first. Please use your finger nail to pull the fillister on the battery latch (the circle marked) toward the front as the direction of the arrow shows. Flip up and remove the battery to replace another.

  • Page 23: Installing / Uninstalling Sd Card

    Installing / Uninstalling SD Card SD Card Slot locates in the inner side of the battery bay which is a push-push type. 2-3-1 Installing the SD Card To open the battery door and remove the main battery first as described in Chapter 2-1 and 2-2. To push the SD card into the Slot until it clicks.

  • Page 24: Neck Strap Installation

    Neck Strap Installation To installing the Neck Strap, please unthread the Neck Strap first then follow the below steps. Start threading the Neck Strap through the Strap Hole as arrow direction. Thread through the plastic ring to make it secured with the Neck strap.

  • Page 25: Wrist Strap Installation

    Wrist Strap Installation Start threading the Wrist Strap through the Strap Ring. Thread through as the arrow direction point. Finished.

  • Page 26: Hand Strap Installation

    Hand Strap Installation Hand strap screw holes Start threading the Hand Strap through the strap hole at the either side of the system. Thread through as the arrows direction show. Finish the Hand Strap threading through the strap hole at the side of the system.
  • Page 27 Fasten the Hand Strap Plastic Ring with the screws (2) to the screw holes at rear side of the system. Thread the Hand Strap through the plastic ring as the direction of the arrows show. Finished.

  • Page 28: Charging The Main Battery

    Charging the Main Battery Connect the Mobile System, Travel Charger and USB-AC power Adaptor as above arrow instruction. Plug the USB-AC Adapter to the electrical outlet. The LED light turns Orange while recharging. When recharging is complete, the LED light turns Green. Note: Please make sure to align the juts (2) of the Travel Ø...

  • Page 29: Backup Battery

    Backup Battery The internal Backup Battery can last for 5 minutes. The screen will be powered on with the last status when you replaced the Main Battery within 5 minutes. When the Main Battery is out of system over 5 minutes, the boot-up screen will pop up as above figure shows after pressing the Power Button for 1 second.

  • Page 30: Power On/Off The System

    Power on/off the System Power Button Turn on the System Press and hold the Power Button (as the arrow marked) for 5 seconds to turn on the system. Turn off the System To press the Power Button for 5 seconds or press “Start Menu” > “Suspend” to turn off the system.

  • Page 31: Using The System

    Using the System Wi-Fi Connection Settings 3-1-1 Connecting to an Existing Network Enable Wireless Connection Enable the Wireless Connection by choosing as steps of “Start” > “Settings” > “Control Panel” > “Network and Dial-up Connections”. Right click on the “GPS186861” and tap the “Enable” icon in the drop down menu to access the wireless connection.
  • Page 32 Select a Network and get connection You will see the “GPSI86861” window pop up after you double click on the icon Press “Main” tab and “Configure” button. Select the network you want and put the key (password) if needed, then press “Connect” button to get connection. NOTE: You can create a new network by selecting “Add New…”...

  • Page 33: Adding A New Network

    3-1-2 Adding a New Network To add a new network connection, please enable the wireless connection first by following the steps in Chapter 3-1-1. The “Wireless Properties” dialog box pop up after pressing “Add New…”. To put a network name you want in “Network name (SSID)” text box, select “Encryption”...

  • Page 34: Enhancing The Wifi Connection

    3-1-3 Enhancing the WiFi Connection If the status of WiFi Connection stays low, please follow the below steps: Please double-click on the icon in the system tray. The “GSP186861” dialog will appear. Please select “Advance” tab and move the “Power Management” to the “Best Performance level”...

  • Page 35: Ssid Lock Function

    3-1-4 SSID Lock Function Enable Wireless Connection by following the steps in Chapter 3-1-1. After enable the Wireless Connection, the icon will appear in the system tray. Double click the icon and press “configure” button on the “GPSI86861” window. “Windows Information” window will appear. Select a network you want and click the “Lock to specific SSID”...

  • Page 36: Connecting To A Bluetooth Device

    Connecting to a Bluetooth Device 3-2-1 Turning on the Bluetooth Connection Enable the Bluetooth Connection by following the steps “Start” > “Settings” > “Control Panel” > “Bluetooth Device”. Select “Config” tab In the “Bluetooth Manager “ dialog box. Press “Turn Bluetooth ON” button to “Turn Bluetooth Off” to enable the Bluetooth connection.

  • Page 37: Scanning Bluetooth Devices

    3-2-2 Scanning Bluetooth Devices We can scan the devices in a area and active their services in a “Bluetooth Manger” dialog by selecting “Start” > “Settings” > “Control Panel” > “Bluetooth Device”. To turn on the Bluetooth Connection. (Chapter 3-2-1) Select “Scan Device”...

  • Page 38: Connecting To A Bluetooth Printer

    3-2-3 Connecting to a Bluetooth Printer Please perform the steps in the Chapter 3-2-1 to turn the Bluetooth on and the Chapter 3-2-2 to scan the surrounding Bluetooth device first. Paring a Bluetooth Printer Device In Bluetooth, you have the option to "pair" two devices. When you pair with a Bluetooth device, this device will be "remembered”...
  • Page 39 Active Printer Service Tapping on the Bluetooth Printer device you want and choose a service on the “Service” menu. The current example is selecting “Printer” service. Press “Active Service” button to active the Printer service. A “Serial Port Setting” dialog box will appear. Choose the COM port options in the drop down list you want.

  • Page 40: To Synchronize With A Pc Via Bluetooth

    3-2-4 To Synchronize with a PC via Bluetooth Before Synchronize the Mobile System with a PC, please turn on the Bluetooth connection as described in the Chapter 3-2-1 and pair the PC and the Mobile System first as detailed in the below. Pairing a Bluetooth enabled PC When you pair with a Bluetooth device, this device will be "remembered”...
  • Page 41 A PIN Entry request will pop up on the 2 Bluetooth connecting devices for paring. Note: Here is an example screen captured from the IVT Ø Bluetooth dongle and the pertaining AP installed on the PC. Enter the same pin code on both sides. Select service at “Service”...
  • Page 42 Installing the Microsoft ActiveSync To synchronize the Mobile System with a PC, we need to install the Microsoft ActiveSync Program on the PC. Please refer the detail installation procedures to the Microsoft official website. Check the Assigned Bluetooth Serial Com Port Check to see what the Bluetooth serial port is assigned.
  • Page 43 Setup COM Port in the ActiveSync Program The COM port is only setup for the first time. Open the Microsoft ActiveSync Program on your PC. Choose “File” > “Connection Settings” menu on the toolbar. A “Connections Settings” dialog box will appear. Enable the “Allow connections to one of the following”...
  • Page 44 “Hide” to hide the message. After running the “repllog”, the Mobile System connects to the PC automatically and a “New Partnership” is requested to set up for the first time. Press “Next” button. A “Select Synchronization Settings” window will appear. Press “Setting”...
  • Page 45 To press “Finish” button to complete the setup procedure. Disconnecting the PC Go to “Start” > “Settings” > “Control Panel” > “Bluetooth Device” on the Mobile System. Press “Deactive Service” button to disable the service and disconnect the PC.

  • Page 46: Bluetooth File Transfer (Ftp)

    3-2-5 Bluetooth File Transfer (FTP) To transfer files from a PC to the Mobile System, please turn on the Bluetooth connection and scanning the Bluetooth enabled PC In this case, we use IVT Bluetooth Dongle and the pertaining AP as an example.
  • Page 47 Access the files on the Mobile System To Select “My Device” icon on Today Screen. Click “View” > “Options” on the toolbar. To disable the 3 check boxes on the “Folder Options” dialog box. You will see the “Temp” folder appears on the “My Device” Window. If the files transferring is successful.

  • Page 48: Backup And Restoring The System

    Backup and Restoring the System Go to “Start” > “Control Panel” > “Device Config”. 3-3-1 B ackup the System 4 5 B To restore the system, please follow Chapter 3-3 then the below steps. Select “Backup” tab then enable the “Entire the registry on your device”...

  • Page 49: Restoring The System

    Press “Browse” button if you want to specify the location Backup Files to be saved to. Press “Backup” button to start backup the system. 3-3-2 Restoring the System To restore the system, please follow Chapter 3-3 then the below steps. Press “Restore”.

  • Page 50: Switching The Admin / User Mode

    Switching the Admin / User mode Please follow below steps to access the Mode Change screen. “Start Menu” > “Settings“ > “Control Panel“ > “Password“ > Enter Password (default is 1111) The “Password Properties” dialog will popup after entering the password (default), select the Mode you want.

  • Page 51: Power Management Settings

    Power Management Settings 3-5-1 CPU Power Mode Settings Select “Start” > ” Control Panel” > ” FPM” button Select the mode you want on the “FPM” window. Note: The CPU Power Consumption is ranked as: Ø ” Performance Mode” > ” Dynamic Power Management” > ” Power Saving Mode”.

  • Page 52: System Configuring Power Mode Settings

    3-5-2 System Configuring Power Mode Settings Click “Start” > ” Control Panel” > ” Power” button Select “Schemes” tab. Set up the power mode as “Battery Power” or “AC Power” in the “Power Scheme” drop down menu. To set up the times you want on each option for turning the Mobile System off or going to standby mode after a period of inactivity.

  • Page 53: Display Backlight Settings

    3-5-3 Display Backlight Settings Go to “Start” > “Control Panel”. Double click on the “Display” icon. In the “Display Properties” window, select “Backlight” tab. You can enable the backlight savings by checking and setting turn-off time in the checkboxes of “Battery power…”, “External power…” and “Enable Dim Mode…”...

  • Page 54: Wifi Power Mode Settings

    3-5-4 WiFi Power Mode Settings To tap “Start” > ”Control Panel” > ”Network and Dial-up Connections” button. Hold to press “GSPI86861” button until the drop down menu appears. Press “Enable” in the drop down menu to active the WiFi Connection. After step “c”, the “GSPI86861”...

  • Page 55: Led Indicator Description

    LED Indicator Description The LED indicator is located in the front of the Mobile System which indicates the status of Power on/off, the Main Battery and WiFi Link. The Description as follows: Green color LED: Battery power charging state(S/W) LED ON: Battery power charging finished (100%) Orange color LED: Battery power charging state(S/W) LED ON: Battery power charging...

  • Page 56: Resetting The Mobile System

    Resetting the Mobile System The mobile system provides functions of “Reset to the factory default settings” and “cold boot”. The detail procedures as bellows: 3-7-1 Reset to the Factory Default Settings Use a tool to gently press the “Reset Hole” on the rear of the Mobile System while keep holding down the “Power Button”...

  • Page 57: Cold Boot

    3-7-2 Cold Boot Use a tool to gently press the “Reset Hole” on the rear of the Mobile System while keep holding the “Power Button” throughout. Release the press of “Reset Hole” and the “Power Button” at the same time after system vibration occurs. System reboot to Today Screen as above picture shows.

  • Page 58: Application Programming Interface

    Application Programming Interface Windows Embedded CE 5.0 Standard I nterface Introduction 2 1 B Most of software programming interfaces of each device are following WindowCE standard architecture to be designed. Core OS Service (Uhttp://msdn.microsoft.com/en-us/library/aa450512.aspxU) Kernel (HUhttp://msdn.microsoft.com/en-us/library/aa450998.aspxUH) P rogramming interface of RAM file system 2 2 B File system and storage management (HUhttp://msdn.microsoft.com/en-us/library/ms892386.aspxUH)
  • Page 59 P rogramming interface of Audio 2 5 B Audio h ttp://msdn.microsoft.com/en-us/library/ms890653.aspx Audio Drivers h ttp://msdn.microsoft.com/en-us/library/aa910103.aspx P rogramming interface of Display(LCD) 2 6 B Shell and User Interface h ttp://msdn.microsoft.com/en-us/library/aa453940.aspx Graphic h ttp://msdn.microsoft.com/en-us/library/ms923392.aspx Display Drivers h ttp://msdn.microsoft.com/en-us/library/aa447505.aspx P rogramming interface of USB Host 2 7 B USB Host Drivers h ttp://msdn.microsoft.com/en-us/library/ms923751.aspx...
  • Page 60 h ttp://msdn.microsoft.com/en-us/library/aa917156.aspx Networking - Remote h ttp://msdn.microsoft.com/en-us/library/aa920180.aspx Networking – Wireless (Bluetooth) h ttp://msdn.microsoft.com/en-us/library/aa917877.aspx P rogramming interface of Wireless 3 1 B Network Driver h ttp://msdn.microsoft.com/en-us/library/aa919639.aspx Networking - Core h ttp://msdn.microsoft.com/en-us/library/aa917156.aspx Networking - Remote h ttp://msdn.microsoft.com/en-us/library/aa920180.aspx Networking – Wireless (Wi-Fi) h ttp://msdn.microsoft.com/en-us/library/aa916578.aspx P rogramming interface of Touch 3 2 B Touch Screen Drivers...
  • Page 61 Programming interface of System Power Battery Drivers (Battery) h ttp://msdn.microsoft.com/en-us/library/aa932396.aspx Power Management (Power status – battery/DC) ( HUhttp://msdn.microsoft.com/en-us/library/aa923906.aspxUH ) Programming interface of Power Management Power Management h ttp://msdn.microsoft.com/en-us/library/aa923906.aspx...

  • Page 62: Non Windowsce Standard

    Non WindowsCE Standard 4-2-1 Admin/User Mode Application Architecture Introduction: System provides three pair of directories to map the working folder of each operating mode. Working folders name of Admin mode /Windows/Desktop File folder for saving the shortcut of application program in the Desktop. /Windows/Programs File folder for saving the shortcut of application program in the Programs tab at start menu.
  • Page 63 Switching between Admin mode and User mode There is a control box in control panel applet, named - “Password”, The Manufacturer redefine the password policy of WindowCE standard. The password control box should input the password in advance to enter the page for finding the selection items of changing the operating mode and/or reset the default password.

  • Page 64: Overwrite Factory Default

    4-2-2 Overwrite Factory Default Architecture Introduction: The Manufacturer provides a mechanism to merge the OEM application and OEM specific settings into WindowCE operating system during booting phase. This feature can make OEM stuffs as system default components. There are many benefits for device maintenance. It is a valuable feature for OEM doesn’t have to reinstall OEM programs after end user reset the device to factory default mode.
  • Page 65 Merge an application program into default operating system by using the OEM Device Manager Example: For Auto-running the OEM application at booting phase of user mode when after reset to factory default. Create a file directory “GHARST” in root folder of SD card. Change into “GHART”...
  • Page 66 Oem.cfg – Using for system registry initialization stage at booting phase. Example: Overwrite the factory default backlight level setting. Create a file directory “GHARST” in root folder of SD card. Change into “GHART” folder to create directory “configfiles”. Prepare the oem.cfg config file by text editor. Input following setting: [HKEY_CURRENT_USER\ControlPanel\BackLight] "BatteryBacklightLevel"=dword:7...
  • Page 67 Overwrite Factory Default Registry Settings for OEM Customization (oem.cfg) <1> Bluetooth operating mode [HKEY_LOCAL_MACHINE\System\State\Hardware\Bluetooth] “BluetoothOn”=dword:1 ; 1-> BT on, 0->BT off ;1-> Enable, 0-> Disable “BluetoothWakeUpEnable”=dword:0 <2> WiFi operating mode [HKEY_LOCAL_MACHINE\Comm\NdisPower] “GSPI86861”=dword:4 ; 0-> WiFi on, 4->WiFi off [HKEY_LOCAL_MACHINE\Comm\GSPI86861\Parms] “PowerMode” = dword:1 ;...
  • Page 68 Enable/Disable <5> Keypad control [HKEY_LOCAL_MACHINE\Drivers\BuiltIn\KEYPAD] "KeyPadSet0"=dword:27280000 "KeyPadSet1"=dword:25260000 <6> CPU operating frequency control Option1: Dynamic Mode [HKEY_LOCAL_MACHINE\Drivers\BuiltIn\IPM] "ProfileType"=dword:0 Option2: Performance Mode [HKEY_LOCAL_MACHINE\Drivers\BuiltIn\IPM] "ProfileType"=dword:1 "Speed"=dword:0 Option3: Power Saving Mode [HKEY_LOCAL_MACHINE\Drivers\BuiltIn\IPM] "ProfileType"=dword:1 "Speed"=dword:4...
  • Page 69 Application program of the OEM Device Manager Snapshoot of OEM Device Manager System Layer : “system.cfg” file update OEM Layer : “oem.cfg” file update Press “OK” button to merge the GHARST directory and specified layer config files into OS image...
  • Page 70 Overwrite display backlight settings Once the backlight is enabled, you can set separately both battery backlight setting and backlight setting of AC power. System Integrator can use Control Panel to change the setting values or modify the following registry keys to change settings.
  • Page 71 // Battery Level lResult = RegSetValueEx(hRegBacklight, L"BatteryBacklightLevel", 0, dwType, (LPBYTE)&dwVal, dwLen); // AC Level lResult = RegSetValueEx(hRegBacklight, L"AcBacklightLevel", 0, dwType, (LPBYTE)&dwVal, dwLen); RegCloseKey(hRegBacklight);...

  • Page 72: Programmable Button Feature

    4-2-3 Programmable button feature Five buttons designed on front bottom of B21 device. Keypad driver will report the Windows virtual key code what described in a registry key to system when button to be pressed. System Integrator can modify the registry key value of each button separately.
  • Page 73 VK_BACK BACKSPACE key VK_TAB TAB key 0AH-0BH Undefined VK_CLEAR CLEAR key VK_RETURN ENTER key 0EH-0FH Undefined VK_SHIFT SHIFT key VK_CONTROL CTRL key VK_MENU ALT key VK_PAUSE PAUSE key VK_CAPITAL CAPS LOCK key 15H-19H Reserved for Kanji systems Undefined VK_ESCAPE ESC key 1CH-1FH Reserved for Kanji systems VK_SPACE...
  • Page 74 VK_SELECT SELECT key Specific to original equipment manufacturer VK_EXECUTE EXECUTE key VK_SNAPSHOT PRINT SCREEN key VK_INSERT INS key VK_DELETE DEL key VK_HELP HELP key 3AH-40H Undefined Left Windows key on a Microsoft Natural VK_LWIN Keyboard Right Windows key on a Microsoft VK_RWIN Natural Keyboard Applications key on a Microsoft Natural...
  • Page 75 VK_MULTIPLY Multiply key VK_ADD Add key VK_SEPARATOR Separator key VK_SUBTRACT Subtract key VK_DECIMAL Decimal key VK_DIVIDE Divide key VK_F1 F1 key VK_F2 F2 key VK_F3 F3 key VK_F4 F4 key VK_F5 F5 key VK_F6 F6 key VK_F7 F7 key VK_F8 F8 key VK_F9 F9 key...
  • Page 76 VK_F19 F19 key VK_F20 F20 key VK_F21 F21 key F22 key VK_F22 (PPC only) Key used to lock device. VK_F23 F23 key VK_F24 F24 key 88H-8FH Unassigned VK_NUMLOCK NUM LOCK key VK_SCROLL SCROLL LOCK key VK_LSHIFT Left SHIFT VK_RSHIFT Right SHIFT VK_LCONTROL Left CTRL VK_RCONTROL...
  • Page 77 manufacturer Used to pass Unicode characters as if they were keystrokes. If VK_PACKET is used with SendInput, then the Unicode character to be delivered should be placed into the lower 16 bits of the scan VK_PACKET code. If a keyboard message is removed from the message queue and the virtual key is VK_PACKET, then the Unicode character will be the upper 16 bits of the...
  • Page 78 Example code void ModifyKeyCode(DWORD data) //modify the virtual key code of up button HKEY hKeyPad = NULL; TCHAR RegStr[14], if (ERROR_SUCCESS == RegOpenKeyEx(HKEY_LOCAL_MACHINE, L"Drivers\\BuiltIn\\KEYPAD", 0, 0, &hKeyPad)) wsprintf(RegStr,L"KeyPadSet0"); //assign value name of up button dwSize = sizeof(DWORD); if (ERROR_SUCCESS == RegQueryValueEx(hKeyPad, RegStr, NULL, &dwType, (LPBYTE)&...

  • Page 79: Vibration Notification Feature

    4-2-4 Vibration notification feature A vibrator is designed into this device for notification usage. The vibrator driver is following the notification LED driver architecture of WindowCE to be developed. This architecture is easy for System Integrator using WindowCE NLED standard API for application development, and also provides the advantage of backward compatibility.
  • Page 80 MetaCycleOff Number of off blink cycles. (Not support – default 0) Example code #include "stdafx.h" NLED_SETTINGS_INFO ledSettingsInfo = { 0 }; void SetVibratorOn(void) ledSettingsInfo.LedNum = 0; ledSettingsInfo.OffOnBlink = 0; if(!NLedSetDevice( ,&ledSettingsInfo)) NLED_SETTINGS_INFO_ID MessageBox(L"NLED ghNLED = NULL!!",L"Error",MB_OK);...

  • Page 81: Optional Accessory Installation

    Optional Accessory Installation USB Cable There is only USB port with WindowsCE® ActiveSync® function to be exposed to software developer to develop and debug their software application. A specific application program located in “Application” Folder and named as “USB.EXE” to provide manual USB Activesync connection. A specific USB cable would be required.

  • Page 82: Synchronization Via Usb Cable

    5-1-1 Synchronization via USB Cable To synchronize the Mobile System with PC, please install the “Microsoft Active Sync” program on each PC first. The set-up of a “Partnership” will be requested once after connecting the USB Cable to the Mobile System and PC. The Synchronization will be running automatically after “Microsoft Active Sync”...

  • Page 83: Installing The Usb Cable

    5-1-2 Installing the USB Cable To Mobile To PC Unscrew the screws (2) on the back cover of the Mobile System to access the Connector Slot. Connect the white connector to the Mobile System. Connect the USB Connector to the PC device to communicate the Mobile System and the PC.

  • Page 84: Start The Synchronization

    5-1-3 Start the Synchronization After installing the “Microsoft® ActiveSync®” program at your PC, please enable it. You will see the “Connecting” is running automatically after USB Cable is connected the Mobile System and PC. NOTE: If the “Connecting” is not running automatically, Ø...

  • Page 85: Enable The Synchronization Manually

    5-1-4 Enable the Synchronization Manually If the synchronization is not running automatically after connecting the USB Cable to your PC and the Mobile System, please follow below steps. Double-click on the “My Device” icon on Today screen. Double-click on the “Application Data” folder. Double-click on the “usb”...
  • Page 86 Select “USB” tab Press “Connect” button. Select “ActiveSync” tab. Select “ACTIVE SYNC” button. Press “OK” button.

  • Page 87: Msr Module Installation

    MSR Module Installation Unscrew the screws (2) on the rear side of the Mobile System. Slide upward to open the Connector Cover to access the connector slot. Connect MSR cable to the respective connector on the connector slot of the Mobile System.
  • Page 88 To make sure the metal juts are entered to the right position of the system. Use the attached screws (2) to fix the MSR module to the Mobile system as above photo shows.
  • Page 89 Finished. Front view of the MSR module and the Mobile system.

  • Page 90: 2-In-1 Msr And Scanner Module Installation

    2-in-1 MSR and Scanner Module Installation MSR Cable Scanner Cable To open the connector cover on the Mobile System first by following the steps in Chapter 5.2.1 Connect cables (2) to the respective connectors on the connector slot of the Mobile System. To make sure the metal juts are entered into the right position of the Mobile System.
  • Page 91 To use the attached screws (2) to fix the 2-in-1 MSR module to the Mobile System. Finished. The front view of the 2-in-1 MSR and Scanner Module with the Mobile System.
