Trademarks
®
TM
TM
TM
Autel
, Maxaero
, X-Memo
and X-Star
are trademarks of Autel Aerial
Technology Co., Ltd., registered in China, the United States and other
countries. All other marks are trademarks or registered trademarks of their
respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of
Maxaero.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on
the latest information available at the time of printing. Maxaero reserves the
right to make changes at any time without notice. While information of this
manual has been carefully checked for accuracy, no guarantee is given to
the completeness and correctness of the contents, including but not limited
to the product specifications, functions, and illustrations.
Use the products within the limits permitted by local laws and regulations. In
purchasing the products, the buyer/user agrees to bear full responsibilities of
the results of using this product. Maxaero will not be liable for any direct
damages or for any special, incidental, or indirect damages or for any
economic consequential damages (including lost profits).
IMPORTANT: Before operating or maintaining this unit, please read this
manual carefully, paying extra attention to the safety warnings and
precautions.
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-Star ST1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxaero X-Star ST1

  • Page 1 Use the products within the limits permitted by local laws and regulations. In purchasing the products, the buyer/user agrees to bear full responsibilities of the results of using this product. Maxaero will not be liable for any direct damages or for any special, incidental, or indirect damages or for any economic consequential damages (including lost profits).
  • Page 2: Safety Information

    IMPORTANT: This product is not intended for use by children without adult supervision. Do not use with incompatible components or alter this product in any way inconsistent with the instructions provided by Maxaero. Fly with an experienced pilot for the first flight is strongly recommended.
  • Page 3: About Battery Usage

    About Battery Usage The product is powered by a built-in Lithium-ion Polymer battery. LiPo/Li-Ion batteries can be extremely hazardous and special attention is required during usage. Read and follow all safety messages and instructions presented to avoid personal injuries or property damages. DANGER: The built-in Lithium-ion Polymer battery is factory replaceable only;...
  • Page 4 Always keep the battery within normal temperatures. Completely discharge the battery prior to disposal. Dispose of the battery properly. For Services and Support: http://www.maxaero.com 0086-755-86147779 (China) Support@maxaero.com Or contact your local selling agent for technical assistance in all other markets.
  • Page 5: Table Of Contents

    Contents DISCLAIMER OF WARRANTIES AND LIMITATION OF LIABILITIES ....... I SAFETY INFORMATION ..................II ABOUT BATTERY USAGE ...................III CHAPTER 1 USING THIS MANUAL ..............1 ..................1 ONVENTIONS 1.1.1 ..................1 1.1.2 ..................1 ERMINOLOGY 1.1.3 ............1 OTES AND MPORTANT ESSAGES 1.1.4...
  • Page 6 ............... 32 REPARING EMOTE ONTROLLER 3.2.1 ............33 PAIRING EMOTE ONTROLLER ............... 34 REPARING OBILE EVICE 3.3.1 ..............35 NSTALLING OBILE 3.3.2 ..............35 EGISTERING CCOUNT 3.3.3 ............35 STABLISHING ETWORK 3.3.4 ............36 PAIRING ETWORK PC A ................. 38 NSTALLING UITE 3.4.1...
  • Page 7: Chapter 1 Using This Manual

    Chapter 1 Using This Manual This manual contains product usage instructions. Some illustrations shown in this manual may contain optional modules or accessories that are not included on your system. Contact your sales representative for availability of other modules and optional accessories. 1.1 Conventions The following conventions are used.
  • Page 8: Hyperlinks

    1.1.4 Hyperlinks Hyperlinks, or links, that take you to other related articles, procedures, and illustrations are available in electronic documents. Blue colored text indicates a selectable hyperlink. 1.1.5 Procedures An arrow icon indicates a procedure. Example: ¾ To use the camera: Tap the Camera button.
  • Page 9: Chapter 2 General Introduction

    2.1 In The Box The complete X-Star ST1 standard package comes with the following items. Before using the system, check if everything is included. NOTE: The package may or may not contain the camera and the camera accessories kit depending on the Gimbal system purchased.
  • Page 10 Image Qty. Description Gimbal Lock Protects the Camera Gimbal when not in Lens Cap Protects camera lens from dust and scratches Gimbal Camera Securing Bracket Secures the camera to the mount Remote Controller Phone holder and 5000mAh Li-Ion battery included Aircraft Battery 6400mAh Rechargeable Li-Po battery Provides 25 minutes of flight time if fully...
  • Page 11 Image Qty. Description Manuals User Manual X-Star ST1 Quick Start Guide Camera Mount Quick Start Guide (for camera attached gimbals) PC Suite Suitable for: Includes PC Aid Program and User Windows 8 Windows 7 Windows Vista ‡ indows XP Manual, etc.
  • Page 12 Camera Accessories Kit Image Qty. Description Waterproof Housing Allows underwater photographing. Backdoors Opened (without cover, not waterproof) Covered (with touchable screen protector) Camera Battery 940mAh Rechargeable Li-Po Battery installed on delivery Flat Mount Curved Mount Short Connectors Long Connector 90 C Rotate Connector (long) 90 C Rotate Connector (short) Connecting Screw (long) Connecting Screws (short)
  • Page 13: Aircraft

    2.2 Aircraft The X-Star aircraft is a quadcopter with an integrated stabilized camera gimba. The camera may or may not be supplied depending on the gimbal model purchased. The Micro-USB port on the aircraft supports convenient connection that allows easy flight configuration and system update through the PC Aid Software.
  • Page 14 Figure 2-2 Rear Side Rear LED Indicator Light – indicates flight status Aircraft Battery 10. RC Pairing Button – prepares the aircraft to perform pairing with the Remote Control, see 3.2.1 Re-pairing Remote Controller on page 33 for detailed instructions 11.
  • Page 15: Built-In Smart Flight System

    Item Descriptions Propeller Size 9.4”x4.3” WiFi Frequency 2.4GHz Receiver Frequency 5.8GHz Flight Modes ATTI Waypoint Operating Environment Temperature 0 C~50 C (32 F~122 F) Storage Temperature 0 C~45 C (32 F~113 F) Weight (Battery & Propellers 1.1kg included) 2.2.2 Built-in Smart Flight System The X-Star features the Built-in Smart Flight System which enables autopilot flight control that provides great ease of use and stability.
  • Page 16 Table 2-4 Smart Flight System Functions Function Descriptions Configures the aircraft to fly in the direction relative to the home point or consistent to the initial aircraft orientation, instead of its nose and tail. Commands the aircraft to return to and land on the Go Home specified home point.
  • Page 17: Flight Led Indicator Light

    2.2.3 Flight LED Indicator Light The LED Indicator Lights on the aircraft can be found at both the front and rear sides. The Front Indicators are mainly used for helping pilots to identify the position of the aircraft nose, and the Rear Indicators are used for showing the current flight status of the aircraft.
  • Page 18: Aircraft Battery

    LED Indicator Status Descriptions Light up when battery voltage is less than R- -Quick (Rear LEDs) 20%. Indicates compass calibration is required. Y- (Front & Rear LEDs) 4.2 Calibrating Compass on page 41 for detailed instructions. Displayed during the 1 step of compass Y- (Rear LEDs) calibration.
  • Page 19 Table 2-7 Aircraft Battery Features Feature Descriptions Balances the voltage of each battery cell to Balancing prevent overcharging or over-discharging. Retrieves and transfers battery info, including Communication battery level, current, voltage, battery life, and temperature to the aircraft and the controller. Charging Temperature Stops battery charging when environment Detection...
  • Page 20 Aircraft Battery Specifications Table 2-8 Aircraft Battery Specifications Descriptions Item Battery Type Rechargeable Li-Po Battery Capacity 6400mAh Battery Voltage 11.1V Charging 0 C~40 C (32 F~104 F) Environment Temperature Discharging -20 C~60 C (-4 F~140 F) Environment Temperature Storage Temperature & Humidity Temp: -10 C~45 C (14 F~113 F);...
  • Page 21 Capacity Indicator Lights Power Button – allows you to check the battery level and turn on/off the battery To turn on the battery and power up the aircraft, long press the Power Button for 3 seconds. The Capacity Indicator Lights will illuminate and indicate the current battery level.
  • Page 22: 3-Axis Camera Gimbal

    2.2.5 3-axis Camera Gimbal The 3-axis Camera Gimbal mounted to the aircraft is specially designed to allow smooth aerial photographing to minimize camera vibration or shake. It is powered through the Aircraft Battery, and therefore it is turned on at the same time with the aircraft. A self-test is performed each time the Gimbal starts up.
  • Page 23 Mounting Rack Vibration Absorber Anti-drop Lock Pin Press the pin through the hole at the corner of the gimbal’s mounting rack with the Vibration Absorber in between; Press the stud from the bottom up to lock the pin. Aircraft Communication Port Camera Connector Micro-USB Port –...
  • Page 24: Camera

    The 3-axis Camera Gimbal for X-Star supports 2 working modes: FPV Mode – synchronizes the camera gimbal movements with the aircraft to provide a real time video piloting experience from a first-person view. Non-FPV Mode – enables stabilized camera tilting control for creative aerial photography.
  • Page 25 1. Shutter/Select Button 2. Power/Mode Button 3. WiFi Status Light (blue) 4. Camera Status Light (red) 5. Micro HDMI Port 6. MicroSD Card Slot 7. Mini USB Port 8. LED Status Light 9. Microphone 10. Touch Screen 11. Audio Speaker 12.
  • Page 26: Remote Controller

    Name Description 9. Microphone Records sound when taking videos. Works as the display monitor featuring 10. Touch Screen intuitive touch control. 11. Audio Speaker Makes alert sounds and plays audios. Locks or unlocks the Battery Compartment. 12. Battery Contains a 940mAh rechargeable Li-Po Compartment Lock battery.
  • Page 27: Functional Description

    The built-in 2.4GHz WiFi module on the Remote Controller allows self-generated WiFi network connection for real time flight and video data transmission between the aircraft and the mobile device enabling convenient controls of aerial photographing and remote piloting. NOTE: The X-Star WiFi Network is only established when the aircraft, the Remote Controller and the mobile device are properly connected through WiFi connection.
  • Page 28 13. Support Stand 14. Re-pair Hole 15. WiFi Switch 16. CE/FCC Control Screw 17. Buzzer 18. Battery Compartment Table 2-13 Remote Controller Functional Descriptions Name Description 5.8GHz signal antenna communicates with and transmits control signals to the aircraft. 1. WiFi & RF Antennas The 2.4GHz WiFi antenna receives and transfers flight data and camera data to the X-Star Mobile App.
  • Page 29 Name Description Set by default: Throttle Up and Down: ascends and 6. Left Command Stick descends Rudder Left and Right: yaws left and yaws right Set by default: 7. Right Command Elevator Up and Down: forward and Stick backward Aileron Left and Right: left and right 8.
  • Page 30: Remote Controller Indicator Lights

    Name Description Pressing the Re-pair Hole with a thin rod 14. Re-pair Hole allows re-pairing the X-Star WiFi network. Switches on/off the WiFi module to allow 15. WiFi Switch flight and video data transmission between the aircraft and the mobile device. Turn the control screw for a full clockwise turn to set as CE compliant;...
  • Page 31 The definitions for each of the Indicator Light are described in the table below: Table 2-14 Remote Controller Indicator Lights Item Button Description Shows green light when GPS mode is enabled and more than 6 GPS satellite signals are received; GPS Signal Shows red light when the GPS mode is disabled or less than 6 GPS satellite...
  • Page 32: Technical Specifications

    Item Button Description Lights up when pressed, turns off when Take Off released. Lights up when pressed, turns off when Landing released. 2.3.3 Technical Specifications Item Descriptions Operating Frequency 5.8GHz (RF Receiver) WiFi Repeater Frequency 2.4GHz Operating Temperature 0 C~50 C Storage Temperature -20 C~75 C Communication Distance...
  • Page 33: Chapter 3 Pre/Post-Flight Operations

    Chapter 3 Pre/Post-flight Operations The X-Star features the user-friendly design that requires very simple assembly to get the aircraft ready to fly. However, it is essential to read and follow all the instructions and warnings in this manual, prior to assembly, setup or use, in order to operate correctly and avoid damages or injuries.
  • Page 34: Installing Propellers

    Replace the Gimbal Lock to protect the gimbal from accidental rotation to avoid damage when not in use. 3.1.2 Installing Propellers IMPORTANT: Do not power up the aircraft while installing or removing the propellers. Use only authorized propellers. It is recommended to wear protective gloves when assembling and removing the propellers.
  • Page 35: Charging Flight Battery

    IMPORTANT: Check and ensure every propeller is properly installed and in good condition before each flight. Keep off and do not touch the propellers and motors when they are spinning. 3.1.3 Charging Flight Battery ¾ To charge the Aircraft Battery NOTE: If the current battery level is 80%, turn on the battery before charging.
  • Page 36: Installing And Removing The Battery

    Table 3-1 Capacity Indicator Status while Charging - Indicates solid green light; - Indicates flashing green light Indicator Status Battery Level 3.1.4 Installing and Removing the Battery ¾ To install the battery Make sure the battery is powered off before installation. Insert the battery into the aircraft battery compartment as shown below (Figure...
  • Page 37: Mounting The Camera

    In the case when the purchased gimbal set does not come with a camera. The camera needs to be mounted manually by the user before flight. NOTE: Use only cameras authorized or specified by Maxaero which are compatible with the gimbal. ¾...
  • Page 38: Preparing Remote Controller

    Figure 3-4 Mounting the Camera 3.2 Preparing Remote Controller ¾ To charge the Remote Controller Connect the remote controller to the USB Power Adapter using the Micro USB Cable supplied. Plug the USB Power Adapter to the wall socket. The Power Button on the remote controller will show flashing red light during charging.
  • Page 39: Re-Pairing Remote Controller

    To power up the remote controller ¾ NOTE: It is recommended to power up the remote controller before turning on the aircraft. Adjust the remote controller power output by twisting the CE/FCC Control Screw using a Philips screwdriver. Turn the screw clockwise for a full turn to set as CE compliant;...
  • Page 40: Preparing Mobile Device

    To re-pair the aircraft and the remote controller ¾ Turn off the remote controller. Turn on the aircraft. Press and hold the RC Pairing Button on the aircraft for about 3 seconds, the pairing indicator beside the RC Pairing Button will flash slowly in green light, indicating the aircraft is ready to re-pair.
  • Page 41: Installing Mobile App

    1. Power up the mobile device, and launch the browser after the internet connection is enabled. 2. Login to the official website: http://www.maxaero.com. 3. Click Download on the home page. 4. Search and download the installation file of X-Star Mobile 5.
  • Page 42: Re-Pairing X-Star Wifi Network

    To connect the mobile device with the X-Star network ¾ 1. Power up the remote controller. 2. Power up the X-Star aircraft. 3. Switch on the Wi-Fi connection on your mobile device. 4. Tap the Settings option on your mobile device. Turn on the WiFi function, and select the X-Star Network from the list.
  • Page 43 5. Enable Wi-Fi connection on your mobile device. 6. Select the X-Star Wi-Fi network from the list. 7. Tap to launch the X-Star Mobile App, and tap the Settings icon. 8. Choose Pairing in the menu list to enter the Pairing page (Figure 3-5).
  • Page 44: Installing Pc Aid Suite

    3.4 Installing PC Aid Suite The PC Aid Suite is specially developed for enhancing aircraft capabilities and refining flight performance. This comprehensive program allows users to perform pre and post flight configurations and upgrade firmware for the X-Star aircraft, gimbal and remote controller on the PC.
  • Page 45 Figure 3-6 Login Prompt After successful registration, enter your X-Star username and password to sign in the PC Aid operation program. 4.5 PC Aid Operations on page 79 for detailed operation instructions of the PC Aid software.
  • Page 46: Flight Operations

    Chapter 4 Flight Operations After all pre-flight preparations have been done properly, before proceeding to perform your first flight, take a few minute to familiarize yourself with the controls of your X-Star by following the operation instructions described in this section. IMPORTANT: Before flying the X-Star aircraft, make sure all safety instructions presented throughout this manual be read and understood by all persons operating, or coming into contact with the product.
  • Page 47: Calibrating Compass

    The mobile device is mounted to the remote controller and properly connected to the X-Star WiFi Network. The ground station on the X-Star Mobile App is enabled. The camera function on the X-Star Mobile App is synchronizing with the mounted camera. Familiarize yourself with the flight controls.
  • Page 48 Hold the aircraft horizontally and revolve for 360 around. The rear LEDs on the aircraft will change into solid green lights when this is done successfully. Figure 4-1 Horizontal Calibration Hold the aircraft vertically with the nose down and rotate for 360 around.
  • Page 49: Remote Controller And Flight Operations

    4.3 Remote Controller and Flight Operations The Remote Controller is specially designed for convenient remote flight controls with 2 command sticks for aerial maneuvers in different directions, including Pitch, Roll, Yaw and Vertical (ascent and descent). The Smart Control Switch on the top left of the remote controller front panel allows pilots to conveniently activate the safety features –...
  • Page 50: Flight Attitude Controls

    Figure 4-3 Motor Start-up or Shut-down Release the sticks gently and simultaneously after the motors have started spinning for 2 seconds. Command the aircraft to take off. There are 2 methods available: Push the Throttle upward to take off the aircraft manually.
  • Page 51 The 4 primary flight controls include: Throttle – commands the aircraft to ascend by pushing the stick upward, and descend by pushing it downward. Figure 4-4 Throttle Control – Aircraft Left Side View Rudder – commands the aircraft to yaw left or right by pushing the Rudder left or right.
  • Page 52 Rudder left Nose Yaws Left Figure 4-5 Rudder Control- Aircraft Top View Elevator – commands the aircraft to pitch up and down to move forward or backward by pushing the Elevator upward or downward. Elevator down Forward Elevator up Backward Figure 4-6 Elevator Control –...
  • Page 53: Landing And Motor Shut-Down

    Aileron – commands the aircraft to roll left or right by pushing the Aileron left or right. Aileron left left Aileron right right Figure 4-7 Aileron Control – Front View 4.3.3 Landing and Motor Shut-down The aircraft may be landed manually, automatically, or passively depending on different circumstances.
  • Page 54 To manually land the aircraft and shut down the motors ¾ Maneuver the aircraft to the desired position for landing. Release the command sticks when the aircraft reaches the target position to let it hover. Push the Throttle down slightly and gently to land the aircraft.
  • Page 55: Operations Of Smart Flight Features

    Landing due to low battery Generally it is recommended to land the aircraft immediately when the battery level reaches 20% or lower, this will be indicated by the indicator lights on both the aircraft and the remote controller. The rear LEDs on the aircraft will show quick flashing red lights.
  • Page 56 Descriptions of the IOC modes: Home Lock - configures the aircraft to fly in the direction relative to the home point, instead of its nose and tail. In this mode, the Elevator will always move the aircraft on a line towards or away from the initial take-off location, and the Aileron will make it move right or left perpendicular to that line.
  • Page 57 NOTE: For safety reasons, if the aircraft is hovering at the altitude lower than 30 meters when the Go Home function is activated, it will ascend to the 30-meter altitude before starting to return. To manually regain control of the aircraft during the activated Go Home procedure, take one of the methods below: When Go Home is activated manually Toggle the Smart Control Switch from Go Home position to...
  • Page 58 A home point is usually memorized by the system as the point where the aircraft motors start up each time. The home point can also be repositioned during flight. Reposition the home point during flight ¾ Maneuver the aircraft to the desired home point. Release the command sticks when the aircraft reaches the target position to let it hover.
  • Page 59: X-Star Mobile App Operations

    4.4 X-Star Mobile App Operations The X-Star Mobile Application is a fully-featured program with 4 essential functions. It configures your mobile to perform as the central monitor for remote piloting control, aerial shooting and recording, and helps to tune the aircraft parameters to achieve refined and smooth flight performance.
  • Page 60 Figure 4-9 X-Star Mobile App Main Menu The application buttons on the Main Menu are listed and described in the table below: Table 4-1 Application Buttons Name Button Description Allows data synchronization for Camera image display and camera pairing for FPV or non-FPV navigation Allows to locate the aircraft, and Ground Station...
  • Page 61: Camera Operations

    4.4.2 Camera Operations The Camera function works as a flight monitor that synchronizes the screen display with the onboard camera, allowing users to perform various camera operations and configurations for aerial photo-and-video shooting. To enter the Camera Operation screen (Figure 4-10), tap the Camera button on the Main Menu.
  • Page 62 Normal Mode In this mode, the camera pitch movement is controlled by the pitch scroll bar. Scroll it up to tilt the camera upwards or down to tilt the camera downwards. Physical Control Mode In this mode, the camera pitch angle simulates with the motions of the mobile device.
  • Page 63 Camera Operation Panel The Camera Operation Panel includes 5 items, the functions of which are described respectively from top to bottom as follows: Camera Settings – opens the camera settings menu Camera Mode – allows choosing different camera modes, including single capture, burst mode, timed capture and video shooting Shooting Button –...
  • Page 64 Camera Settings By tapping the Settings button, the Settings Panel will be displayed (Figure 4-11), which allows you to adjust camera configuration settings. Figure 4-11 Camera Settings Panel The functions of each setting option are described in the table below: Table 4-3 General Camera Settings Settings Button...
  • Page 65 Settings Button Options TV System PAL; NTSC (default) Format (default) Reset (default) NOTE: When you select Format in camera settings, the SD card will be formatted. Make sure to create a back-up copy of the SD card files. When you select TV system to view a TV/HDTV, select NTSC for North American televisions;...
  • Page 66 Single Capture: press Shooting button once for a single photo Burst Mode: press Shooting button once for continuous capture Time Lapse: press Shooting button once to begin a timed capture, and press again to stop 2. Tap the Shooting button to run the selected camera mode action.
  • Page 67: Ground Station Operations

    4.4.3 Ground Station Operations The Ground Station function allows you to create flight plans by placing waypoints, setting waypoint altitude, hover time and overall speed, etc. To perform this function, tap the Ground Station icon on the Main Menu, and select a desired map type (Gmap or Amap) to initiate the program.
  • Page 68 Table 4-4 Control Panel Buttons Name Button Description Returns to X-Star Mobile App Main Back Menu Waypoints Opens the Waypoint Control Panel Start Uploads the flight mission Suspends execution of the flight Pause mission Aborts flight mission Go Home commands the aircraft home Landing Lands the aircraft Status Information Bar...
  • Page 69 Functional Buttons The Functional buttons are vertically aligned on the right side of the operation screen. They are mainly used for controlling flight speed, calibrating the compass, selecting map view and locating the home point. Detailed descriptions of the Functional Buttons are listed in the following table: Table 4-5 Functional Buttons Name Button...
  • Page 70 ¾ To view the map on Main Section: 1. Tap the Map View button to choose among the Normal, Hybrid or Satellite view. 2. Use two fingers to zoom in or zoom out the map. 3. Tap to move the map to view different areas. Camera Split Screen The Camera Thumbnail, located on the lower right corner of the screen, allows the pilot to view the current camera filming...
  • Page 71 Table 4-6 Waypoint Operation Buttons Name Button Description Back Exits the waypoint operation mode. Adds a waypoint. The total number of waypoints should not exceed 20. Waypoints cannot be added beyond Waypoints 500m from the home point or outside of the Safety Zone. Draw Creates the flight route by sliding Waypoints...
  • Page 72 ¾ To edit the waypoints: 1. Tap the desired waypoint number at the bottom of the screen. 2. Adjust the waypoint altitude and hover time as demanded. 3. Tap OK to complete the waypoint setting. ¾ To start the flight mission: 1.
  • Page 73: Configuration Operations

    4.4.4 Configuration Operations The Configuration program is designed to configure and upgrade the Smart Flight System and the Remote Controller. To optimize the X-Star system performance for accurate and stable flight maneuvering, it is recommended to perform configurations and firmware upgrades on a regular basis, either through PC Aid or X-Star Mobile App.
  • Page 74 Figure 4-15 Flight Limits Setting Screen You can set the maximum flight height and distance to protect the aircraft from losing signal or being out of control. When these limits are determined, the aircraft cannot fly outside the preset limit boundaries under GPS mode. In non-GPS mode, the aircraft is only restricted to the preset height limit.
  • Page 75 Figure 4-16 Gimbal Control Screen Angle Limits Horizontal Limit – sets the maximum angle on horizontal axis Vertical Limit – sets the maximum angle on vertical axis Control Sensitivity - adjusts the speed of camera pitch movement Mode Switch Non-FPV Mode –enables stabilized camera tilting control FPV Mode –synchronizes the camera gimbal movement with the aircraft...
  • Page 76 Speed Range Level Flight Speed 2m/s – 12m/s Descent Speed 1m/s – 3m/s Ascent Speed 1m/s – 6m/s Yaw Rate 60 /s - 360 /s Remote Controller The Remote Controller function enables the pilots to choose preferred transmitter modes, calibrate command sticks and testify if the Smart Control Switch and the Flight Mode Switch work properly.
  • Page 77 The Remote Controller configuration screen consists of 3 sections. Transmitter Modes Section There are 3 transmitter modes: Mode 1, Mode 2, and Mode 3. Each mode indicates how the movement of command sticks controls the actions of the aircraft correspondingly. Below are the illustrations of Mode 1, Mode 2, and Mode 3: Figure 4-18 Mode 1, 2 and 3...
  • Page 78 The table below describes the respective aircraft movements reacting to the movements of the command sticks. Table 4-7 Controls of the Command Sticks Command Stick Movement Aircraft Movement Throttle Up/Down Ascend/Descend Rudder Left/Right Yaw Left/Right Elevator Up/Down Forward/Backward Aileron Left/Right Left/Right Command Sticks Calibration There are 4 channels in total for command sticks...
  • Page 79 8. Tap Finish on the top right side to complete the calibration. If all scale icons (A, E, T and R) fall in the middle position, the remote controller is ready for use. Switch and Button Test The Switch and button Test section allows users to test the 2 switches on the front top of the remote controller and 2 buttons at the bottom of the remote controller.
  • Page 80 Failsafe The Failsafe mode is set to enable the aircraft to take default emergency protection procedure when communication with the remote controller is lost, to prevent damage or injury. Go Home is set as the priority protection measure when Failsafe is activated.
  • Page 81 Battery The Battery function allows you to view the current status and general information of the aircraft battery, and check the Low Battery Protection settings. There are 2 levels of protection measures for the inflight low battery concerns. Tap the Battery icon to enter the battery screen as below: Figure 4-21 Battery Screen The displayed battery information includes the following...
  • Page 82 First Level Protection – activated when the battery level drops below 10% that forces the aircraft to immediately land onsite It is highly recommended to activate the Go Home procedure or manually command the aircraft to return when the low battery alarm is triggered (i.e.
  • Page 83: Settings Operations

    Figure 4-22 IOC Screen NOTE: The flying direction is relative to the starting point but not the location of the pilot. Home Lock mode works in GPS mode only while Course Lock mode works in both GPS and ATTI modes. View Status Tapping View Status from the main menu displays an information screen, which presents an overview list of the...
  • Page 84 Camera Settings Toolbar Auto Hide – slide the button to enable or disable auto hide of the operation panels When Communication Lost – allows to set the camera operation mode in case when communication is lost Preview Quality – tap to select the resolution and frame rate Flight Control and Gimbal Settings Parameter Unit –...
  • Page 85: Pc Aid Operations

    4.5 PC Aid Operations The PC Aid Suite is specially developed for enhancing aircraft capabilities and refining flight performance. This comprehensive program allows users to perform pre and post flight configurations and upgrade firmware for the X-Star aircraft, gimbal and remote controller on the PC.
  • Page 86 The PC Aid Operation screen includes 3 main sections: Menu Bar The Menu Bar consists of 4 tags: Flight Control System Settings Gimbal Settings Remote Controller Settings Firmware Upgrades Selecting each tag will navigate you to the corresponding operation page. Navigation Pane The Navigation Pane displays all the items that are required to be adjusted or calibrated for the flight system, gimbal and...
  • Page 87 Name Button Description Enables the aircraft to take automatic Failsafe failsafe measure when communication with the remote controller is lost. Displays the battery information, and Battery allows activating/deactivating the low battery protection function. Allows pilots to set the IOC mode for easy aircraft navigation when its orientation is uncertain.
  • Page 88: Chapter 5 Maintenance And Service

    Chapter 5 Maintenance and Service To ensure optimum performance of the product, we advise that the maintenance instructions in this section are read and followed carefully. 5.1 Maintenance Instructions The following shows how to maintain your devices, together with precautions to take.
  • Page 89: Troubleshooting Checklist

    5.2 Troubleshooting Checklist This section helps users to detect possible causes to certain problems occurred, and provide feasible solutions to handle certain operation failures. When the aircraft indicates failure during self-check (with 4 LED lights flashing slowly in red and the buzzers beep all the time) Check if the IMU is properly calibrated through the PC Aid or X-Star Mobile App Check if the remote controller parameters are properly...
  • Page 90 When pairing up, the aircraft does not respond to the remote controller Make sure there is no large metal object, wireless source or other remote controller around If the Wi-Fi connection fails all the time Make sure to be free from all magnetic or signal interferences If the camera is powered off during video recording Keep the MicroSD card inside the camera.
  • Page 91: Service Procedures

    Contact local distributers or agents. Visit our website http://www.maxaero.com. Repair Service If it becomes necessary to return your device for repair, please download the repair service form from www.maxaero.com, and fill in the form. The following information must be included: Contact name Return address...
  • Page 92 6th-10th Floor, Building B1, Zhiyuan, Xueyuan Road, Xili, Nanshan, Shenzhen, 518055, China Other Services You can purchase the optional accessories directly from Maxaero’s authorized tool suppliers, and/or your local distributors or agents. Your purchase order should include the following information:...
  • Page 93: Chapter 6 Warranty

    Company’s option, without charge for parts or labor directly related to the defect(s). Please visit http://www.maxaero.com for details of the limited periods warranted for the different parts of this product. The Company shall not be liable for any incidental or consequential damages arising from the use, misuse, or mounting of the device.
  • Page 94 FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
