iCON-101CU Quick Installation Guide

Overview

The CAN (Controller Area Network) is a serial bus system and is

usually used in structuring intelligent industrial device networks and

building smart automatic control systems. The iCON-101CU is a

cost-efficient industrial converter for pairs to PC using the standard

USB interface. It supports CAN monitor tool that displays the CAN

received message in decimal or hexadecimal mode. This converter

shows the time stamp of each received message. The GUI

management program and programming guide both are ready for

use. The CAN host, monitor or HMI can access and control CAN

device through iCON-101CU.

Version A1 Oct 2011

Printed in Taiwan

9413C101000E

Need help?

Do you have a question about the icon-101CU and is the answer not in the manual?

Page 1 The CAN (Controller Area Network) is a serial bus system and is usually used in structuring intelligent industrial device networks and building smart automatic control systems. The iCON-101CU is a cost-efficient industrial converter for pairs to PC using the standard USB interface.
Page 2 Quick Installation Guide Features  Full compliance with USB 1.1/2.0 (fully speed)  Full compliance with CAN 2.0A and CAN 2.0B  D-sub DB9 CAN port support 3KV isolation  Easily setup to CAN terminator by software configuring ...
Page 3 Light off disabled. Driver It is necessary to install driver so the iCON-101CU can work properly under operating system. About how to install the device driver under Windows XP. You can follow the user manual instructions to install the driver.
Page 4 Utility You can use hyperterminal program to send and retrieve command messages from iCON-101CU. Or Use AXCAN utility to configure CAN communication parameters. It is also used to transmit or receive CAN messages for simple function testing. About how to install AXCAN software utility please follow the user manual instructions.
