Important Notes
The unit corresponds to all relevant direc-
tives of the EU and is therefore marked
with
.
WARNING The unit uses dangerous mains
voltage. Leave servicing to
skilled personnel and do not
insert anything into the air
vents; inexpert handling may
result in electric shock.
To prevent damage to your
eyes, never look directly into
the light source for any length
of time.
Please note that fast changes
in lighting may trigger epilep-
tic seizures with photosensi-
tive persons or persons with
epilepsy!
Install the unit safely and ex-
pertly. If it is installed at a place
where people may walk or sit
under, it must additionally be
secured (e. g. by a safty rope;
fix the safety rope so that the
maximum falling distance of
the unit will not exceed 20 cm).
The unit is suitable for indoor use only.
Protect it against dripping water, splash
water and high air humidity. The ad-
missible ambient temperature range is
0 – 40 °C.
MONACOR INTERNATIONAL GmbH & Co. KG • Zum Falsch 36 • 28307 Bremen
www.monacor.com
The heat generated inside the unit must
be dissipated by air circulation; never
cover the air vents of the housing.
Immediately disconnect the mains plug
from the socket
1. if the unit or the mains cable is visibly
damaged,
2. if a defect might have occurred after
the unit was dropped or suffered a sim-
ilar accident,
3. if malfunctions occur.
In any case the unit must be repaired by
skilled personnel.
Never pull the mains cable to disconnect
the mains plug from the socket, always
seize the plug.
When transporting the unit, always seize
its lower part. Never carry the unit by its
moving head or rotary arm.
No guarantee claims for the unit and no
liability for any resulting personal dam-
age or material damage will be accepted
if the unit is used for other purposes than
originally intended, if it is not safely in-
stalled or not correctly connected or op-
erated, or if it is not repaired in an expert
way.
If the unit is to be put out of oper-
ation definitively, take it to a local
recycling plant for a disposal which
is not harmful to the environment.
• Germany
01.18.01.2018
LEUCHTKRAFT

USER MANUAL

TWIST-40LED
Keep This Manual For Future Need

Advertisement

loading
Need help?

Need help?

Do you have a question about the TWIST-40LED and is the answer not in the manual?

Questions and answers

Summary of Contents for LeuchtKraft TWIST-40LED

  • Page 1: User Manual

    To prevent damage to your TWIST-40LED 3. if malfunctions occur. eyes, never look directly into In any case the unit must be repaired by the light source for any length skilled personnel.
  • Page 2 Unpacking: Thank purchasing TWIST-40LED workable in 100-240V/50~60Hz. Please make sure your unit voltage moving head wash, every fixture has been thoroughly tested and matches the wall outlet voltage before attempting to operate you fixture.
  • Page 3 DMX MODE: 150-184 5050 SMD section 3 Red mix Blue 185-219 5050 SMD section 3 Green mix Blue 16CH MODE: 220-255 5050 SMD section 3 RGB 000-010 No Function Channel DMX Value Function 011-044 5050 SMD section 4 Red 000-255 Pan 0°~ 540°...
  • Page 4 DMX address setting will be effect at once. Every time you turn the unit on. 185-219 5050 SMD section 3 Green mix Blue It will show TWIST-40LED on the display and move the motors to their 220-255 5050 SMD section 3 RGB position and you may hear some noises for about 20 seconds.
