Summary of Contents for Acucraft Outdoor Linear 8 Burner System
- Page 1 OUTDOOR LINEAR 8 BURNER SYSTEM Natural Gas www.acucraft.com 888-317-6499 Complies with ANSI Z21.97-2014 / CSA 2.41-2014 Installation/Operator’s Manual Rev5...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ................. pg 3 Safety / Warnings ..............pg 4 Installation Guide System Illustration ..............pg 5-9 Wiring Diagrams ..............pg 10 Connecting the Gas Valve & Ignition System ......pg 11 Installing the Media ............... pg 12 Operation Guide Instructions ................ -
Page 3: Introduction
We are a family first organization, and we strive to be good stewards locally, nationally, and internationally. Please review this manual carefully before installing your new fireplace. Model: Outdoor Linear 8 Burner System (NG) Acucraft Fireplaces 19672 172nd Street Big Lake, MN 55309 www.acucraft.com... -
Page 4: Safety / Warnings
The appliance is rated for installation up to 4500’ (1372m) damaged. For replacement please contact Acucraft at: above sea level. Above 4500’ the appliance must be 763-263-3156 or service@acucraft.com. -
Page 5: Installation Guide
INSTALLATION GUIDE Note: The installation of this product must conform with local codes or, in the absence of local codes, the cur- rent National Fuel Gas Code - ANZI Z223.1 (NFPA 54) Installation Code. Please check local codes before installation. NOTE TO INSTALLER: 1. - Page 6 It is imperative that the control compartment, burners and circulating air passageways of the appliance be kept clean. 2. Carefully inspect for shipping damage. If any parts are damaged, call Acucraft at 763-263-3156. 3. Correct installation and proper placement of the unit and decorative media is crucial to safe performance of the unit.
- Page 7 INSTALLATION GUIDE GAS INFORMATION Fuel - Before making gas connections ensure appliance being installed is compatible with the available gas type. Gas Pressure - Proper Input Pressures are required for optimum appliance performance. Gas line sizing re- quirements need to be made following NFPA51. Pressure Requirements for Appliance (Natural Gas) Minimum Inlet Pressure: 0.25 psi...
- Page 8 INSTALLATION GUIDE...
- Page 9 INSTALLATION GUIDE...
-
Page 10: Wiring Diagrams
INSTALLATION GUIDE... -
Page 11: Connecting The Gas Valve & Ignition System
INSTALLATION GUIDE Control Box Connection of the ignition system to the burner. On the side of the AWEIS there are two connections for the pilot burner assembly. The white “quick connect” is the electrical connection and the brass plumbing fitting is the gas connection. There is a label next to these connections, “Attached Pilot Burner Here.”... -
Page 12: Installing The Media
INSTALLATION GUIDE Installation of fireplace media and glass panels: This fireplace burner requires a layer of 1/4” glass media to cover the burner tube, allowing proper dissipation of the gas flow and prop- agation of the flame. This should be spread evenly across and completely covering the burner located inside of the square burner tray. -
Page 13: Instructions
INSTALLATION GUIDE OPERATING INSTRUCTIONS WARNING Do NOT use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. WARNING Fire Risk / Burn Risk / HOT! DO NOT TOUCH SEVERE BURNS MAY RESULT - CLOTHING IGNITION MAY RESULT... -
Page 14: Lighting Instructions
INSTALLATION GUIDE LIGHTING INSTRUCTIONS 1. Prior to turning appliance on, visually inspect fire feature to ensure debris such as leaves or other combustible material has not collected inside the feature which could burn and emit embers once the fire feature is turned on. Also ensure any person standing close to the fire feature is aware that you will be turning the fire feature on prior to actually turning it on. -
Page 15: Troubleshooting
24 volts. If you do have a minimum of 24 volts at the fire feature contact Acucraft for further assistance: 763-263-3156. Q: I installed the Electronic Ignition System, turned it on and I can see the glow plug glowing orange and I can hear gas flowing but it will not ignite. -
Page 16: Troubleshooting
2.0 amps. If you do not see the amps listed above AND the wire gauge used was less than 12 gauge wire - change the wiring. Otherwise contact Acucraft for further assistance: 763-263-3156. -
Page 17: Caution
INSTALLATION GUIDE CAUTION • Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition •... -
Page 18: Maintenance & Care
INSTALLATION GUIDE MAINTENANCE AND GENERAL CARE • Examination and inspection of the appliance and all components including the burner, should be performed annually by a qualified service technician • Examination and visual check of the burner & flame should be performed periodically to ensure prop- er operation •... -
Page 19: Specifications
PROPRIETARY AND CONFIDENTIAL: THE INFORMATION CONTAINED IN Acucraft Fireplace Systems 8 " THIS DRAWING IS THE SOLE UNLESS PROPERTY OF ACUCRAFT. ANY 19672 172nd Street REPRODUCTION IN PART OR AS A OTHERWISE Big Lake, MN 55309 WHOLE WITHOUT THE WRITTEN... - Page 20 PRODUCT SPECIFICATIONS...
-
Page 21: Notes
NOTES... -
Page 22: Warranty
The coverage of this warranty is limited to all components of the gas appliance manufactured by Acucraft. If the components of the gas appliance covered by this warranty are found to be defective within the time stated. Acucraft, at its option, will replace or repair defective components of the gas appliance manufactured by Acucraft at no charge, and may also choose pay for reasonable labor costs incurred in repairing components requiring approval prior to work commencing.This warranty covers only parts and labor as provided above. - Page 23 FIRE IS OUR PASSION www.acucraft.com 888-317-6499 Acucraft Fireplaces 19672 172nd Street Big Lake, MN 55309...
