OW-1000 Outdoor Wireless Access Point User’s Manual E F O R E I N S T A L L I N G T H E U N I T P L E A S E R E A D T H I S M A N U A L T H O R O U G H L Y...
Package Contents ......................3 System Requirements ....................4 Inline Power Injector (PoE) ..................4 Chapter 2. Installation and Basic Configuration ...............5 Before You Start ......................5 Locate the OW-1000 and Inline Power Injector Ports ..........6 Preparing Installation....................8 Basic Configuration .......................9 2.4.1 Basic Configuration Steps ..............9 2.4.2 Logging into the Web Interface ............9...
Introduction Introducing the OW-1000 The OW-1000 is fully interoperable with IEEE 802.11b/g compliant Outdoor Wireless Last-mile product. The OW-1000 operates in AP mode or remote bridge mode, and connects to OW-1000 AP/CB to construct point-to-point as well as point-to-multipoint topologies,...
This works great in areas where you may not have power , like house roof. This also allows you to place the OW-1000 unit closer to the antenna, to make installation easier more thus reducing signal loss over antenna cabling.
Chapter 2. Installation and Basic Configuration This chapter describes the procedures of installing the OW-1000. Before You Start After unpacking the system, make sure the following items are present and in good condition. Refer to below pictures for product image.
Locate the OW-1000 and Inline Power Injector Ports ► Interface on the OW-1000 Unit Ethernet Port 1 : for connecting the 30m RJ-45 CAT-5 Ethernet cable. ► Interface on the Inline Power Injector Data Input Port 2 : for connecting cross-over Ethernet Cable to PC or straight Ethernet cable to Hub Switch Router .
Page 7
► Mount OW-1000 on A Wall/Mast The OW-1000 can be mounted on the wall, you can use the Wall Mount kit to mount the OW-1000 as shown in Figure 2-2. Figure 2-2 You can also mount the OW-1000 to the mast as shown in Figure 2-3.
Step4 : Connect the remaining end of the 30m CAT 5 cable into the PoE labeled AP/Bridge. This is the power side of the PoE that will power up the OW-1000. When the OW-1000 receives power over the Ethernet cable, the OW-1000 will start its boot up sequence and the Active LED on the Inline Power Injector will light up.
Reboot the Device to take effect on the previous configuration changes. 2.4.2 Logging into the Web Interface The OW-1000 supports access to the configuration system through the use of an HTTP Interface. ► Web Configuration Before configuring OW-1000, the user needs to know the IP Address assigned to the unit.
Page 10
Figure 2-5 Step3 : Enter “admin” in the Username and Password fields, and click Log In to enter the web configuration user interface screen as shown below. Figure 2-6 ► Web Configuration Structure The web configuration user interface shown above in Figure 2-6 is grouped into a tree structure, and contains the following settings or information.
Page 11
▽ SYSTEM Administrator ● Firmware ● Configuration ● Status ● ● System Time ● Reboot ● ▽ NETWORK Network ● ▽ WIRELESS Access Control ● Wi-fi 1 ● Wi-fi 2 ● Wi-fi 3 ● Wi-fi 4 ● Wi-fi 5 ● Wi-fi 6 ●...
2.4.3 Set Operating Mode, IP Address, Subnet Mask, Default Route IP, DNS Server IP of OW-1000 ► LAN Settings These are the settings of the LAN (Local Area Network) interface for the Access Point. The Access Point's local network (LAN) settings are configured based on the IP Address and Subnet Mask assigned in this section.
► IP Address The IP address of the AP on the local area network. Assign any unused IP address in the range of IP addresses available for the LAN. For example, 192.168.1.1. ► Subnet Mask The subnet mask of the local area network. ►...
2.4.4 Set Wireless SSID for Wireless Interface ► Wireless Network Name (Also called the SSID) When you are browsing for available wireless networks, this is the name that will appear in the list (unless Visibility Status is set to Invisible, see below). This name is also referred to as the SSID.
2.4.5 Set Wireless Encryption for Wireless Interface The OW-1000 supports 64-bit and 128-bit WEP encryption. For 64-bit WEP encryption, an encryption key is 10 hexadecimal characters (0-9 and A-F) or 5 ASCII characters. For 128-bit WEP encryption, an encryption key is 26 hexadecimal characters or 13 ASCII characters.
2.4.6 Change Supervisor Account & Password Enter the SYSTEM > Administrator page. Figure 2-10 below shows the SYSTEM / Administrator page. Figure 2-10 ADMIN PASSWORD ► Key in current password in the SYSTEM / Administrator / Password Setting Current Password field. Change the ADMIN PASSWORD’s password in the SYSTEM / Administrator Password Setting Password and Re-type Password fields, and click APPLY ,than,“/SYSTEM/Reboot ”Reboot.
► Update the Firmware Enter the SYSTEM > FIRMWARE page as shown in Figure 2-11 to upgrade OW-1000. Here, user must select which file you want to upgrade it (Program image), then click APPLY button to start the upgrade process.
